FAW Jiefang J6L 260hp 4X2(6 wheels) 9.6m LNG wing-opening box-type cargo truck

Export reference
From $39,903
MSRP ¥28.73M CNY
Horsepower: 260
Emission: China VI
Fuel: LNG (liquefied natural gas)
Engine: Xichai7.4L
Transmission: FAW Jiefang
Curb Weight:: 9.37ton
Air tank capacity: 500+500L
Rated payload: 8.5ton
Drive 4X2 (6 wheels)
Cargo box type: Wing Van

Overview

The FAW Jiefang J6L 260hp 4X2(6 wheels) 9.6m LNG wing-opening box-type cargo truck is a Medium-duty truck featuring 9.6m cargo length, Wing Van cargo body, 500+500L volume and 8.5t payload. On the powertrain side, it comes with a Xichai7.4L engine, 260 hp, 4X2 (6 wheels) drive and China VI emissions.

China VI 260 LNG (liquefied natural gas) 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): CA5180XYKP62M2L5E6
Type: enclosed cargo truck
Drive type: 4X2
Wheelbase: 7100mm
Box length class: 9.6m
engine: XichaiCA6SL-26E6N
transmission: FAW JiefangCA8TAX110FS1
Rear Axle Ratio: 4.111
Cab length: 12m
Cab width: 2.55m
Cab height: 4m
Front track width: 1943mm
rear track: 1860mm
Curb Weight: 9.37ton
Rated payload: 8.5ton
GVWR: 18ton
Max. speed: 89km/h
Origin: Changchun, Jilin
tonnage class: Medium-duty truck
Approach angle: 18°
departure angle: 10°
Remarks: Optional ratio 3.9.
Front/rear suspension: 1.4/3.49m
Energy Type: LNG (liquefied natural gas)
Engine parameters
Engine Brand: Xichai
Engine Model: XichaiCA6SL-26E6N
Engine info: Xichai7.4L
Number of cylinders: 6cylinder
fuel type: LNG (liquefied natural gas)
Cylinder arrangement: Inline
Displacement: 7.4L
Emission standard: China VI
Max output power: 190kW
Max hp: 260Horsepower
Max torque: 1000N·m
Max torque speed: 1100-1500rpm
Rated speed: 2100rpm
Transmission Parameters
Transmission Model: FAW JiefangCA8TAX110FS1
Transmission Brand: FAW Jiefang
shift method: Manual
Forward gears: 8Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Cargo box type: Wing Van
Cargo box length: 9.6m
Cargo box width: 2.46m
Cargo box height: 2.88m
*Cargo box interior width: 2.46
fuel tank
Air tank capacity: 500+500L
Cab parameters
Cab: J6L Semi-floating High Roof Extended Cab
Cab width: 2250mm
seating capacity: 2Personnel
Cab tilting: Electric
Seat rows: Sleeper cab
Chassis Specs
Front axle allowable load: 6500kg
Frame Dimensions: 237×75×(7+4)mm
rear axle description: Axle ф378 cast axle
rear axle allowable load: 11500kg
Axle ratio: 4.111
Leaf spring count: 7/7+6
Tire
Tire Size: 275/80R22.5
Number of tires: 6pcs
Control configuration
ABS:
automatic slack adjuster:
interior configuration
Multifunction steering wheel:
Power Windows:
Power Mirrors:
Electric Heated Rearview Mirror:
Seat material: leather
Reverse Camera:
Exterior features
Air deflector:
Multimedia features
Center Console Color Screen:
smart configuration
Cruise control (CCS):

Photos

0 photos

FAQ

What is the export price of FAW Jiefang J6L 260hp 4X2(6 wheels) 9.6m LNG wing-opening box-type cargo truck, and what does it include?

FAW Jiefang J6L 260hp 4X2(6 wheels) 9.6m LNG wing-opening box-type cargo truck export reference is about From $39,903; MSRP is ¥28.73M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does FAW Jiefang J6L 260hp 4X2(6 wheels) 9.6m LNG wing-opening box-type cargo truck use, and can it enter my country?

This model is listed as China VI. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of FAW Jiefang J6L 260hp 4X2(6 wheels) 9.6m LNG wing-opening box-type cargo truck?

Key specs of FAW Jiefang J6L 260hp 4X2(6 wheels) 9.6m LNG wing-opening box-type cargo truck: Drive: 4x2; Horsepower: 260 hp; Emission: China VI; Fuel: LNG (liquefied natural gas); Engine: Xichai7.4L; Transmission: FAW Jiefang. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is FAW Jiefang J6L 260hp 4X2(6 wheels) 9.6m LNG wing-opening box-type cargo truck suited for?

FAW Jiefang J6L 260hp 4X2(6 wheels) 9.6m LNG wing-opening box-type cargo truck is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does FAW Jiefang J6L 260hp 4X2(6 wheels) 9.6m LNG wing-opening box-type cargo truck differ from other variants in the same series?

FAW Jiefang J6L 260hp 4X2(6 wheels) 9.6m LNG wing-opening box-type cargo truck belongs to FAW Jiefang J6L Medium Truck (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for FAW Jiefang J6L 260hp 4X2(6 wheels) 9.6m LNG wing-opening box-type cargo truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export FAW Jiefang J6L 260hp 4X2(6 wheels) 9.6m LNG wing-opening box-type cargo truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
