FAW Linghe Dongfang Star 141 hp 4X2(6 wheels) 5.2m crew cab flatbed light truck

Export reference
MSRP N/A
Horsepower: 141
Emission: China V
Fuel: Diesel
Engine: Fukang 3.8
Transmission: WLY
Curb Weight:: 3.75ton
FAW Linghe Dongfang Star 141 hp 4X2(6 wheels) 5.2m crew cab flatbed light truck exterior
seating capacity: 3Personnel
Rated payload: 6.045ton
Drive 4X2 (6 wheels)
Cargo box type: stake body

Overview

The FAW Linghe Dongfang Star 141 hp 4X2(6 wheels) 5.2m crew cab flatbed light truck is a Light Truck featuring 5.2m cargo length, stake body cargo body, 3Personnel volume and 6.045t payload. Its segment focus covers Building materials and agricultural products, matching those duty cycles. On the powertrain side, it comes with a Fukang 3.8 engine, 141 hp, 4X2 (6 wheels) drive and China V emissions.

China V 141 Diesel 4X2

Model Specs

Legend: ● Standard　○ Optional　- N/A

Basic Info
Model code (announced): CAL1101DCRE5
Type: Cargo Trucks
Drive type: 4X2
Wheelbase: 3845mm
Box length class: 5.2m
engine: FotonISF3.8s5141
transmission: WLY5-speed
Cab length: 7.065m
Cab width: 2.3m
Cab height: 2.43m
Front track width: 1695mm
rear track: 1610mm
Curb Weight: 3.75ton
Rated payload: 6.045ton
GVWR: 9.99ton
Max. speed: 90km/h
Origin: Lingyuan, Liaoning
tonnage class: Light Truck
Approach angle: 24°
departure angle: 13°
market segment: Building materials, agricultural products
Front/rear suspension: 1.16/2.06m
Energy Type: Diesel
Engine parameters
Engine Brand: Foton
Engine Model: FotonISF3.8s5141
Engine info: Fukang 3.8
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 3.76L
Emission standard: China V
Max output power: 105kW
Max hp: 141Horsepower
Max torque: 440N·m
Max torque speed: 1200-2200rpm
Rated speed: 2600rpm
Engine Type: Turbocharged Air-to-Air Intercooling Bosch High-Pressure Common Rail Direct Injection SCR
Transmission Parameters
Transmission Model: WLY5-speed
Transmission Brand: WLY
shift method: Manual
Forward gears: 5Gear
Number of Reverse Gears:
Cargo box parameters
Cargo box type: stake body
Cargo box length: 5.2m
Cargo box width: 2.11m
Cargo box height: 0.55m
*Cargo box interior width: 2.1099998950958
Cab parameters
Cab: New 700P
seating capacity: 3Personnel
Seat rows: Sleeper cab
Chassis Specs
Front axle allowable load: 3600kg
rear axle description: 6.5T
rear axle allowable load: 6390kg
Leaf spring count: 9/6+6,9/7+7
Tire
Tire Size: 8.25-16 16PR,8.25R16 16PR
Number of tires: 6pcs
Control configuration
ABS:
interior configuration
AC control type: Manual
Electronic Central Lock:

Photos

0 photos

FAQ

What emission standard does FAW Linghe Dongfang Star 141 hp 4X2(6 wheels) 5.2m crew cab flatbed light truck use, and can it enter my country?

This model is listed as China V. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of FAW Linghe Dongfang Star 141 hp 4X2(6 wheels) 5.2m crew cab flatbed light truck?

Key specs of FAW Linghe Dongfang Star 141 hp 4X2(6 wheels) 5.2m crew cab flatbed light truck: Drive: 4x2; Horsepower: 141 hp; Emission: China V; Fuel: Diesel; Engine: Fukang 3.8; Transmission: WLY. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is FAW Linghe Dongfang Star 141 hp 4X2(6 wheels) 5.2m crew cab flatbed light truck suited for?

FAW Linghe Dongfang Star 141 hp 4X2(6 wheels) 5.2m crew cab flatbed light truck is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does FAW Linghe Dongfang Star 141 hp 4X2(6 wheels) 5.2m crew cab flatbed light truck differ from other variants in the same series?

FAW Linghe Dongfang Star 141 hp 4X2(6 wheels) 5.2m crew cab flatbed light truck belongs to FAW Linghe Oriental Star Light Truck (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for FAW Linghe Dongfang Star 141 hp 4X2(6 wheels) 5.2m crew cab flatbed light truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export FAW Linghe Dongfang Star 141 hp 4X2(6 wheels) 5.2m crew cab flatbed light truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
