JAC Kangling 28 medium body 73 hp 4X2(6 wheels) 3.7m single-row cage light truck

Export reference
From $8,889
MSRP ¥6.4M CNY
Horsepower: 73
Emission: China IV
Fuel: Diesel
Engine: Xichai485
Transmission: Lu'an
Curb Weight:: 2.05ton
seating capacity: 2Personnel
Rated payload: 1.49ton
Drive 4X2 (6 wheels)
Cargo box type: Stake type

Overview

The JAC Kangling 28 medium body 73 hp 4X2(6 wheels) 3.7m single-row cage light truck is a Light Truck featuring 3.7m cargo length, Stake type cargo body, 2Personnel volume and 1.49t payload. Its segment focus covers Agricultural product transport and green channel, matching those duty cycles. On the powertrain side, it comes with a Xichai485 engine, 73 hp, 4X2 (6 wheels) drive and China IV emissions.

China IV 73 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): HFC5040CCYP93K9B4
Type: stake truck
Drive type: 4X2
Wheelbase: 2800mm
Box length class: 3.7m
engine: Xichai4DW83-73E4
transmission: Lu'an LC5T190
Cab length: 5.43m
Cab width: 1.91m
Cab height: 2.8m
Front track width: 1420mm
rear track: 1395mm
Curb Weight: 2.05ton
Rated payload: 1.49ton
GVWR: 3.67ton
Max. speed: 90km/h
Origin: Hefei, Anhui
tonnage class: Light Truck
Approach angle: 18°
departure angle: 14°
market segment: Agricultural product transport, green channel
Front/rear suspension: 1.09/1.54m
Energy Type: Diesel
Engine parameters
Engine Brand: Xichai
Engine Model: Xichai4DW83-73E4
Engine info: Xichai485
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 2.16L
Emission standard: China IV
Max output power: 54kW
Max hp: 73Horsepower
Max torque: 200N·m
Max torque speed: 1900-2100rpm
Rated speed: 2800rpm
Transmission Parameters
Transmission Model: Lu'an LC5T190
Transmission Brand: Lu'an
shift method: Manual
Forward gears: 5Gear
Number of Reverse Gears:
Cargo box parameters
Cargo box type: Stake type
Cargo box length: 3.7m
Cargo box width: 1.81m
Cargo box height: 0.37m
*Cargo box interior width: 1.8099999427795
Cab parameters
seating capacity: 2Personnel
Seat rows: Single Row
Chassis Specs
Front axle allowable load: 1320kg
rear axle allowable load: 2350kg
Leaf spring count: 3/5+3
Tire
Tire Size: 6.50R16
Number of tires: 6pcs
Control configuration
ABS:

Photos

0 photos

FAQ

What is the export price of JAC Kangling 28 medium body 73 hp 4X2(6 wheels) 3.7m single-row cage light truck, and what does it include?

JAC Kangling 28 medium body 73 hp 4X2(6 wheels) 3.7m single-row cage light truck export reference is about From $8,889; MSRP is ¥6.4M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does JAC Kangling 28 medium body 73 hp 4X2(6 wheels) 3.7m single-row cage light truck use, and can it enter my country?

This model is listed as China IV. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of JAC Kangling 28 medium body 73 hp 4X2(6 wheels) 3.7m single-row cage light truck?

Key specs of JAC Kangling 28 medium body 73 hp 4X2(6 wheels) 3.7m single-row cage light truck: Drive: 4x2; Horsepower: 73 hp; Emission: China IV; Fuel: Diesel; Engine: Xichai485; Transmission: Lu'an. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is JAC Kangling 28 medium body 73 hp 4X2(6 wheels) 3.7m single-row cage light truck suited for?

JAC Kangling 28 medium body 73 hp 4X2(6 wheels) 3.7m single-row cage light truck is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does JAC Kangling 28 medium body 73 hp 4X2(6 wheels) 3.7m single-row cage light truck differ from other variants in the same series?

JAC Kangling 28 medium body 73 hp 4X2(6 wheels) 3.7m single-row cage light truck belongs to JAC H1 light truck (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for JAC Kangling 28 medium body 73 hp 4X2(6 wheels) 3.7m single-row cage light truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export JAC Kangling 28 medium body 73 hp 4X2(6 wheels) 3.7m single-row cage light truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
