Foton Aoling M Card 122hp 4X2(6 wheels) 3.15m double-row van light truck

Export reference
From $13,486
MSRP ¥9.71M CNY
Horsepower: 122
Emission: China VI
Fuel: Diesel
Engine: De Wei D20
Transmission: WLY
Curb Weight:: 2.35ton
seating capacity: 5Personnel
Rated payload: 1.82ton
Drive 4X2 (6 wheels)
Cargo box type: Van body

Overview

The Foton Aoling M Card 122hp 4X2(6 wheels) 3.15m double-row van light truck is a mini truck featuring 3.15m cargo length, Van body cargo body, 5Personnel volume and 1.82t payload. On the powertrain side, it comes with a De Wei D20 engine, 122 hp, 4X2 (6 wheels) drive and China VI emissions.

China VI 122 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): BJ5044XXY9AA6-AB2
Type: enclosed cargo truck
Drive type: 4X2
Wheelbase: 3360mm
Box length class: 3.2m
engine: Yunnei PowerD20TCIF15
transmission: WLYWLY5G32
Rear Axle Ratio: 4.875
Cab length: 5.995m
Cab width: 1.95m
Cab height: 2.69m
Front track width: 1495mm
rear track: 1420mm
Curb Weight: 2.35ton
Rated payload: 1.82ton
GVWR: 4.495ton
Max. speed: 100km/h
Origin: Shandong Zhucheng
tonnage class: mini truck
Approach angle: 15°
departure angle: 13°
Remarks: Optional 4.33 ratio, mechanical-suspension driver seat.
Front/rear suspension: 1.115/1.52m
Energy Type: Diesel
Engine parameters
Engine Brand: Yunnei Power
Engine Model: Yunnei PowerD20TCIF15
Engine info: De Wei D20
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 1.999L
Emission standard: China VI
Max output power: 90kW
Max hp: 122Horsepower
Transmission Parameters
Transmission Model: WLYWLY5G32
Transmission Brand: WLY
shift method: Manual
Forward gears: 5Gear
Number of Reverse Gears:
Cargo box parameters
Cargo box type: Van body
Cargo box length: 3.15m
Cargo box width: 1.85m
Cargo box height: 1.9m
*Cargo box interior width: 1.85
Cab parameters
Cab width: 1730mm
seating capacity: 5Personnel
Seat rows: Double cab
fuel tank
Fuel tank material: Plastic
Fuel tank capacity: 70L
Chassis Specs
Front axle description: 1.5t
Front axle allowable load: 1575kg
Frame Dimensions: 714/760, H140, W50, T4 framemm
rear axle description: 2.85t/220 single reduction drive axle
rear axle allowable load: 2920kg
Axle ratio: 4.875
Leaf spring count: 3/3+2
Aluminum wheels:
Tire
Tire Size: 185R15LT 8PR
Number of tires: 6pcs
Control configuration
ABS:
Power steering:
interior configuration
Multifunction steering wheel:
AC control type: Manual
Power Windows:
Power Mirrors:
Electric Heated Rearview Mirror:
Reverse Radar:
Seat material: Fabric
Reverse Camera:
Remote key:
Electronic Central Lock:
Exterior features
Air deflector:
Multimedia features
Center Console Color Screen:
Bluetooth / hands-free calling:
lighting configuration
Front fog lamp:
Service brake
Brake Type: Hydraulic brake
Parking brake: parking brake
Front wheel brake: Disc
Rear Wheel Brake: Drum Type
smart configuration
Cruise control (CCS):

Photos

0 photos

FAQ

What is the export price of Foton Aoling M Card 122hp 4X2(6 wheels) 3.15m double-row van light truck, and what does it include?

Foton Aoling M Card 122hp 4X2(6 wheels) 3.15m double-row van light truck export reference is about From $13,486; MSRP is ¥9.71M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does Foton Aoling M Card 122hp 4X2(6 wheels) 3.15m double-row van light truck use, and can it enter my country?

This model is listed as China VI. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Foton Aoling M Card 122hp 4X2(6 wheels) 3.15m double-row van light truck?

Key specs of Foton Aoling M Card 122hp 4X2(6 wheels) 3.15m double-row van light truck: Drive: 4x2; Horsepower: 122 hp; Emission: China VI; Fuel: Diesel; Engine: De Wei D20; Transmission: WLY. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Foton Aoling M Card 122hp 4X2(6 wheels) 3.15m double-row van light truck suited for?

Foton Aoling M Card 122hp 4X2(6 wheels) 3.15m double-row van light truck is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does Foton Aoling M Card 122hp 4X2(6 wheels) 3.15m double-row van light truck differ from other variants in the same series?

Foton Aoling M Card 122hp 4X2(6 wheels) 3.15m double-row van light truck belongs to Foton M Card Mini Truck (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Foton Aoling M Card 122hp 4X2(6 wheels) 3.15m double-row van light truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Foton Aoling M Card 122hp 4X2(6 wheels) 3.15m double-row van light truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
