JAC EK6 4.18m Single-Row Electric Cargo Cage Light Truck CATL 86.55kWh 4X2(6 wheels)

Export reference
From $24,972
MSRP ¥17.98M CNY
Rated payload:: 1.2ton
Wheelbase:: 3365mm
Cargo box type:: Stake type
Model code (announced):: HFC5043CCYEV3N
Type:: stake truck
Box length class:: 4.2m
Drive 4X2 (6 wheels)
CLTC range: 260km
Motor 1 Brand: Sichuan JAC
Curb Weight: 3.1ton

Overview

The JAC EK6 4.18m Single-Row Electric Cargo Cage Light Truck CATL 86.55kWh 4X2(6 wheels) is a Light Truck featuring 260km battery/range, Sichuan JAC motor, 4X2 (6 wheels) drive and 1.2t payload.

4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): HFC5043CCYEV3N
Type: stake truck
Drive type: 4X2
Wheelbase: 3365mm
Box length class: 4.2m
Cab length: 5.995m
Cab width: 2.2m
Cab height: 3.1m
CLTC range: 260km
Curb Weight: 3.1ton
Rated payload: 1.2ton
GVWR: 4.495ton
Max. speed: 90km/h
Origin: Suining, Sichuan
tonnage class: Light Truck
Energy Type: Electric
electric motor
Motor 1 Brand: Sichuan JAC
Motor 1 Model: TZ220XS-SJ01
Motor Type: Permanent magnet synchronous motor
total rated power: 65kW
Peak power: 140kW
Battery/Charging
Battery Brand: CATL
Battery type: Lithium Iron Phosphate Battery
Battery capacity: 86.55kWh
Cargo box parameters
Cargo box type: Stake type
Cargo box length: 4.18m
Cargo box width: 2.1m
Cab parameters
Cab width: 1995mm
seating capacity: 3Personnel
Seat rows: Single Row
Chassis Specs
Front axle allowable load: 1950kg
rear axle allowable load: 2545kg
Tire
Tire Size: 7.00R16LT 8PR
Number of tires: 6pcs
Control configuration
ABS:
interior configuration
AC control type: Manual
Power Windows:
Remote key:
Electronic Central Lock:

Photos

Exterior1

1 photos

FAQ

What is the export price of JAC EK6 4.18m Single-Row Electric Cargo Cage Light Truck CATL 86.55kWh 4X2(6 wheels), and what does it include?

JAC EK6 4.18m Single-Row Electric Cargo Cage Light Truck CATL 86.55kWh 4X2(6 wheels) export reference is about From $24,972; MSRP is ¥17.98M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What are the key specs of JAC EK6 4.18m Single-Row Electric Cargo Cage Light Truck CATL 86.55kWh 4X2(6 wheels)?

Key specs of JAC EK6 4.18m Single-Row Electric Cargo Cage Light Truck CATL 86.55kWh 4X2(6 wheels): Drive: 4x2. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is JAC EK6 4.18m Single-Row Electric Cargo Cage Light Truck CATL 86.55kWh 4X2(6 wheels) suited for?

JAC EK6 4.18m Single-Row Electric Cargo Cage Light Truck CATL 86.55kWh 4X2(6 wheels) is a electric cargo truck model suited to short-haul or fixed routes with charging access. Confirm local charging and registration rules, then request a quote.

How does JAC EK6 4.18m Single-Row Electric Cargo Cage Light Truck CATL 86.55kWh 4X2(6 wheels) differ from other variants in the same series?

JAC EK6 4.18m Single-Row Electric Cargo Cage Light Truck CATL 86.55kWh 4X2(6 wheels) belongs to JAC New Energy (electric cargo truck). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for JAC EK6 4.18m Single-Row Electric Cargo Cage Light Truck CATL 86.55kWh 4X2(6 wheels)?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export JAC EK6 4.18m Single-Row Electric Cargo Cage Light Truck CATL 86.55kWh 4X2(6 wheels)?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
