Dongfeng T3 220 hp 6X2(8 wheels) 6.8m dump truck (China VI)

Export reference
From $28,194
MSRP ¥20.3M CNY
Emission: China VI
Fuel: Diesel
Transmission: Fast Gear
Curb Weight:: 8.1ton
Wheelbase:: 1750+3950mm
Tire Size:: 10.00R20 18PR
Rated payload: 16.27ton
Drive 6X2 (8 wheels)
Horsepower 220
Cargo box type: Rear-dump body

Overview

The Dongfeng T3 220 hp 6X2(8 wheels) 6.8m dump truck (China VI) is a Heavy truck featuring 16.27t payload, 24.5t GVW, Rear-dump body cargo body and 6X2 (8 wheels) drive. On the powertrain side, it comes with a Yunnei PowerD45TCIF1 engine, 220 hp, China VI emissions and Fast Gear transmission.

China VI 220 Diesel 6X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): EQ3246GL6D21
Drive type: 6X2
Wheelbase: 1750+3950mm
engine: Yunnei PowerD45TCIF1
transmission: Fast Gear10JS90A-B
Rear Axle Ratio: 5.286
Cab length: 9.5m
Cab width: 2.5m
Cab height: 2.8m
Front track width: 1810/1810mm
rear track: 1860mm
Curb Weight: 8.1ton
Rated payload: 16.27ton
GVWR: 24.5ton
Origin: Shiyan, Hubei
tonnage class: Heavy truck
Approach angle: 21°
departure angle: 14°
Remarks: Standard: full digital instrument cluster, multi-lock integration, PTO, steel air tanks, standard air filter; Optional: front single-cylinder lift
Energy Type: Diesel
Engine parameters
Engine Brand: Yunnei Power
Engine Model: Yunnei PowerD45TCIF1
Number of cylinders: 4cylinder
fuel type: Diesel
Displacement: 4.461L
Emission standard: China VI
Max output power: 162kW
Max hp: 220Horsepower
Max torque: 810N·m
Max torque speed: 1200-1800rpm
Rated speed: 2300rpm
Transmission Parameters
Transmission Model: Fast Gear10JS90A-B
Transmission Brand: Fast Gear
Forward gears: 10Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Unloading Type: Rear-dump body
Cargo box type: Rear-dump body
Cargo box length: 6.8m
Cargo box width: 2.2m
Cargo box height: 0.6m
Cab parameters
Cab: T710 Standard Roof
Cab width: 2080mm
Driver seat type: air suspension seat
fuel tank
Fuel tank material: aluminum alloy
Chassis Specs
Front axle description: 3.6T*2
Front axle allowable load: 6500/6500kg
Frame Dimensions: 250(8+4)mm
rear axle description: 13T shortened
rear axle allowable load: 11500kg
Axle ratio: 5.286
Leaf spring count: 9/9/10+8
clutch: Φ395
Tire
Tire Size: 10.00R20 18PR
Number of tires: 8pcs
Control configuration
ABS:
interior configuration
Multifunction steering wheel:
AC control type: Manual
Reverse Camera:
Electronic Central Lock:

Photos

0 photos

FAQ

What is the export price of Dongfeng T3 220 hp 6X2(8 wheels) 6.8m dump truck (China VI), and what does it include?

Dongfeng T3 220 hp 6X2(8 wheels) 6.8m dump truck (China VI) export reference is about From $28,194; MSRP is ¥20.3M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does Dongfeng T3 220 hp 6X2(8 wheels) 6.8m dump truck (China VI) use, and can it enter my country?

This model is listed as China VI. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Dongfeng T3 220 hp 6X2(8 wheels) 6.8m dump truck (China VI)?

Key specs of Dongfeng T3 220 hp 6X2(8 wheels) 6.8m dump truck (China VI): Drive: 6x2; Horsepower: 220 hp; Emission: China VI; Fuel: Diesel; Transmission: Fast Gear. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Dongfeng T3 220 hp 6X2(8 wheels) 6.8m dump truck (China VI) suited for?

Dongfeng T3 220 hp 6X2(8 wheels) 6.8m dump truck (China VI) is a Dump Trucks model often used on construction, mining and aggregate jobs. Check drive, horsepower and emission; state duty cycle and destination in your quote.

How does Dongfeng T3 220 hp 6X2(8 wheels) 6.8m dump truck (China VI) differ from other variants in the same series?

Dongfeng T3 220 hp 6X2(8 wheels) 6.8m dump truck (China VI) belongs to Dongfeng T3 medium truck (Dump Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Dongfeng T3 220 hp 6X2(8 wheels) 6.8m dump truck (China VI)?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Dongfeng T3 220 hp 6X2(8 wheels) 6.8m dump truck (China VI)?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
