SHACMAN Commercial Vehicle Xuande Yi 6 Composite Edition 260 hp 6X2(8 wheels) 9.6m Stake Cargo Truck (China VI)

Export reference
From $37,667
MSRP ¥27.12M CNY
Horsepower: 260
Emission: China VI
Fuel: Diesel
Engine: Dongkang 6.2L
Transmission: Fast Gear
Curb Weight:: 9.5ton
seating capacity: 3Personnel
Rated payload: 15.305ton
Drive 6X2 (8 wheels)
Cargo box type: Stake type

Overview

The SHACMAN Commercial Vehicle Xuande Yi 6 Composite Edition 260 hp 6X2(8 wheels) 9.6m Stake Cargo Truck (China VI) is a Medium-duty truck featuring 9.6m cargo length, Stake type cargo body, 3Personnel volume and 15.305t payload. Its segment focus covers Building material transport, matching those duty cycles. On the powertrain side, it comes with a Dongkang 6.2L engine, 260 hp, 6X2 (8 wheels) drive and China VI emissions.

China VI 260 Diesel 6X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): SX5251CCYGP6559
Type: stake truck
Drive type: 6X2
Wheelbase: 1800+5500mm
Box length class: 9.6m
engine: DongfengB6.2NS6B260
transmission: Fast Gear8JS105TA
Rear Axle Ratio: 4.875
Cab length: 12m
Cab width: 2.55m
Cab height: 3.995m
Front track width: 1934/1934mm
rear track: 1860mm
Curb Weight: 9.5ton
Rated payload: 15.305ton
GVWR: 25ton
Max. speed: 89km/h
Origin: Baoji, Shaanxi
tonnage class: Medium-duty truck
Approach angle: 23°
departure angle: 11°
market segment: Building material transport
Remarks: Standard: Cab: 7-inch color LCD combo instrument cluster, Bluetooth radio (with 5-inch screen), central door lock (1 central key + 2 mechanical keys), Tianxingjian Zhiya BD telematics terminal, integrated rearview mirrors, non-illuminated emblem, sun visor). Chassis: steel air reservoir, 120Ah maintenance-free battery, four-lock integration, front guard included, spare tire included; Optional: 8JS105A transmission, 8JS105TA/ shift-assist transmission, Cab: Yi6 high-roof double bunk/2220, LED headlights, illuminated emblem, ring curtain + bunk curtain, ventilated/heated driver seat, 360° surround view (includes reverse camera, 10.1-inch multimedia screen), electric tilt, 1200W inverter. Chassis: aluminum air reservoir, 400L steel fuel tank, 600L aluminum fuel tank
Front/rear suspension: 1.45/3.25m
Version: composite version
Energy Type: Diesel
Engine parameters
Engine Brand: Dongfeng
Engine Model: DongfengB6.2NS6B260
Engine info: Dongkang 6.2L
Number of cylinders: 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 6.2L
Emission standard: China VI
Max output power: 191kW
Max hp: 260Horsepower
Max torque: 1020N·m
Max torque speed: 1300-1700rpm
Rated speed: 2300rpm
Transmission Parameters
Transmission Model: Fast Gear8JS105TA
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 8Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Cargo box type: Stake type
Cargo box length: 9.6m
Cargo box width: 2.45m
*Cargo box interior width: 2.4500000476837
Cab parameters
Cab: Semi-high roof
Cab width: 2220mm
Cab suspension: 4-point mechanical suspension
Cab tilting: Manual
seating capacity: 3Personnel
Seat rows: Sleeper cab
Driver seat type: air suspension seat
fuel tank
Fuel tank material: aluminum alloy
Fuel tank capacity: 400L
Chassis Specs
Front axle description: 5T+5T
Front axle allowable load: 7000/7000kg
Frame Dimensions: 280/8+6mm
rear axle description: 13T single reduction
rear axle allowable load: 11000kg
Axle ratio: 4.875
Leaf spring count: 10/10/10+8
Aluminum wheels:
Maintenance-free wheel end:
Tire
Tire Size: 11.00R20 18PR
Number of tires: 8pcs
Control configuration
ABS:
Stability control system:
Power steering:
EBS electronic braking system:
clutch booster:
automatic slack adjuster:
interior configuration
Steering Wheel Material: Plastic
steering wheel adjustment: Manual
Multifunction steering wheel:
AC control type: Manual
Power Windows:
Power Mirrors:
Electric Heated Rearview Mirror:
Power interface:
Reverse Radar:
Seat material: leather
Reverse Camera:
Remote key:
Electronic Central Lock:
Exterior features
Air deflector:
Aluminum air tank:
Wiper type: Frameless wiper
Service brake
Engine brake:
Brake Type: Air brake
Parking brake: Spring brake
Exhaust brake:
Front wheel brake: Drum Type
Rear Wheel Brake: Drum Type
Multimedia features
Center Console Color Screen:
External audio input (AUX/USB/iPod etc.):
Bluetooth / hands-free calling:
Radio:
LCD instrument cluster:
lighting configuration
Front fog lamp:
daytime running lights:
Headlight height adjustment:
Halogen Headlights:
smart configuration
Telematics System:
Cruise control (CCS):
Tire Pressure Monitoring System (TPMS):
Fatigue driving monitoring:

Photos

0 photos

FAQ

What is the export price of SHACMAN Commercial Vehicle Xuande Yi 6 Composite Edition 260 hp 6X2(8 wheels) 9.6m Stake Cargo Truck (China VI), and what does it include?

SHACMAN Commercial Vehicle Xuande Yi 6 Composite Edition 260 hp 6X2(8 wheels) 9.6m Stake Cargo Truck (China VI) export reference is about From $37,667; MSRP is ¥27.12M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does SHACMAN Commercial Vehicle Xuande Yi 6 Composite Edition 260 hp 6X2(8 wheels) 9.6m Stake Cargo Truck (China VI) use, and can it enter my country?

This model is listed as China VI. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of SHACMAN Commercial Vehicle Xuande Yi 6 Composite Edition 260 hp 6X2(8 wheels) 9.6m Stake Cargo Truck (China VI)?

Key specs of SHACMAN Commercial Vehicle Xuande Yi 6 Composite Edition 260 hp 6X2(8 wheels) 9.6m Stake Cargo Truck (China VI): Drive: 6x2; Horsepower: 260 hp; Emission: China VI; Fuel: Diesel; Engine: Dongkang 6.2L; Transmission: Fast Gear. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is SHACMAN Commercial Vehicle Xuande Yi 6 Composite Edition 260 hp 6X2(8 wheels) 9.6m Stake Cargo Truck (China VI) suited for?

SHACMAN Commercial Vehicle Xuande Yi 6 Composite Edition 260 hp 6X2(8 wheels) 9.6m Stake Cargo Truck (China VI) is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does SHACMAN Commercial Vehicle Xuande Yi 6 Composite Edition 260 hp 6X2(8 wheels) 9.6m Stake Cargo Truck (China VI) differ from other variants in the same series?

SHACMAN Commercial Vehicle Xuande Yi 6 Composite Edition 260 hp 6X2(8 wheels) 9.6m Stake Cargo Truck (China VI) belongs to SHACMAN Commercial Vehicle Xuande Yi 6 (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for SHACMAN Commercial Vehicle Xuande Yi 6 Composite Edition 260 hp 6X2(8 wheels) 9.6m Stake Cargo Truck (China VI)?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export SHACMAN Commercial Vehicle Xuande Yi 6 Composite Edition 260 hp 6X2(8 wheels) 9.6m Stake Cargo Truck (China VI)?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
