Dongfeng Commercial Vehicle Tianjin Medium Truck 160 hp 4X2(6 wheels) Flatbed Cargo Truck Chassis

Export reference
MSRP N/A
Horsepower: 160
Emission: China IV
Fuel: Diesel
Engine: Dongfeng 4-cylinder
Transmission: Dongfeng
Curb Weight:: 4.415ton
seating capacity: 3Personnel
Rated payload: 4.99ton
Drive 4X2 (6 wheels)
Cargo box type: stake body

Overview

The Dongfeng Commercial Vehicle Tianjin Medium Truck 160 hp 4X2(6 wheels) Flatbed Cargo Truck Chassis is a Medium-duty truck featuring 5.75m cargo length, stake body cargo body, 3Personnel volume and 4.99t payload. Its segment focus covers Building materials and agricultural products, matching those duty cycles. On the powertrain side, it comes with a Dongfeng 4-cylinder engine, 160 hp, 4X2 (6 wheels) drive and China IV emissions.

China IV 160 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): DFL1100BX7
Type: Chassis
Drive type: 4X2
Wheelbase: 3800mm
engine: DongfengEQH160-40
transmission: DongfengDF6S650
Rear Axle Ratio: 4.33
Cab length: 7.05m
Cab width: 2.5m
Cab height: 2.6m
Front track width: 1880mm
rear track: 1680mm
Curb Weight: 4.415ton
Rated payload: 4.99ton
GVWR: 9.6ton
Max. speed: 98km/h
Origin: Shiyan, Hubei
tonnage class: Medium-duty truck
Approach angle: 18.5°
departure angle: 12°
market segment: Building materials, agricultural products
Front/rear suspension: 1.365/2.135m
Energy Type: Diesel
Engine parameters
Engine Brand: Dongfeng
Engine Model: DongfengEQH160-40
Engine info: Dongfeng 4-cylinder
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 4.752L
Emission standard: China IV
Max output power: 118kW
Max hp: 160Horsepower
Max torque: 600N·m
Max torque speed: 1200-1600rpm
Rated speed: 2400rpm
Engine Type: 4-cylinder, inline, 4-stroke, electronically controlled common rail direct injection, turbocharged intercooled
Technology route: Electronic control common rail direct injection
Transmission Parameters
Transmission Model: DongfengDF6S650
Transmission Brand: Dongfeng
shift method: Manual
Forward gears: 6Gear
Number of Reverse Gears:
Cargo box parameters
Cargo box type: stake body
Cargo box length: 5.75m
Cargo box width: 2.4m
Cargo box height: 0.6m
*Cargo box interior width: 2.4000000953674
Cab parameters
Cab: Flat roof
seating capacity: 3Personnel
Seat rows: Sleeper cab
fuel tank
Fuel tank material: Steel
Fuel tank capacity: 160L
Chassis Specs
Front axle description: 3.6T front axle
Front axle allowable load: 3700kg
Frame Dimensions: 220x65x6mm
rear axle description: 6T rear axle
rear axle allowable load: 5900kg
Axle ratio: 4.33
Leaf spring count: 8/9+7
Suspension (front/rear): Leaf spring
Tire
Tire Size: 8.25R16
Number of tires: 6pcs

Photos

Exterior3

Cab3

6 photos

FAQ

What emission standard does Dongfeng Commercial Vehicle Tianjin Medium Truck 160 hp 4X2(6 wheels) Flatbed Cargo Truck Chassis use, and can it enter my country?

This model is listed as China IV. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Dongfeng Commercial Vehicle Tianjin Medium Truck 160 hp 4X2(6 wheels) Flatbed Cargo Truck Chassis?

Key specs of Dongfeng Commercial Vehicle Tianjin Medium Truck 160 hp 4X2(6 wheels) Flatbed Cargo Truck Chassis: Drive: 4x2; Horsepower: 160 hp; Emission: China IV; Fuel: Diesel; Engine: Dongfeng 4-cylinder; Transmission: Dongfeng. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Dongfeng Commercial Vehicle Tianjin Medium Truck 160 hp 4X2(6 wheels) Flatbed Cargo Truck Chassis suited for?

Dongfeng Commercial Vehicle Tianjin Medium Truck 160 hp 4X2(6 wheels) Flatbed Cargo Truck Chassis is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does Dongfeng Commercial Vehicle Tianjin Medium Truck 160 hp 4X2(6 wheels) Flatbed Cargo Truck Chassis differ from other variants in the same series?

Dongfeng Commercial Vehicle Tianjin Medium Truck 160 hp 4X2(6 wheels) Flatbed Cargo Truck Chassis belongs to Dongfeng Tianjin Medium Truck (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Dongfeng Commercial Vehicle Tianjin Medium Truck 160 hp 4X2(6 wheels) Flatbed Cargo Truck Chassis?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Dongfeng Commercial Vehicle Tianjin Medium Truck 160 hp 4X2(6 wheels) Flatbed Cargo Truck Chassis?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
