Sanhuan Shitong Chuangke 248hp 6X4(10 wheels) 4.7m dump truck

Export reference
From $39,028
MSRP ¥28.1M CNY
Emission: China VI
Fuel: Diesel
Transmission: Fast Gear
Curb Weight:: 9.85ton
Wheelbase:: 2600+1200mm
Tire Size:: 11.00R20 18PR
Rated payload: 15.02ton
Drive 6X4 (10 wheels)
Horsepower 248
Cargo box type: Dump type

Overview

The Sanhuan Shitong Chuangke 248hp 6X4(10 wheels) 4.7m dump truck is a Medium-duty truck featuring 15.02t payload, 25t GVW, Dump type cargo body and 6X4 (10 wheels) drive. On the powertrain side, it comes with a YuchaiYCK05248-66 engine, 248 hp, China VI emissions and Fast Gear transmission.

China VI 248 Diesel 6X4

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): STQ3257L04Y3S6
Drive type: 6X4
Wheelbase: 2600+1200mm
engine: YuchaiYCK05248-66
transmission: Fast Gear10JS90A-B
Rear Axle Ratio: 6.73
Cab length: 7.13m
Cab width: 2.5m
Cab height: 3m
Front track width: 1720mm
rear track: 1785/1880mm
Curb Weight: 9.85ton
Rated payload: 15.02ton
GVWR: 25ton
Origin: 19
tonnage class: Medium-duty truck
departure angle: 30°
Energy Type: Diesel
Engine parameters
Engine Brand: Yuchai
Engine Model: YuchaiYCK05248-66
Number of cylinders: 4cylinder
fuel type: Diesel
Displacement: 5.132L
Emission standard: China VI
Max output power: 182kW
Max hp: 248Horsepower
Transmission Parameters
Transmission Model: Fast Gear10JS90A-B
Transmission Brand: Fast Gear
Forward gears: 10Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Unloading Type: Dump type
Cargo box type: Dump type
Cargo box length: 4.7m
Cargo box width: 2.3m
Cargo box height: 1.3m
Cab parameters
Cab: T3
seating capacity: 3Personnel
fuel tank
Fuel tank material: aluminum alloy
Fuel tank capacity: 200L
Chassis Specs
Front axle description: 6.5T wheel reduction single front
Front axle allowable load: 7000/6500kg
Frame Dimensions: 290 (8+6) external high-strength platemm
rear axle description: Lifting airbag axle +Mercedes-Benz shortened
rear axle allowable load: 11500kg
Axle ratio: 6.73
Leaf spring count: 4+4/7+-/10+8
Tire
Tire Size: 11.00R20 18PR
Number of tires: 8pcs
Control configuration
ABS:
interior configuration
Multifunction steering wheel:
Power Windows:
Electronic Central Lock:

Photos

0 photos

FAQ

What is the export price of Sanhuan Shitong Chuangke 248hp 6X4(10 wheels) 4.7m dump truck, and what does it include?

Sanhuan Shitong Chuangke 248hp 6X4(10 wheels) 4.7m dump truck export reference is about From $39,028; MSRP is ¥28.1M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does Sanhuan Shitong Chuangke 248hp 6X4(10 wheels) 4.7m dump truck use, and can it enter my country?

This model is listed as China VI. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Sanhuan Shitong Chuangke 248hp 6X4(10 wheels) 4.7m dump truck?

Key specs of Sanhuan Shitong Chuangke 248hp 6X4(10 wheels) 4.7m dump truck: Drive: 6x4; Horsepower: 248 hp; Emission: China VI; Fuel: Diesel; Transmission: Fast Gear. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Sanhuan Shitong Chuangke 248hp 6X4(10 wheels) 4.7m dump truck suited for?

Sanhuan Shitong Chuangke 248hp 6X4(10 wheels) 4.7m dump truck is a Dump Trucks model often used on construction, mining and aggregate jobs. Check drive, horsepower and emission; state duty cycle and destination in your quote.

How does Sanhuan Shitong Chuangke 248hp 6X4(10 wheels) 4.7m dump truck differ from other variants in the same series?

Sanhuan Shitong Chuangke 248hp 6X4(10 wheels) 4.7m dump truck belongs to Sanhuan Shitong Chuanke Light Truck (Dump Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Sanhuan Shitong Chuangke 248hp 6X4(10 wheels) 4.7m dump truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Sanhuan Shitong Chuangke 248hp 6X4(10 wheels) 4.7m dump truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
