Lieniu 13m Dump Trailer

Export reference
MSRP N/A
Cab length:: 13m
Axle Brand:: Lieniu
suspension:: Anti-scrub tread design
Wheel Material:: Steel
Brake chamber:: 4 double 2 single
Toolbox:: Steel aluminum doorpcs
Design load capacity: 32.8ton
Cargo box floor thickness: 2mm
Curb Weight: 7.2ton
Tire brand: Goodyear

Overview

The Lienew Lieniu 13m Dump Trailer is a dump semi-trailer featuring 32.8ton payload, 7.2ton GVW, 2mm cargo body and 13m cab.

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Design load capacity: 32.8ton
Cab length: 13m
Cab width: 2.55m
Cab height: 2.9m
Curb Weight: 7.2ton
Chassis Specs
Axle Brand: Lieniu
Number of Axles: 3
Axle Load Rating: 24000kg
suspension: Anti-scrub tread design
Wheel Material: Steel
Parts & accessories
Brake chamber: 4 double 2 single
Toolbox: Steel aluminum doorpcs
ABS: Kemi
Body Parameters
Frame material: Thick High-Strength Steel
frame rail height: 500mm
Web Plate: 5mm
upper wing panel: 8mm
Lower Wing Plate: 10mm
Cargo box floor thickness: 2mm
Side beam: 140
Lifting device: 6+1
Cargo box parameters
Cargo box length: 12.82m
Cargo box width: 2.45m
Cargo box height: 0.6m
Other notes
Lead time for customization: 20 days
warranty period: 12 months
warranty method: Three guarantees policy
Tire
Tire brand: Goodyear
Tire Size: 12R22.5
Number of tires: 12pcs

Photos

Exterior2

2 photos

FAQ

What transport jobs is Lieniu 13m Dump Trailer suited for?

Lieniu 13m Dump Trailer is a dump semi-trailer model often used on construction, mining and aggregate jobs. Check drive, horsepower and emission; state duty cycle and destination in your quote.

How does Lieniu 13m Dump Trailer differ from other variants in the same series?

Lieniu 13m Dump Trailer belongs to Lienew 13m Series (dump semi-trailer). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Lieniu 13m Dump Trailer?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Lieniu 13m Dump Trailer?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
