SHACMAN Delong L3000 Classic Edition 240 hp 4X2(6 wheels) 6.8 m stake truck (China VI)

Export reference
From $26,556
MSRP ¥19.12M CNY
Horsepower: 240
Emission: China VI
Fuel: Diesel
Engine: Yuchai 4-cylinder
Transmission: Fast Gear
Curb Weight:: 7.815ton
seating capacity: 3Personnel
Rated payload: 9.99ton
Drive 4X2 (6 wheels)
Cargo box type: Stake type

Overview

The SHACMAN Delong L3000 Classic Edition 240 hp 4X2(6 wheels) 6.8 m stake truck (China VI) is a Heavy-duty cargo trucks featuring 6.8m cargo length, Stake type cargo body, 3Personnel volume and 9.99t payload. Its segment focus covers LTL transport, matching those duty cycles. On the powertrain side, it comes with a Yuchai 4-cylinder engine, 240 hp, 4X2 (6 wheels) drive and China VI emissions.

China VI 240 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): SX5189CCYLA501F2
Type: stake truck
Drive type: 4X2
Wheelbase: 5000mm
Box length class: 6.8m
engine: YuchaiYCK05240-60
transmission: Fast GearS08MO
Rear Axle Ratio: 4.111
Cab length: 8.995m
Cab width: 2.55m
Cab height: 3.96m
Front track width: 1935mm
rear track: 1860mm
Curb Weight: 7.815ton
Rated payload: 9.99ton
GVWR: 18ton
Max. speed: 89km/h
Origin: Xi'an, Shaanxi
tonnage class: Heavy-duty cargo trucks
Approach angle: 16°
departure angle:
market segment: LTL transport
Remarks: Standard: L3000 cab without deflector, front fixed rear hydraulic mounts, Tianxingjian Zhiya version, standard steering wheel, halogen headlights, maintenance-free battery, drum front axle, speed limited to 89km/h; Optional: L3000 cab with deflector, L3000 short high-roof cab without deflector, ventilated/heated air driver seat, disc front axle, third seat, four-point hydraulic mounts, Tianxingjian Zhixing version.
Front/rear suspension: 1.34/2.655m
Version: Classic Edition
Energy Type: Diesel
Engine parameters
Engine Brand: Yuchai
Engine Model: YuchaiYCK05240-60
Engine info: Yuchai 4-cylinder
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 5.13L
Emission standard: China VI
Max output power: 176kW
Max hp: 240Horsepower
Max torque: 900N·m
Max torque speed: 1200-1600rpm
Rated speed: 2200rpm
Engine Type: High-pressure common rail + EGR + DOC + DPF + SCR + ASC
Transmission Parameters
Transmission Model: Fast GearS08MO
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 8Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Cargo box type: Stake type
Cargo box length: 6.8m
Cargo box width: 2.45m
*Cargo box interior width: 2.4500000476837
Cab parameters
seating capacity: 3Personnel
Cab tilting: Manual
Seat rows: Sleeper cab
Driver seat type: air suspension seat
fuel tank
Fuel tank capacity: 400L
Chassis Specs
Front axle allowable load: 6500kg
Frame Dimensions: 870×230 (single 7)mm
rear axle allowable load: 11500kg
Axle ratio: 4.111
Leaf spring count: 3/4+3
Suspension (front/rear): Front and rear multi-leaf springs
Tire
Tire Size: 295/80R22.5 18PR
Number of tires: 6pcs
Control configuration
ABS:
interior configuration
AC control type: Manual
Power Windows:
Electronic Central Lock:

Photos

Exterior3

3 photos

FAQ

What is the export price of SHACMAN Delong L3000 Classic Edition 240 hp 4X2(6 wheels) 6.8 m stake truck (China VI), and what does it include?

SHACMAN Delong L3000 Classic Edition 240 hp 4X2(6 wheels) 6.8 m stake truck (China VI) export reference is about From $26,556; MSRP is ¥19.12M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does SHACMAN Delong L3000 Classic Edition 240 hp 4X2(6 wheels) 6.8 m stake truck (China VI) use, and can it enter my country?

This model is listed as China VI. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of SHACMAN Delong L3000 Classic Edition 240 hp 4X2(6 wheels) 6.8 m stake truck (China VI)?

Key specs of SHACMAN Delong L3000 Classic Edition 240 hp 4X2(6 wheels) 6.8 m stake truck (China VI): Drive: 4x2; Horsepower: 240 hp; Emission: China VI; Fuel: Diesel; Engine: Yuchai 4-cylinder; Transmission: Fast Gear. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is SHACMAN Delong L3000 Classic Edition 240 hp 4X2(6 wheels) 6.8 m stake truck (China VI) suited for?

SHACMAN Delong L3000 Classic Edition 240 hp 4X2(6 wheels) 6.8 m stake truck (China VI) is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does SHACMAN Delong L3000 Classic Edition 240 hp 4X2(6 wheels) 6.8 m stake truck (China VI) differ from other variants in the same series?

SHACMAN Delong L3000 Classic Edition 240 hp 4X2(6 wheels) 6.8 m stake truck (China VI) belongs to SHACMAN Delong L3000 Medium Truck (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for SHACMAN Delong L3000 Classic Edition 240 hp 4X2(6 wheels) 6.8 m stake truck (China VI)?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export SHACMAN Delong L3000 Classic Edition 240 hp 4X2(6 wheels) 6.8 m stake truck (China VI)?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
