SHACMANCummins Delong X3000 Green Pass Edition 440 hp 8X4(12 wheels) 9.55m stake truck

Export reference
From $50,708
MSRP ¥36.51M CNY
Horsepower: 440
Emission: China V
Fuel: Diesel
Engine: Xikang 11L
Transmission: Fast Gear
Curb Weight:: 13.95ton
seating capacity: 3Personnel
Rated payload: 16.92ton
Drive 8X4 (12 wheels)
Cargo box type: Stake type

Overview

The SHACMANCummins Delong X3000 Green Pass Edition 440 hp 8X4(12 wheels) 9.55m stake truck is a Heavy-duty cargo trucks featuring 9.55m cargo length, Stake type cargo body, 3Personnel volume and 16.92t payload. Its segment focus covers Agricultural product transport and LTL transport, matching those duty cycles. On the powertrain side, it comes with a Xikang 11L engine, 440 hp, 8X4 (12 wheels) drive and China V emissions.

China V 440 Diesel 8X4

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): SX5310CCY4C4562
Type: stake truck
Drive type: 8X4
Wheelbase: 1800+4575+1400mm
Box length class: 9.6m
engine: Xi’an CumminsISM11E5 440
transmission: Fast Gear 12-speed
Rear Axle Ratio: 3.7
Cab length: 12m
Cab width: 2.55m
Cab height: 3.98m
Front track width: 2011/2011mm
rear track: 1860/1860mm
Curb Weight: 13.95ton
Rated payload: 16.92ton
GVWR: 31ton
Max. speed: 108km/h
Origin: Xi'an, Shaanxi
tonnage class: Heavy-duty cargo trucks
Approach angle: 17°
departure angle: 11°
market segment: Agricultural product transport, LTL transport
Remarks: Fiberglass bumper, Tianxingjian Zhixing Edition, 180Ah maintenance-free battery, telescopic shift shaft, spare tire carrier, ring curtain, imported oil-filtering APU, WP13 model-specific cab appearance, WP13 model-specific DC air filter, ISM engine standard Jacob brake, ISM model standard dual-cylinder air compressor
Front/rear suspension: 1.525/2.7m
Version: Green Pass Edition
Energy Type: Diesel
Engine parameters
Engine Brand: Xi’an Cummins
Engine Model: Xi’an CumminsISM11E5 440
Engine info: Xikang 11L
Number of cylinders: 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 10.8L
Emission standard: China V
Max output power: 324kW
Max hp: 440Horsepower
Max torque: 2150N·m
Max torque speed: 1100-1300rpm
Rated speed: 1900rpm
Engine Type: Full electronic control
Transmission Parameters
Transmission Model: Fast Gear 12-speed
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 12Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Cargo box type: Stake type
Cargo box length: 9.55m
Cargo box width: 2.45m
*Cargo box interior width: 2.4500000476837
Cab parameters
Cab: Extended high roof cab
Cab tilting: Electric
seating capacity: 3Personnel
Seat rows: Sleeper cab
Driver seat type: air suspension seat
fuel tank
Fuel tank material: aluminum alloy
Fuel tank capacity: 700L
Chassis Specs
Front axle description: MAN5.5T
Front axle allowable load: 6500/6500kg
Frame Dimensions: 850×300 (single 8)mm
rear axle description: 11.5T MAN single reduction
rear axle allowable load: 18000 (tandem axle group)kg
Axle ratio: 3.7
Leaf spring count: 3/3/5
Suspension (front/rear): Front and rear leaf springs (few)
Tire
Tire Size: 12R22.5
Number of tires: 12pcs
Control configuration
ABS:
interior configuration
Multifunction steering wheel:
AC control type: Automatic
Power Windows:
Power Mirrors:
Electric Heated Rearview Mirror:
Electronic Central Lock:
Exterior features
Aluminum air tank:
lighting configuration
daytime running lights:
smart configuration
Cruise control (CCS):

Photos

0 photos

FAQ

What is the export price of SHACMANCummins Delong X3000 Green Pass Edition 440 hp 8X4(12 wheels) 9.55m stake truck, and what does it include?

SHACMANCummins Delong X3000 Green Pass Edition 440 hp 8X4(12 wheels) 9.55m stake truck export reference is about From $50,708; MSRP is ¥36.51M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does SHACMANCummins Delong X3000 Green Pass Edition 440 hp 8X4(12 wheels) 9.55m stake truck use, and can it enter my country?

This model is listed as China V. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of SHACMANCummins Delong X3000 Green Pass Edition 440 hp 8X4(12 wheels) 9.55m stake truck?

Key specs of SHACMANCummins Delong X3000 Green Pass Edition 440 hp 8X4(12 wheels) 9.55m stake truck: Drive: 8x4; Horsepower: 440 hp; Emission: China V; Fuel: Diesel; Engine: Xikang 11L; Transmission: Fast Gear. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is SHACMANCummins Delong X3000 Green Pass Edition 440 hp 8X4(12 wheels) 9.55m stake truck suited for?

SHACMANCummins Delong X3000 Green Pass Edition 440 hp 8X4(12 wheels) 9.55m stake truck is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does SHACMANCummins Delong X3000 Green Pass Edition 440 hp 8X4(12 wheels) 9.55m stake truck differ from other variants in the same series?

SHACMANCummins Delong X3000 Green Pass Edition 440 hp 8X4(12 wheels) 9.55m stake truck belongs to SHACMAN Delong X3000 Heavy Truck (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for SHACMANCummins Delong X3000 Green Pass Edition 440 hp 8X4(12 wheels) 9.55m stake truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export SHACMANCummins Delong X3000 Green Pass Edition 440 hp 8X4(12 wheels) 9.55m stake truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
