Sinotruk Howo MAN Pioneer H3 160hp 4X4(6 wheels) 4.2m Single Row Off-road Side Panel Light Truck

Export reference
From $27,083
MSRP ¥19.5M CNY
Horsepower: 160
Emission: China VI
Fuel: Diesel
Engine: Weichai2.5L
Transmission: Fast Gear
Curb Weight:: 2.975ton
seating capacity: 2Personnel
Rated payload: 1.06ton
Drive 4X4 (6 wheels)
Cargo box type: stake body

Overview

The Sinotruk Howo MAN Pioneer H3 160hp 4X4(6 wheels) 4.2m Single Row Off-road Side Panel Light Truck is a Light Truck featuring 4.2m cargo length, stake body cargo body, 2Personnel volume and 1.06t payload. On the powertrain side, it comes with a Weichai2.5L engine, 160 hp, 4X4 (6 wheels) drive and China VI emissions.

China VI 160 Diesel 4X4

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): ZZ2048F27FB1
Type: Cargo Trucks
Drive type: 4X4
Wheelbase: 3360mm
Box length class: 4.2m
engine: WeichaiWP2.5NQ160E61
transmission: Fast Gear8JS85TE-C
Rear Axle Ratio: 6.73
Cab length: 5.998m
Cab width: 2.2m
Cab height: 2.52m
Front track width: 1570mm
rear track: 1485mm
Curb Weight: 2.975ton
Rated payload: 1.06ton
GVWR: 4.165ton
Max. speed: 89km/h
tonnage class: Light Truck
Approach angle: 24°
departure angle: 15°
Front/rear suspension: 1.175/1.463m
Energy Type: Diesel
Engine parameters
Engine Brand: Weichai
Engine Model: WeichaiWP2.5NQ160E61
Engine info: Weichai2.5L
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 2.49L
Emission standard: China VI
Max output power: 118kW
Max hp: 160Horsepower
Max torque: 450N·m
Max torque speed: 1400-2200rpm
Rated speed: 2900rpm
Engine Type: High-pressure common rail
Transmission Parameters
Transmission Model: Fast Gear8JS85TE-C
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 8Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Cargo box type: stake body
Cargo box length: 4.2m
Cargo box width: 2.1m
Cargo box height: 0.4m
*Cargo box interior width: 2.1
Cab parameters
Cab width: 1880mm
seating capacity: 2Personnel
Seat rows: Single Row
fuel tank
Fuel tank material: aluminum alloy
Fuel tank capacity: 150L
Chassis Specs
Front axle description: Q205
Front axle allowable load: 1545kg
Frame Dimensions: 230mm
rear axle description: H205,6T
rear axle allowable load: 2620kg
Axle ratio: 6.73
Leaf spring count: 11/11+7
Tire
Tire Size: 7.00R16LT 8PR
Number of tires: 6pcs
Control configuration
ABS:
interior configuration
AC control type: Manual
Power Windows:
Remote key:
Electronic Central Lock:
Multimedia features
External audio input (AUX/USB/iPod etc.):
Service brake
Brake Type: Air brake
Parking brake: Spring brake
Front wheel brake: Drum Type
Rear Wheel Brake: Drum Type

Photos

0 photos

FAQ

What is the export price of Sinotruk Howo MAN Pioneer H3 160hp 4X4(6 wheels) 4.2m Single Row Off-road Side Panel Light Truck, and what does it include?

Sinotruk Howo MAN Pioneer H3 160hp 4X4(6 wheels) 4.2m Single Row Off-road Side Panel Light Truck export reference is about From $27,083; MSRP is ¥19.5M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does Sinotruk Howo MAN Pioneer H3 160hp 4X4(6 wheels) 4.2m Single Row Off-road Side Panel Light Truck use, and can it enter my country?

This model is listed as China VI. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Sinotruk Howo MAN Pioneer H3 160hp 4X4(6 wheels) 4.2m Single Row Off-road Side Panel Light Truck?

Key specs of Sinotruk Howo MAN Pioneer H3 160hp 4X4(6 wheels) 4.2m Single Row Off-road Side Panel Light Truck: Drive: 4x4; Horsepower: 160 hp; Emission: China VI; Fuel: Diesel; Engine: Weichai2.5L; Transmission: Fast Gear. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Sinotruk Howo MAN Pioneer H3 160hp 4X4(6 wheels) 4.2m Single Row Off-road Side Panel Light Truck suited for?

Sinotruk Howo MAN Pioneer H3 160hp 4X4(6 wheels) 4.2m Single Row Off-road Side Panel Light Truck is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does Sinotruk Howo MAN Pioneer H3 160hp 4X4(6 wheels) 4.2m Single Row Off-road Side Panel Light Truck differ from other variants in the same series?

Sinotruk Howo MAN Pioneer H3 160hp 4X4(6 wheels) 4.2m Single Row Off-road Side Panel Light Truck belongs to Sinotruk Pioneer Light Truck (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Sinotruk Howo MAN Pioneer H3 160hp 4X4(6 wheels) 4.2m Single Row Off-road Side Panel Light Truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Sinotruk Howo MAN Pioneer H3 160hp 4X4(6 wheels) 4.2m Single Row Off-road Side Panel Light Truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
