FAW Jiefang J6L Classic Edition 320hp 8X2(10 wheels) 9.6m flatbed cargo truck (flat roof)

Export reference
From $35,083
MSRP ¥25.26M CNY
Horsepower: 320
Emission: China VI
Fuel: Diesel
Engine: Dachai 6-cylinder
Transmission: FAW Jiefang
Curb Weight:: 10.437ton
seating capacity: 2Personnel
Rated payload: 20.433ton
Drive 8X2 (10 wheels)
Cargo box type: stake body

Overview

The FAW Jiefang J6L Classic Edition 320hp 8X2(10 wheels) 9.6m flatbed cargo truck (flat roof) is a Heavy-duty cargo trucks featuring 9.6m cargo length, stake body cargo body, 2Personnel volume and 20.433t payload. On the powertrain side, it comes with a Dachai 6-cylinder engine, 320 hp, 8X2 (10 wheels) drive and China VI emissions.

China VI 320 Diesel 8X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): CA1310P62K1L5T10E6
Type: Cargo Trucks
Drive type: 8X2
Wheelbase: 1900+5400+1350mm
Box length class: 9.6m
engine: DachaiCA6DK2-32E65
transmission: FAW JiefangCA10TAX130S
Rear Axle Ratio: 4.1
Cab length: 11.9m
Cab width: 2.55m
Cab height: 3.13m
Front track width: 1960/1960mm
rear track: 1878/2050mm
Curb Weight: 10.437ton
Rated payload: 20.433ton
GVWR: 31ton
Max. speed: 89km/h
Origin: Changchun
tonnage class: Heavy-duty cargo trucks
Approach angle: 21°
departure angle: 19°
Front/rear suspension: 1.4/1.85m
Version: Classic Edition
Energy Type: Diesel
Engine parameters
Engine Brand: Dachai
Engine Model: DachaiCA6DK2-32E65
Engine info: Dachai 6-cylinder
Number of cylinders: 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 7.751L
Emission standard: China VI
Max output power: 238kW
Max hp: 320Horsepower
Max torque: 1310N·m
Max torque speed: 1300-1500rpm
Rated speed: 2100rpm
Engine Type: DOC+DPF+HI+SCR
Transmission Parameters
Transmission Model: FAW JiefangCA10TAX130S
Transmission Brand: FAW Jiefang
shift method: Manual
Forward gears: 10Gear
Number of Reverse Gears: 2pcs
Housing Material: aluminum alloy
Cargo box parameters
Cargo box type: stake body
Cargo box length: 9.6m
Cargo box width: 2.46m
Cargo box height: 0.6m
*Cargo box interior width: 2.46
Cab parameters
Cab: J6L Classic Full-Float Flat-Top Semi-Sleeper Cab
Cab suspension: 4-point mechanical suspension
Cab tilting: Electric
seating capacity: 2Personnel
Seat rows: Sleeper cab
fuel tank
Fuel tank material: aluminum alloy
Fuel tank capacity: 300L
Chassis Specs
Front axle description: New F4N-1960 Front Axle
Front axle allowable load: 6500/6500kg
Frame Dimensions: 270×75×(7+5)mm
rear axle description: Axle φ457 stamped-welded axle
rear axle allowable load: 18000 (tandem axle group)kg
Axle ratio: 4.1
Leaf spring count: 10/10/10+9/-
clutch: Φ395
Tire
Tire Size: 12R22.5
Number of tires: 10pcs
Control configuration
ABS:
automatic slack adjuster:
interior configuration
AC control type: Automatic
Power Windows:
Power Mirrors:
Electric Heated Rearview Mirror:
lighting configuration
Front fog lamp:
smart configuration
Cruise control (CCS):

Photos

0 photos

FAQ

What is the export price of FAW Jiefang J6L Classic Edition 320hp 8X2(10 wheels) 9.6m flatbed cargo truck (flat roof), and what does it include?

FAW Jiefang J6L Classic Edition 320hp 8X2(10 wheels) 9.6m flatbed cargo truck (flat roof) export reference is about From $35,083; MSRP is ¥25.26M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does FAW Jiefang J6L Classic Edition 320hp 8X2(10 wheels) 9.6m flatbed cargo truck (flat roof) use, and can it enter my country?

This model is listed as China VI. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of FAW Jiefang J6L Classic Edition 320hp 8X2(10 wheels) 9.6m flatbed cargo truck (flat roof)?

Key specs of FAW Jiefang J6L Classic Edition 320hp 8X2(10 wheels) 9.6m flatbed cargo truck (flat roof): Drive: 8x2; Horsepower: 320 hp; Emission: China VI; Fuel: Diesel; Engine: Dachai 6-cylinder; Transmission: FAW Jiefang. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is FAW Jiefang J6L Classic Edition 320hp 8X2(10 wheels) 9.6m flatbed cargo truck (flat roof) suited for?

FAW Jiefang J6L Classic Edition 320hp 8X2(10 wheels) 9.6m flatbed cargo truck (flat roof) is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does FAW Jiefang J6L Classic Edition 320hp 8X2(10 wheels) 9.6m flatbed cargo truck (flat roof) differ from other variants in the same series?

FAW Jiefang J6L Classic Edition 320hp 8X2(10 wheels) 9.6m flatbed cargo truck (flat roof) belongs to FAW Jiefang J6L Medium Truck (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for FAW Jiefang J6L Classic Edition 320hp 8X2(10 wheels) 9.6m flatbed cargo truck (flat roof)?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export FAW Jiefang J6L Classic Edition 320hp 8X2(10 wheels) 9.6m flatbed cargo truck (flat roof)?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
