Jinbei Yunying N Series 87 hp 4X2(6 wheels) 4.2m Single Row Cage Van Light Truck (Air Brake)

Export reference
MSRP N/A
Horsepower: 87
Emission: China V
Fuel: Diesel
Engine: Xichai490
Transmission: WLY
Curb Weight:: 2.5ton
seating capacity: 2Personnel
Rated payload: 1.495ton
Drive 4X2 (6 wheels)
Cargo box type: Stake type

Overview

The Shenyang Jinbei Jinbei Yunying N Series 87 hp 4X2(6 wheels) 4.2m Single Row Cage Van Light Truck (Air Brake) is a Light Truck featuring 4.2m cargo length, Stake type cargo body, 2Personnel volume and 1.495t payload. Its segment focus covers Agricultural product transport and green channel, matching those duty cycles. On the powertrain side, it comes with a Xichai490 engine, 87 hp, 4X2 (6 wheels) drive and China V emissions.

China V 87 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): SY5045CCYH-ZE
Type: stake truck
Drive type: 4X2
Wheelbase: 3350mm
Box length class: 4.2m
engine: Xichai4DW93-84E5
transmission: WLYWLY525
Cab length: 5.995m
Cab width: 2m
Cab height: 2.95m
Front track width: 1486mm
rear track: 1480mm
Curb Weight: 2.5ton
Rated payload: 1.495ton
GVWR: 4.125ton
Max. speed: 110km/h
Origin: Shenyang, Liaoning
tonnage class: Light Truck
Approach angle: 21°
departure angle: 20°
market segment: Agricultural product transport, green channel
Front/rear suspension: 1.115/1.53m
Energy Type: Diesel
Engine parameters
Engine Brand: Xichai
Engine Model: Xichai4DW93-84E5
Engine info: Xichai490
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 2.54L
Emission standard: China V
Max output power: 64kW
Max hp: 87Horsepower
Max torque: 220N·m
Max torque speed: 1900-2100rpm
Rated speed: 3000rpm
Engine Type: 4-cylinder inline, direct injection, turbocharged & intercooled, electronic common rail
Transmission Parameters
Transmission Model: WLYWLY525
Transmission Brand: WLY
shift method: Manual
Forward gears: 5Gear
Number of Reverse Gears:
Cargo box parameters
Cargo box type: Stake type
Cargo box length: 4.2m
Cargo box width: 1.9m
Cargo box height: 1.9m
*Cargo box interior width: 1.8999999761581
Cab parameters
Cab width: 1730mm
seating capacity: 2Personnel
Seat rows: Single Row
fuel tank
Fuel tank capacity: 90L
Chassis Specs
Front axle allowable load: 1525kg
rear axle description: 2T air brake axle
rear axle allowable load: 2600kg
Leaf spring count: 8/9+3
Suspension (front/rear): leaf spring suspension
Tire
Tire Size: 6.50-16 10PR,7.00-16 8PR,6.50R16 10PR,7.00R16 8PR
Number of tires: 6pcs
Control configuration
ABS:
Service brake
Brake Type: Air brake
Parking brake: Spring brake

Photos

0 photos

FAQ

What emission standard does Jinbei Yunying N Series 87 hp 4X2(6 wheels) 4.2m Single Row Cage Van Light Truck (Air Brake) use, and can it enter my country?

This model is listed as China V. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Jinbei Yunying N Series 87 hp 4X2(6 wheels) 4.2m Single Row Cage Van Light Truck (Air Brake)?

Key specs of Jinbei Yunying N Series 87 hp 4X2(6 wheels) 4.2m Single Row Cage Van Light Truck (Air Brake): Drive: 4x2; Horsepower: 87 hp; Emission: China V; Fuel: Diesel; Engine: Xichai490; Transmission: WLY. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Jinbei Yunying N Series 87 hp 4X2(6 wheels) 4.2m Single Row Cage Van Light Truck (Air Brake) suited for?

Jinbei Yunying N Series 87 hp 4X2(6 wheels) 4.2m Single Row Cage Van Light Truck (Air Brake) is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does Jinbei Yunying N Series 87 hp 4X2(6 wheels) 4.2m Single Row Cage Van Light Truck (Air Brake) differ from other variants in the same series?

Jinbei Yunying N Series 87 hp 4X2(6 wheels) 4.2m Single Row Cage Van Light Truck (Air Brake) belongs to Jinbei Yunying Light Truck (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Jinbei Yunying N Series 87 hp 4X2(6 wheels) 4.2m Single Row Cage Van Light Truck (Air Brake)?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Jinbei Yunying N Series 87 hp 4X2(6 wheels) 4.2m Single Row Cage Van Light Truck (Air Brake)?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
