SAIC Hongyan Genlyon M100 Heavy Truck Heavy Load 310 hp 8X4(12 wheels) Cargo Truck Chassis

Export reference
From $44,806
MSRP ¥32.26M CNY
Horsepower: 310
Emission: China IV
Fuel: Diesel
Engine: SAIC Fiat Powertrain HongyanC9
Transmission: Fast Gear
Curb Weight:: 11.4ton
seating capacity: 3Personnel
Rated payload: 19.47ton
Drive 8X4 (12 wheels)
Cargo box type: Chassis

Overview

The SAIC Hongyan Genlyon M100 Heavy Truck Heavy Load 310 hp 8X4(12 wheels) Cargo Truck Chassis is a Heavy-duty cargo trucks featuring 9.4m cargo length, Chassis cargo body, 3Personnel volume and 19.47t payload. Its segment focus covers Heavy load, matching those duty cycles. On the powertrain side, it comes with a SAIC Fiat Powertrain HongyanC9 engine, 310 hp, 8X4 (12 wheels) drive and China IV emissions.

China IV 310 Diesel 8X4

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): CQ1315HMG466V
Type: Chassis
Drive type: 8X4
Wheelbase: 1800+4625+1350mm
engine: SAIC Fiat Powertrain HongyanC9 310 C4(F2CE3681H*P)
transmission: Fast Gear10JSD140A
Rear Axle Ratio: 4.111
Cab length: 11.99m
Cab width: 2.5m
Cab height: 3.226m
Front track width: 2006/2006mm
rear track: 1850/1850mm
Curb Weight: 11.4ton
Rated payload: 19.47ton
GVWR: 31ton
Max. speed: 95km/h
Origin: Chongqing
tonnage class: Heavy-duty cargo trucks
Approach angle: 19°
departure angle: 12°
market segment: Heavy load
Remarks: ABS, manual A/C, 400L, premium manual mirrors, air seat, manual tilt cab, spare tire carrier, no central locking, no stabilizer bar; optional: body color, axle ratio, tires
Front/rear suspension: 1.435/2.78m
Version: Heavy-duty version
Energy Type: Diesel
Engine parameters
Engine Brand: SAIC Fiat Powertrain Hongyan
Engine Model: SAIC Fiat Powertrain HongyanC9 310 C4(F2CE3681H*P)
Engine info: SAIC Fiat Powertrain HongyanC9
Number of cylinders: 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 8.709L
Emission standard: China IV
Max output power: 228kW
Max hp: 310Horsepower
Max torque: 1350N·m
Max torque speed: 1100-1700rpm
Rated speed: 2100rpm
Engine Type: Electronic high-pressure common rail system
Transmission Parameters
Transmission Model: Fast Gear10JSD140A
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 10Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Cargo box type: Chassis
Cargo box length: 9.4m
Cargo box width: 2.368m
Cargo box height: 0.8m
*Cargo box interior width: 2.3680000305176
Cab parameters
Cab: High roof
seating capacity: 3Personnel
Seat rows: Sleeper cab
fuel tank
Fuel tank material: aluminum alloy
Fuel tank capacity: 400L
Chassis Specs
Front axle allowable load: 6500/6500kg
Frame Dimensions: 940- 865/305 8+4mm
rear axle description: 457 stamped-welded axle
rear axle allowable load: 18000 (twin axle)kg
Axle ratio: 4.111
Leaf spring count: 3/3/4,5/5/6,8/8/12
Tire
Tire Size: 11.00R20
Number of tires: 12pcs
Control configuration
ABS:

Photos

0 photos

FAQ

What is the export price of SAIC Hongyan Genlyon M100 Heavy Truck Heavy Load 310 hp 8X4(12 wheels) Cargo Truck Chassis, and what does it include?

SAIC Hongyan Genlyon M100 Heavy Truck Heavy Load 310 hp 8X4(12 wheels) Cargo Truck Chassis export reference is about From $44,806; MSRP is ¥32.26M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does SAIC Hongyan Genlyon M100 Heavy Truck Heavy Load 310 hp 8X4(12 wheels) Cargo Truck Chassis use, and can it enter my country?

This model is listed as China IV. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of SAIC Hongyan Genlyon M100 Heavy Truck Heavy Load 310 hp 8X4(12 wheels) Cargo Truck Chassis?

Key specs of SAIC Hongyan Genlyon M100 Heavy Truck Heavy Load 310 hp 8X4(12 wheels) Cargo Truck Chassis: Drive: 8x4; Horsepower: 310 hp; Emission: China IV; Fuel: Diesel; Engine: SAIC Fiat Powertrain HongyanC9; Transmission: Fast Gear. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is SAIC Hongyan Genlyon M100 Heavy Truck Heavy Load 310 hp 8X4(12 wheels) Cargo Truck Chassis suited for?

SAIC Hongyan Genlyon M100 Heavy Truck Heavy Load 310 hp 8X4(12 wheels) Cargo Truck Chassis is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does SAIC Hongyan Genlyon M100 Heavy Truck Heavy Load 310 hp 8X4(12 wheels) Cargo Truck Chassis differ from other variants in the same series?

SAIC Hongyan Genlyon M100 Heavy Truck Heavy Load 310 hp 8X4(12 wheels) Cargo Truck Chassis belongs to SAIC Hongyan Genlyon Heavy Truck (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for SAIC Hongyan Genlyon M100 Heavy Truck Heavy Load 310 hp 8X4(12 wheels) Cargo Truck Chassis?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export SAIC Hongyan Genlyon M100 Heavy Truck Heavy Load 310 hp 8X4(12 wheels) Cargo Truck Chassis?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
