Yuchai 85kW(electric) 190hp(diesel) YCK05190-60(YCPD170-1)eCVT1 split-type hybrid powertrain

Export reference
MSRP N/A
Overall dimensions:: 1768.2×790×1013
Weight:: 760kg
Energy Type:: Hybrid
Yuchai 85kW(electric) 190hp(diesel) YCK05190-60(YCPD170-1)eCVT1 split-type hybrid powertrain exterior
View more photos (1)
Suitable Vehicle Model: 12-20 ton trucks; 12-20 ton special vehicles; 10-12m buses
Model: YCPD170-1
brand: Yuchai

Overview

The Yuchai 85kW(electric) 190hp(diesel) YCK05190-60(YCPD170-1)eCVT1 split-type hybrid powertrain is a parts product with fit for 12-20 ton trucks; 12-20 ton special vehicles; 10-12m buses and spec YCPD170-1.

China VI 190 Diesel

Model Specs

Legend: ● Standard　○ Optional　- N/A

Basic Info
Model: YCPD170-1
brand: Yuchai
Overall dimensions: 1768.2×790×1013
Weight: 760kg
Energy Type: Hybrid
Engine parameters
Engine Series: YCK05 Series
Engine manufacturer: Guangxi Yuchai Machinery Co., Ltd.
Engine Model: YCK05190-60
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 5.1L
Emission standard: China VI
Max output power: 140kW
Max hp: 190Horsepower
Max torque: 700N·m
Max torque speed: 1200-1700rpm
Rated speed: 2200rpm
Other parameters
Voltage Platform: 560/600/700
cooling method: Water-Cooled
Suitable Vehicle Model: 12-20 ton trucks; 12-20 ton special vehicles; 10-12m buses
electric motor
total rated power: 85kW
Peak power: 107kW
total rated torque: 165N·m
total peak torque: 205N·m

Photos

Exterior1

Yuchai 85kW(electric) 190hp(diesel) YCK05190-60(YCPD170-1)eCVT1 split-type hybrid powertrain Exterior (1) | 86Trucks

1 photos

FAQ

What emission standard does Yuchai 85kW(electric) 190hp(diesel) YCK05190-60(YCPD170-1)eCVT1 split-type hybrid powertrain use, and can it enter my country?

This model is listed as China VI. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Yuchai 85kW(electric) 190hp(diesel) YCK05190-60(YCPD170-1)eCVT1 split-type hybrid powertrain?

Key specs of Yuchai 85kW(electric) 190hp(diesel) YCK05190-60(YCPD170-1)eCVT1 split-type hybrid powertrain: Horsepower: 190 hp; Emission: China VI; Fuel: Diesel. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Yuchai 85kW(electric) 190hp(diesel) YCK05190-60(YCPD170-1)eCVT1 split-type hybrid powertrain suited for?

Match Yuchai 85kW(electric) 190hp(diesel) YCK05190-60(YCPD170-1)eCVT1 split-type hybrid powertrain to your job using drive, horsepower and emission on this page. Include use case, destination and quantity in your quote request.

How does Yuchai 85kW(electric) 190hp(diesel) YCK05190-60(YCPD170-1)eCVT1 split-type hybrid powertrain differ from other variants in the same series?

Yuchai 85kW(electric) 190hp(diesel) YCK05190-60(YCPD170-1)eCVT1 split-type hybrid powertrain belongs to Yuchai eCVT1 Series (Hybrid Powertrain). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Yuchai 85kW(electric) 190hp(diesel) YCK05190-60(YCPD170-1)eCVT1 split-type hybrid powertrain?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Yuchai 85kW(electric) 190hp(diesel) YCK05190-60(YCPD170-1)eCVT1 split-type hybrid powertrain?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
