JAC Haoyun 33 95 hp 4X2(6 wheels) 3.2m Double Row Stake Truck

Export reference
From $9,444
MSRP ¥6.8M CNY
Horsepower: 95
Emission: China IV
Fuel: Diesel
Engine: Quanchai490
Curb Weight:: 2.37ton
Wheelbase:: 3308mm
seating capacity: 6Personnel
Rated payload: 1.4ton
Drive 4X2 (6 wheels)
Cargo box type: Stake type

Overview

The JAC Haoyun 33 95 hp 4X2(6 wheels) 3.2m Double Row Stake Truck is a Light Truck featuring 3.2m cargo length, Stake type cargo body, 6Personnel volume and 1.4t payload. On the powertrain side, it comes with a Quanchai490 engine, 95 hp, 4X2 (6 wheels) drive and China IV emissions.

China IV 95 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): HFC5041CCYR92K3C2
Type: stake truck
Drive type: 4X2
Wheelbase: 3308mm
Box length class: 3.2m
Cab length: 5.995m
Cab width: 2.06m
Cab height: 2.9m
Front track width: 1440mm
rear track: 1395mm
Curb Weight: 2.37ton
Rated payload: 1.4ton
GVWR: 4.16ton
Max. speed: 90km/h
Origin: Hefei, Anhui
tonnage class: Light Truck
Remarks: 1. The correspondence of overall width / cargo box inner length / overall width is: 1)1910/3200/1810, 2)2000/3200/1900, 3)2060/3200/1960; 2. Distance from cargo box floor to top of stake rack is 1850mm; 3. Optional front panel, grille, front bumper, combination lights, front fog lights as per chassis; 4. Optional side guard; 5. Side and rear underrun guard material is Q235, connection by bolts, rear guard section size (L×W): 130mm×30mm, ground clearance 530mm
Energy Type: Diesel
Engine parameters
Engine Brand: Quanchai
Engine Model: Quanchai4B2-95C40
Engine info: Quanchai490
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 2.545L
Emission standard: China IV
Max output power: 70kW
Max hp: 95Horsepower
Max torque: 270N·m
Max torque speed: 2000rpm
Rated speed: 3200rpm
Engine Type: Electronic control EGR
Transmission Parameters
Transmission Model: 5-speed transmission
Forward gears: 5Gear
Number of Reverse Gears:
Cargo box parameters
Cargo box type: Stake type
Cargo box length: 3.2m
Cargo box width: 1.96m
Cargo box height: 0.4m
*Cargo box interior width: 1.960000038147
Cab parameters
seating capacity: 6Personnel
Seat rows: Double cab
fuel tank
Fuel tank capacity: 120L
Chassis Specs
rear axle description: 2660
Leaf spring count: 11/9+7
Tire
Tire Size: 6.50-168PR,6.50R168PR,7.00-166PR,7.00R166PR
Number of tires: 6pcs

Photos

0 photos

FAQ

What is the export price of JAC Haoyun 33 95 hp 4X2(6 wheels) 3.2m Double Row Stake Truck, and what does it include?

JAC Haoyun 33 95 hp 4X2(6 wheels) 3.2m Double Row Stake Truck export reference is about From $9,444; MSRP is ¥6.8M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does JAC Haoyun 33 95 hp 4X2(6 wheels) 3.2m Double Row Stake Truck use, and can it enter my country?

This model is listed as China IV. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of JAC Haoyun 33 95 hp 4X2(6 wheels) 3.2m Double Row Stake Truck?

Key specs of JAC Haoyun 33 95 hp 4X2(6 wheels) 3.2m Double Row Stake Truck: Drive: 4x2; Horsepower: 95 hp; Emission: China IV; Fuel: Diesel; Engine: Quanchai490. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is JAC Haoyun 33 95 hp 4X2(6 wheels) 3.2m Double Row Stake Truck suited for?

JAC Haoyun 33 95 hp 4X2(6 wheels) 3.2m Double Row Stake Truck is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does JAC Haoyun 33 95 hp 4X2(6 wheels) 3.2m Double Row Stake Truck differ from other variants in the same series?

JAC Haoyun 33 95 hp 4X2(6 wheels) 3.2m Double Row Stake Truck belongs to JAC Haoyun light truck (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for JAC Haoyun 33 95 hp 4X2(6 wheels) 3.2m Double Row Stake Truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export JAC Haoyun 33 95 hp 4X2(6 wheels) 3.2m Double Row Stake Truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
