Tangjun Ouling T6 Series 160hp 6X2(8 wheels) 6.75m Semi-panel Flatbed Cargo Truck (Ratio: 5.571)

Export reference
From $21,389
MSRP ¥15.4M CNY
Horsepower: 160
Emission: China IV
Fuel: Diesel
Engine: Yuchai 4-cylinder
Transmission: Fast Gear
Curb Weight:: 6.7ton
seating capacity: 3Personnel
Rated payload: 15.705ton
Drive 6X2 (8 wheels)
Cargo box type: stake body

Overview

The Tangjun Ouling T6 Series 160hp 6X2(8 wheels) 6.75m Semi-panel Flatbed Cargo Truck (Ratio: 5.571) is a Medium-duty truck featuring 6.75m cargo length, stake body cargo body, 3Personnel volume and 15.705t payload. Its segment focus covers Building materials and agricultural products, matching those duty cycles. On the powertrain side, it comes with a Yuchai 4-cylinder engine, 160 hp, 6X2 (8 wheels) drive and China IV emissions.

China IV 160 Diesel 6X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): ZB1230DPQ2F
Type: Cargo Trucks
Drive type: 6X2
Wheelbase: 1800+3800mm
Box length class: 6.8m
engine: YuchaiYC4E160-45
transmission: Fast Gear8JS85E
Rear Axle Ratio: 5.571
Cab length: 9.195m
Cab width: 2.49m
Cab height: 2.895m
Front track width: 1896/1896mm
rear track: 1864mm
Curb Weight: 6.7ton
Rated payload: 15.705ton
GVWR: 22.6ton
Max. speed: 85km/h
Origin: Zibo, Shandong
tonnage class: Medium-duty truck
Approach angle: 25°
departure angle: 15°
market segment: Building materials, agricultural products
Front/rear suspension: 1.33/1.715m
Energy Type: Diesel
Engine parameters
Engine Brand: Yuchai
Engine Model: YuchaiYC4E160-45
Engine info: Yuchai 4-cylinder
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 4.26L
Emission standard: China IV
Max output power: 118kW
Max hp: 160Horsepower
Max torque: 550N·m
Max torque speed: 1300-1600rpm
Rated speed: 2600rpm
Engine Type: Vertical, inline 4-cylinder, water-cooled, 4-stroke, electronic direct injection
Transmission Parameters
Transmission Model: Fast Gear8JS85E
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 8Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Cargo box type: stake body
Cargo box length: 6.75m
Cargo box width: 2.3m
Cargo box height: 0.8m
*Cargo box interior width: 2.2999999523163
Cab parameters
Cab: Isuzu flat roof
seating capacity: 3Personnel
Seat rows: Sleeper cab
fuel tank
Fuel tank material: aluminum alloy
Fuel tank capacity: 180L
Chassis Specs
Front axle allowable load: 6000/6300kg
rear axle description: 153
rear axle allowable load: 10300kg
Axle ratio: 5.571
Leaf spring count: 10/10/11+8
Tire
Tire Size: 10.00-20
Number of tires: 8pcs
Control configuration
ABS:
Service brake
Parking brake: Spring brake

Photos

0 photos

FAQ

What is the export price of Tangjun Ouling T6 Series 160hp 6X2(8 wheels) 6.75m Semi-panel Flatbed Cargo Truck (Ratio: 5.571), and what does it include?

Tangjun Ouling T6 Series 160hp 6X2(8 wheels) 6.75m Semi-panel Flatbed Cargo Truck (Ratio: 5.571) export reference is about From $21,389; MSRP is ¥15.4M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does Tangjun Ouling T6 Series 160hp 6X2(8 wheels) 6.75m Semi-panel Flatbed Cargo Truck (Ratio: 5.571) use, and can it enter my country?

This model is listed as China IV. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Tangjun Ouling T6 Series 160hp 6X2(8 wheels) 6.75m Semi-panel Flatbed Cargo Truck (Ratio: 5.571)?

Key specs of Tangjun Ouling T6 Series 160hp 6X2(8 wheels) 6.75m Semi-panel Flatbed Cargo Truck (Ratio: 5.571): Drive: 6x2; Horsepower: 160 hp; Emission: China IV; Fuel: Diesel; Engine: Yuchai 4-cylinder; Transmission: Fast Gear. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Tangjun Ouling T6 Series 160hp 6X2(8 wheels) 6.75m Semi-panel Flatbed Cargo Truck (Ratio: 5.571) suited for?

Tangjun Ouling T6 Series 160hp 6X2(8 wheels) 6.75m Semi-panel Flatbed Cargo Truck (Ratio: 5.571) is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does Tangjun Ouling T6 Series 160hp 6X2(8 wheels) 6.75m Semi-panel Flatbed Cargo Truck (Ratio: 5.571) differ from other variants in the same series?

Tangjun Ouling T6 Series 160hp 6X2(8 wheels) 6.75m Semi-panel Flatbed Cargo Truck (Ratio: 5.571) belongs to Tangjun T6 Medium Truck (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Tangjun Ouling T6 Series 160hp 6X2(8 wheels) 6.75m Semi-panel Flatbed Cargo Truck (Ratio: 5.571)?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Tangjun Ouling T6 Series 160hp 6X2(8 wheels) 6.75m Semi-panel Flatbed Cargo Truck (Ratio: 5.571)?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
