Proton Auto Charging Version 8X4(12 wheels) Battery Electric Hook Loader Garbage Truck 350kWh

Export reference
MSRP N/A
Rated payload:: 15.67ton
Wheelbase:: 1800+3400+1400mm
Model code (announced):: SHN5317ZXXMA6BEV
Truck Type:: Battery Electric Hook-Lift Refuse Truck
Cab length:: 9.5m
GVWR:: 31ton
Drive 8X4 (12 wheels)
Battery Brand: CATL
Motor 1 Brand: Zhide
Curb Weight: 15.2ton

Overview

The Proton Auto Charging Version 8X4(12 wheels) Battery Electric Hook Loader Garbage Truck 350kWh is a Electric Garbage Truck featuring CATL battery/range, Zhide motor, 8X4 (12 wheels) drive and 15.67t payload.

8X4

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): SHN5317ZXXMA6BEV
Truck Type: Battery Electric Hook-Lift Refuse Truck
Drive type: 8X4
Wheelbase: 1800+3400+1400mm
Cab length: 9.5m
Cab width: 2.55m
Cab height: 3.33m
Curb Weight: 15.2ton
Rated payload: 15.67ton
GVWR: 31ton
Max. speed: 89km/h
Origin: Huainan, Anhui
Energy Type: Electric
electric motor
Motor 1 Brand: Zhide
Motor 1 Model: TZ400XS023
Motor Type: Permanent magnet synchronous motor
total rated power: 250kW
Peak power: 360kW
total rated torque: 1400N·m
total peak torque: 2500N·m
Battery/Charging
Battery Brand: CATL
Battery type: Lithium Iron Phosphate Battery
fast charge time: 2h
Battery capacity: 350kWh
Chassis Specs
Front axle load: 6500/6500ton
Rear Axle Load: 18000 (tandem axle group)ton
Chassis Series: Dechuang Heavy Truck
Chassis Model: SX1317MF6EV
Leaf spring count: 3/3/5,10/10/10,10/10/12,5/5/5
Body Parameters
Body Brand: Dechuang Future
Transmission Parameters
Number of gears: 6Gear
Transmission Model: 6.0E+240
Tire
Tire Size: 11.00R20 18PR,12.00R20 18PR,12R22.5 18PR
Number of tires: 12pcs

Photos

Exterior1

1 photos

FAQ

What are the key specs of Proton Auto Charging Version 8X4(12 wheels) Battery Electric Hook Loader Garbage Truck 350kWh?

Key specs of Proton Auto Charging Version 8X4(12 wheels) Battery Electric Hook Loader Garbage Truck 350kWh: Drive: 8x4. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Proton Auto Charging Version 8X4(12 wheels) Battery Electric Hook Loader Garbage Truck 350kWh suited for?

Proton Auto Charging Version 8X4(12 wheels) Battery Electric Hook Loader Garbage Truck 350kWh is a Electric Garbage Truck model suited to short-haul or fixed routes with charging access. Confirm local charging and registration rules, then request a quote.

How does Proton Auto Charging Version 8X4(12 wheels) Battery Electric Hook Loader Garbage Truck 350kWh differ from other variants in the same series?

Proton Auto Charging Version 8X4(12 wheels) Battery Electric Hook Loader Garbage Truck 350kWh belongs to Dechuang Battery-Electric Truck (Electric Garbage Truck). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Proton Auto Charging Version 8X4(12 wheels) Battery Electric Hook Loader Garbage Truck 350kWh?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Proton Auto Charging Version 8X4(12 wheels) Battery Electric Hook Loader Garbage Truck 350kWh?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
