JAC Visteon W530 190 hp 4X2(6 wheels) 6.75m half-row stake truck

Export reference
MSRP N/A
Horsepower: 190
Emission: China V
Fuel: Diesel
Engine: MaxxForce 4-cylinder
Transmission: Fast Gear
Curb Weight:: 6.205ton
seating capacity: 3Personnel
Rated payload: 7.995ton
Drive 4X2 (6 wheels)
Cargo box type: Stake type

Overview

The JAC Visteon W530 190 hp 4X2(6 wheels) 6.75m half-row stake truck is a Medium-duty truck featuring 6.75m cargo length, Stake type cargo body, 3Personnel volume and 7.995t payload. Its segment focus covers Agricultural product transport, green channel and industrial product transport, matching those duty cycles. On the powertrain side, it comes with a MaxxForce 4-cylinder engine, 190 hp, 4X2 (6 wheels) drive and China V emissions.

China V 190 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): HFC5142CCYP70K1E1V
Type: stake truck
Drive type: 4X2
Wheelbase: 5300mm
Box length class: 6.8m
engine: MaxxForce JND412D190-52
transmission: Fast Gear8JS75C
Rear Axle Ratio: 4.875
Cab length: 8.995m
Cab width: 2.5m
Cab height: 3.9m
Front track width: 1830mm
rear track: 1800mm
Curb Weight: 6.205ton
Rated payload: 7.995ton
GVWR: 14.395ton
Max. speed: 98km/h
Origin: Hefei, Anhui
tonnage class: Medium-duty truck
Approach angle: 21.4°
departure angle: 13.8°
market segment: Agricultural product transport, green channel, industrial product transport
Front/rear suspension: 1.29/2.705m
Energy Type: Diesel
Engine parameters
Engine Brand: JAC
Engine Model: MaxxForce JND412D190-52
Engine info: MaxxForce 4-cylinder
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 4.748L
Emission standard: China V
Max output power: 140kW
Max hp: 190Horsepower
Max torque: 740N·m
Max torque speed: 1200-1800rpm
Rated speed: 2200rpm
Engine Type: Inline, water-cooled, 4-cylinder, air-to-air intercooled
Transmission Parameters
Transmission Model: Fast Gear8JS75C
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 8Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Cargo box type: Stake type
Cargo box length: 6.75m
Cargo box width: 2.4m
Cargo box height: 2.6m
*Cargo box interior width: 2.4000000953674
Cab parameters
seating capacity: 3Personnel
Seat rows: Sleeper cab
Chassis Specs
Front axle allowable load: 5180kg
rear axle allowable load: 9215kg
Axle ratio: 4.875
Leaf spring count: 10/9+7
Tire
Tire Size: 9.00R20 16PR,10R22.5 16PR
Number of tires: 6pcs
Control configuration
ABS:

Photos

0 photos

FAQ

What emission standard does JAC Visteon W530 190 hp 4X2(6 wheels) 6.75m half-row stake truck use, and can it enter my country?

This model is listed as China V. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of JAC Visteon W530 190 hp 4X2(6 wheels) 6.75m half-row stake truck?

Key specs of JAC Visteon W530 190 hp 4X2(6 wheels) 6.75m half-row stake truck: Drive: 4x2; Horsepower: 190 hp; Emission: China V; Fuel: Diesel; Engine: MaxxForce 4-cylinder; Transmission: Fast Gear. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is JAC Visteon W530 190 hp 4X2(6 wheels) 6.75m half-row stake truck suited for?

JAC Visteon W530 190 hp 4X2(6 wheels) 6.75m half-row stake truck is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does JAC Visteon W530 190 hp 4X2(6 wheels) 6.75m half-row stake truck differ from other variants in the same series?

JAC Visteon W530 190 hp 4X2(6 wheels) 6.75m half-row stake truck belongs to JAC Q9 medium truck (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for JAC Visteon W530 190 hp 4X2(6 wheels) 6.75m half-row stake truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export JAC Visteon W530 190 hp 4X2(6 wheels) 6.75m half-row stake truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
