Jinbei Lingqi 107hp 4X2(6 wheels) 3.055m Dump Truck

Export reference
MSRP N/A
Emission: China V
Fuel: Diesel
Curb Weight:: 2.72ton
Wheelbase:: 3350mm
Tire Size:: 7.00R16
Model code (announced):: SY3045SZCS
Rated payload: 1.45ton
Drive 4X2 (6 wheels)
Horsepower 100
Cargo box type: Dump type

Overview

The Shenyang Jinbei Jinbei Lingqi 107hp 4X2(6 wheels) 3.055m Dump Truck is a Light Truck featuring 1.45t payload, 4.495t GVW, Dump type cargo body and 4X2 (6 wheels) drive. On the powertrain side, it comes with a DachaiCA4DC3-10E5 engine, 100 hp, China V emissions and 5-speed transmission transmission.

China V 100 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): SY3045SZCS
Drive type: 4X2
Wheelbase: 3350mm
engine: DachaiCA4DC3-10E5
transmission: 5-speed transmission
Cab length: 5.76m
Cab width: 2m
Cab height: 2.3m
Front track width: 1486mm
rear track: 1480mm
Curb Weight: 2.72ton
Rated payload: 1.45ton
GVWR: 4.495ton
Origin: Shenyang, Liaoning
tonnage class: Light Truck
Approach angle: 22°
departure angle: 20°
Energy Type: Diesel
Engine parameters
Engine Brand: Dachai
Engine Model: DachaiCA4DC3-10E5
Number of cylinders: 4cylinder
fuel type: Diesel
Displacement: 3L
Emission standard: China V
Max output power: 76kW
Max hp: 100Horsepower
Max torque: 275N·m
Max torque speed: 1600-2200rpm
Rated speed: 3200rpm
Engine Type: SCR
Transmission Parameters
Transmission Model: 5-speed transmission
Forward gears: 5Gear
Number of Reverse Gears:
Cargo box parameters
Unloading Type: Dump type
Cargo box type: Dump type
Cargo box length: 3.055m
Cargo box width: 1.9m
Cargo box height: 0.45m
Cab parameters
Cab width: 1690mm
Chassis Specs
Front axle allowable load: 1645kg
rear axle description: 2-ton air brake
rear axle allowable load: 2850kg
Leaf spring count: 8/9+3
Tire
Tire Size: 7.00R16
Number of tires: 6pcs
Control configuration
ABS:
Service brake
Parking brake: Spring brake

Photos

Exterior1

1 photos
