Foton Aumark S1 Series Smart Edition 131hp 4X2(6 wheels) 3.83m half-row flatbed light truck

Export reference
From $14,861
MSRP ¥10.7M CNY
Horsepower: 131
Emission: China V
Fuel: Diesel
Engine: Fukang 2.8
Transmission: ZF
Curb Weight:: 2.565ton
seating capacity: 3Personnel
Rated payload: 1.735ton
Drive 4X2 (6 wheels)
Cargo box type: stake body

Overview

The Foton Aumark S1 Series Smart Edition 131hp 4X2(6 wheels) 3.83m half-row flatbed light truck is a Light Truck featuring 3.83m cargo length, stake body cargo body, 3Personnel volume and 1.735t payload. Its segment focus covers Building materials and agricultural products, matching those duty cycles. On the powertrain side, it comes with a Fukang 2.8 engine, 131 hp, 4X2 (6 wheels) drive and China V emissions.

China V 131 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): BJ1045V9JD6-F2
Type: Cargo Trucks
Drive type: 4X2
Wheelbase: 3360mm
Box length class: 3.8m
engine: FotonISF2.8s5129T
transmission: ZFZF5S328
Rear Axle Ratio: 4.875
Cab length: 5.995m
Cab width: 2.2m
Cab height: 2.33m
Front track width: 1590mm
rear track: 1485mm
Curb Weight: 2.565ton
Rated payload: 1.735ton
GVWR: 4.495ton
Max. speed: 105km/h
Origin: Beijing
tonnage class: Light Truck
Approach angle: 19°
departure angle: 16°
market segment: Building materials, agricultural products
Remarks: No airbag, no PTO, manual tilt, no cargo box, no side guard, manual windows and mirrors, MP3
Front/rear suspension: 1.11/1.525m
Version: Zhiying Edition
Energy Type: Diesel
Engine parameters
Engine Brand: Foton
Engine Model: FotonISF2.8s5129T
Engine info: Fukang 2.8
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 2.78L
Emission standard: China V
Max output power: 96kW
Max hp: 131Horsepower
Max torque: 300N·m
Max torque speed: 1500-2900rpm
Rated speed: 2900rpm
Engine Type: Turbocharged intercooled, Bosch high-pressure common rail, high-pressure direct injection, SCR
Transmission Parameters
Transmission Model: ZFZF5S328
Transmission Brand: ZF
shift method: Manual
Forward gears: 5Gear
Number of Reverse Gears:
Cargo box parameters
Cargo box type: stake body
Cargo box length: 3.83m
Cargo box width: 1.96m
Cargo box height: 0.4m
*Cargo box interior width: 1.960000038147
Cab parameters
Cab width: 1880mm
seating capacity: 3Personnel
Seat rows: Sleeper cab
fuel tank
Fuel tank material: Plastic
Fuel tank capacity: 80L
Chassis Specs
Front axle description: 2.4T
Front axle allowable load: 1850kg
Frame Dimensions: 110/180/140×65×4.5mm
rear axle description: 4.5T
rear axle allowable load: 2645kg
Axle ratio: 4.875
Leaf spring count: 3/5+2
Tire
Tire Size: 7.00R16 8PR
Number of tires: 6pcs
Control configuration
ABS:
Power steering:
interior configuration
AC control type: Manual
Power Windows:
Electronic Central Lock:
lighting configuration
Front fog lamp:
Service brake
Brake Type: Air brake
Front wheel brake: Drum Type
Rear Wheel Brake: Drum Type
smart configuration
Cruise control (CCS):
