Foton M Card 2.5L Diesel 146hp 4X2(6 wheels) WLY 5-Speed 3.19m Double Row Stake Truck Mini Truck

Export reference
From $13,750
MSRP ¥9.9M CNY
Horsepower: 146
Emission: China VI
Fuel: Diesel
Engine: Yunnei Power2.5L
Transmission: WLY
Curb Weight:: 2.72ton
seating capacity: 5Personnel
Rated payload: 1.45ton
Drive 4X2 (6 wheels)
Cargo box type: Stake type

Overview

The Foton M Card 2.5L Diesel 146hp 4X2(6 wheels) WLY 5-Speed 3.19m Double Row Stake Truck Mini Truck is a mini truck featuring 3.19m cargo length, Stake type cargo body, 5Personnel volume and 1.45t payload. On the powertrain side, it comes with a Yunnei Power2.5L engine, 146 hp, 4X2 (6 wheels) drive and China VI emissions.

China VI 146 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): BJ5044CCY9ABA-AB4
Type: stake truck
Drive type: 4X2
Wheelbase: 3360mm
Box length class: 3.2m
engine: Yunnei PowerYN25AL
transmission: WLYWLY5G32
Rear Axle Ratio: 4.33
Cab length: 5.995m
Cab width: 2.05m
Cab height: 2.985m
Front track width: 1515mm
rear track: 1475mm
Curb Weight: 2.72ton
Rated payload: 1.45ton
GVWR: 4.495ton
Max. speed: 100km/h
Origin: Shandong Zhucheng
tonnage class: mini truck
Approach angle: 18°
departure angle: 17°
Remarks: Optional 4.33 ratio.
Front/rear suspension: 1.115/1.52m
Energy Type: Diesel
Engine parameters
Engine Brand: Yunnei Power
Engine Model: YN25AL
Engine info: Yunnei Power2.5L
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 2.499L
Emission standard: China VI
Max output power: 107kW
Max hp: 146Horsepower
Transmission Parameters
Transmission Model: WLYWLY5G32
Transmission Brand: WLY
shift method: Manual
Forward gears: 5Gear
Number of Reverse Gears:
Cargo box parameters
Cargo box type: Stake type
Cargo box length: 3.19m
Cargo box width: 1.95m
*Cargo box interior width: 1.95
Cab parameters
Cab width: 1730mm
seating capacity: 5Personnel
Seat rows: Double cab
fuel tank
Fuel tank capacity: 70L
Chassis Specs
Front axle description: 1.5t
Front axle allowable load: 1800kg
Frame Dimensions: 714/760-140×50×4mm
rear axle description: 4.5t
rear axle allowable load: 2695kg
Axle ratio: 4.33
Leaf spring count: 3/3+2
Aluminum wheels:
Tire
Tire Size: 6.50R16LT 10PR
Number of tires: 6pcs
Control configuration
ABS:
Power steering:
interior configuration
Multifunction steering wheel:
AC control type: Manual
Power Windows:
Electric Heated Rearview Mirror:
Reverse Radar:
Seat material: Fabric
Reverse Camera:
Remote key:
Electronic Central Lock:
Exterior features
Air deflector:
Multimedia features
Center Console Color Screen:
Bluetooth / hands-free calling:
lighting configuration
Front fog lamp:
daytime running lights:
Service brake
Brake Type: Hydraulic brake
Parking brake: parking brake
Front wheel brake: Disc
Rear Wheel Brake: Drum Type
smart configuration
Telematics System:
Cruise control (CCS):

Photos

0 photos

FAQ

What is the export price of Foton M Card 2.5L Diesel 146hp 4X2(6 wheels) WLY 5-Speed 3.19m Double Row Stake Truck Mini Truck, and what does it include?

Foton M Card 2.5L Diesel 146hp 4X2(6 wheels) WLY 5-Speed 3.19m Double Row Stake Truck Mini Truck export reference is about From $13,750; MSRP is ¥9.9M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does Foton M Card 2.5L Diesel 146hp 4X2(6 wheels) WLY 5-Speed 3.19m Double Row Stake Truck Mini Truck use, and can it enter my country?

This model is listed as China VI. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Foton M Card 2.5L Diesel 146hp 4X2(6 wheels) WLY 5-Speed 3.19m Double Row Stake Truck Mini Truck?

Key specs of Foton M Card 2.5L Diesel 146hp 4X2(6 wheels) WLY 5-Speed 3.19m Double Row Stake Truck Mini Truck: Drive: 4x2; Horsepower: 146 hp; Emission: China VI; Fuel: Diesel; Engine: Yunnei Power2.5L; Transmission: WLY. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Foton M Card 2.5L Diesel 146hp 4X2(6 wheels) WLY 5-Speed 3.19m Double Row Stake Truck Mini Truck suited for?

Foton M Card 2.5L Diesel 146hp 4X2(6 wheels) WLY 5-Speed 3.19m Double Row Stake Truck Mini Truck is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does Foton M Card 2.5L Diesel 146hp 4X2(6 wheels) WLY 5-Speed 3.19m Double Row Stake Truck Mini Truck differ from other variants in the same series?

Foton M Card 2.5L Diesel 146hp 4X2(6 wheels) WLY 5-Speed 3.19m Double Row Stake Truck Mini Truck belongs to Foton M Card Mini Truck (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Foton M Card 2.5L Diesel 146hp 4X2(6 wheels) WLY 5-Speed 3.19m Double Row Stake Truck Mini Truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Foton M Card 2.5L Diesel 146hp 4X2(6 wheels) WLY 5-Speed 3.19m Double Row Stake Truck Mini Truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
