Union Truck U340 Heavy Truck Standard Load Type 340hp 6X2(8 wheels) LNG Tractor Truck

Export reference
MSRP N/A
Fuel: LNG (liquefied natural gas)
Gross Trailer Weight:: 37.505ton
Wheelbase:: 1950+2650mm
Tire Size:: 12R22.5
rear axle allowable load:: 13000kg
Displacement:: 10.338L
Drive 6X2 (8 wheels)
Horsepower 340
Emission China IV
Transmission Fast Gear

Overview

The Union Truck U340 Heavy Truck Standard Load Type 340hp 6X2(8 wheels) LNG Tractor Truck is a Heavy truck featuring 6X2 (8 wheels) drive, 340 hp, 25t GVW and China IV emissions. On the powertrain side, it comes with a United PowerYC6MK340N-40 engine, Fast Gear transmission and LNG (liquefied natural gas) fuel.

China IV 340 LNG (liquefied natural gas) 6X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): SQR4251N6ZT2
Drive type: 6X2
Wheelbase: 1950+2650mm
engine: United PowerYC6MK340N-40
transmission: Fast Gear9JS135TA
Rear Axle Ratio: 4.11
Cab length: 7.126m
Cab width: 2.5m
Cab height: 3.65m
Front track width: 2025/2025mm
Gross Trailer Weight: 37.505ton
rear track: 1860mm
Curb Weight: 8.3ton
GVWR: 25ton
Max. speed: 102km/h
Origin: Wuhu, Anhui
tonnage class: Heavy truck
Version: LNG Standard Load Edition
Energy Type: LNG (liquefied natural gas)
Engine parameters
Engine Brand: United Power
Engine Model: United PowerYC6MK340N-40
Number of cylinders: 6cylinder
fuel type: LNG (liquefied natural gas)
Cylinder arrangement: Inline
Displacement: 10.338L
Emission standard: China IV
Max output power: 250kW
Max hp: 340Horsepower
Max torque: 1500N·m
Max torque speed: 1100-1500rpm
Rated speed: 2100rpm
Transmission Parameters
Transmission Model: Fast Gear9JS135TA
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 9Gear
Number of Reverse Gears:
Cab parameters
Cab: High roof
seating capacity: 2Personnel
Seat rows: Sleeper cab
Chassis Specs
rear axle description: Front axle: forged I-beam, drum brake 5.5T*2; Rear axle: 457 single-stage stamped-welded axle
rear axle allowable load: 13000kg
Axle ratio: 4.11
Leaf spring count: 3/3/4+3,9/9/10+6,3/3/10+6,3/3/-
Tire
Tire Size: 12R22.5
Number of tires: 8pcs

Photos

Exterior3

Chassis3

6 photos

FAQ

What emission standard does Union Truck U340 Heavy Truck Standard Load Type 340hp 6X2(8 wheels) LNG Tractor Truck use, and can it enter my country?

This model is listed as China IV. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Union Truck U340 Heavy Truck Standard Load Type 340hp 6X2(8 wheels) LNG Tractor Truck?

Key specs of Union Truck U340 Heavy Truck Standard Load Type 340hp 6X2(8 wheels) LNG Tractor Truck: Drive: 6x2; Horsepower: 340 hp; Emission: China IV; Fuel: LNG (liquefied natural gas); Transmission: Fast Gear. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Union Truck U340 Heavy Truck Standard Load Type 340hp 6X2(8 wheels) LNG Tractor Truck suited for?

Union Truck U340 Heavy Truck Standard Load Type 340hp 6X2(8 wheels) LNG Tractor Truck is a Tractor Trucks model, typically used for semi-trailer haulage, long-haul and port shuttle work. Match axle load, route and emission needs; describe route and payload in your quote request.

How does Union Truck U340 Heavy Truck Standard Load Type 340hp 6X2(8 wheels) LNG Tractor Truck differ from other variants in the same series?

Union Truck U340 Heavy Truck Standard Load Type 340hp 6X2(8 wheels) LNG Tractor Truck belongs to Union Truck U-Series Heavy Truck (Tractor Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Union Truck U340 Heavy Truck Standard Load Type 340hp 6X2(8 wheels) LNG Tractor Truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Union Truck U340 Heavy Truck Standard Load Type 340hp 6X2(8 wheels) LNG Tractor Truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
