XCMG XS202 Hydraulic Drive Single Drum Vibratory Roller

Export reference
MSRP N/A
Engine Model:: Single-drum roller
Front axle load distribution:: 13.5ton
Rear Wheel Distributed Mass:: 6.5ton
vibration frequency:: 33Hz
nominal amplitude:: 1.86mm
Highway cruising speed:: 10km/h
Operating mass: 20ton
Fuel tank capacity: 240L
Max output power: 132kW
Model: XS202

Overview

The XCMG XS202 Hydraulic Drive Single Drum Vibratory Roller is a roller featuring 20ton GVW, 240L tank capacity and 132kW power. On the powertrain side, it comes with a Single-drum roller engine.

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model: XS202
Engine Model: Single-drum roller
Fuel tank capacity: 240L
Operating mass: 20ton
Front axle load distribution: 13.5ton
Rear Wheel Distributed Mass: 6.5ton
Compaction Parameters
vibration frequency: 33Hz
nominal amplitude: 1.86mm
Maneuverability
Highway cruising speed: 10km/h
Theoretical Gradeability: 50
Min turning outer radius: 6.5m
Engine parameters
Engine Model: Cummins B5.9
Max output power: 132kW

Photos

Exterior1

1 photos

FAQ

What transport jobs is XCMG XS202 Hydraulic Drive Single Drum Vibratory Roller suited for?

XCMG XS202 Hydraulic Drive Single Drum Vibratory Roller is a roller model; configuration should match the job. State the application, emission and LHD/RHD needs in your quote.

How does XCMG XS202 Hydraulic Drive Single Drum Vibratory Roller differ from other variants in the same series?

XCMG XS202 Hydraulic Drive Single Drum Vibratory Roller belongs to XCMG Single Drum Roller (roller). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for XCMG XS202 Hydraulic Drive Single Drum Vibratory Roller?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export XCMG XS202 Hydraulic Drive Single Drum Vibratory Roller?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
