Hitachi ZX470LCH-5G Crawler Excavator

Export reference
MSRP N/A
Model:: ZX470LCH-5G
Engine Model:: crawler excavator
Tonnage:: 47ton
Bucket capacity:: 2.1cubic meter
boom length:: 6300mm
Arm Length:: 2900mm
Hitachi ZX470LCH-5G Crawler Excavator exterior
View more photos (3)
Operating weight: 47.2ton
Bucket type: backhoe
Fuel Tank Capacity: 725L
Product power: Conventional Power

Overview

The Hitachi ZX470LCH-5G Crawler Excavator is a excavator featuring 47.2ton GVW, backhoe bucket capacity, 725L tank capacity and Conventional Power power. On the powertrain side, it comes with a crawler excavator engine.

Model Specs

Legend: ● Standard　○ Optional　- N/A

Basic Info
Model: ZX470LCH-5G
Engine Model: crawler excavator
Product power: Conventional Power
Bucket type: backhoe
Tonnage: 47ton
Operating weight: 47.2ton
Bucket capacity: 2.1cubic meter
boom length: 6300mm
Arm Length: 2900mm
Machine dimensions: 11.56×4.3×3.48mm
Track shoe width: 600mm
Track gauge: 2890mm
Counterweight ground clearance: 1360mm
Min ground clearance: 723cm
Rear Overhang Radius: 3645mm
hydraulic system
Max flow of main pump: 2×360+30L/min
Working hydraulic circuit: 31.9
travel hydraulic circuit: 34.3Mpa
Swing Hydraulic Circuit: 27.9Mpa
Oil capacity
Fuel Tank Capacity: 725L
coolant: 55L
hydraulic oil tank: 330L
Engine Oil Capacity: 57L
performance specs
Travel speed: 3.4/5.5km/h
Bucket digging force: 296kN
Arm Digging Force: 218kN
Operating Range
Max digging radius: 12060mm
Max digging depth: 5790mm
Max digging height: 10660mm
Max unloading height: 7320mm
Max vertical digging depth: 4260mm
Engine parameters
Engine Model: IsuzuISUZU AH-6WG1XYSA-01
Max output power: 235kW

Photos

Exterior3

Hitachi ZX470LCH-5G Crawler Excavator Exterior (1) | 86Trucks Hitachi ZX470LCH-5G Crawler Excavator Exterior (2) | 86Trucks Hitachi ZX470LCH-5G Crawler Excavator Exterior (3) | 86Trucks

3 photos

FAQ

What transport jobs is Hitachi ZX470LCH-5G Crawler Excavator suited for?

Hitachi ZX470LCH-5G Crawler Excavator is a excavator model; configuration should match the job. State the application, emission and LHD/RHD needs in your quote.

How does Hitachi ZX470LCH-5G Crawler Excavator differ from other variants in the same series?

Hitachi ZX470LCH-5G Crawler Excavator belongs to Hitachi Hitachi Crawler Excavator (excavator). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Hitachi ZX470LCH-5G Crawler Excavator?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Hitachi ZX470LCH-5G Crawler Excavator?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
