SAIC Hongyan Genlyon M500 320hp 8X4(12 wheels) Fuel Tanker Truck (Luping Machine Brand)

Export reference
MSRP N/A
Curb Weight:: 13.65ton
Emission: China V
Fuel: Diesel
Wheelbase:: 1800+4200+1400mm
Cab dimensions:: 11.57×2.5×3.738m
Truck Type:: Fuel tanker truck
Tank Size: 8.6×2.2×1.47m
Rated payload: 17.155ton
Drive 8X4 (12 wheels)
Horsepower 320

Overview

The SAIC Hongyan Genlyon M500 320hp 8X4(12 wheels) Fuel Tanker Truck (Luping Machine Brand) is a fuel tanker truck featuring 8.6×2.2×1.47m tank capacity, 17.155t payload, 21.5m³ volume and 13.65ton GVW. On the powertrain side, it comes with 320 hp, 8X4 (12 wheels) drive, China V emissions and Diesel fuel.

China V 320 Diesel 8X4

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Cab dimensions: 11.57×2.5×3.738m
Truck Type: Fuel tanker truck
Drive type: 8X4
Vehicle origin: Tieling, Liaoning
Wheelbase: 1800+4200+1400mm
Front track width: 2006/2006,2020/2020,2070/2070mm
rear track: 1850/1850mm
Curb Weight: 13.65ton
Rated payload: 17.155ton
Max. speed: 80km/h
Front/rear suspension: 1.435/2.135m
Energy Type: Diesel
Body Parameters
Tank Size: 8.6×2.2×1.47m
Tank Volume: 21.5m3
Transport medium: gasoline, kerosene, diesel
Medium Density: 0.83ton/cubic meter
Vehicle certification code: LPC5310GYYH5
Body Brand: Luping Machinery
Engine parameters
Engine Brand: SAIC Fiat Powertrain Hongyan
Engine Model: SAIC Fiat Powertrain HongyanF2CCE611D*L
Number of cylinders: 6cylinder
fuel type: Diesel
Displacement: 8.709L
Emission standard: China V
Max output power: 235kW
Max hp: 320Horsepower
Engine Type: Electronic high-pressure common rail system
Chassis Specs
Chassis Brand: SAIC Hongyan
Chassis Series: Genlyon
Chassis Model: CQ1316HMVG39-486
Leaf spring count: 3/3/4,3/3/6,9/9/12,3/3/12,5/5/6
Cab parameters
Cab: Genlyon
Tire
Tire Size: 11.00R20,12.00R20 18PR,295/80R22.5,315/80R22.5 18PR

Photos

Exterior1

1 photos

FAQ

What emission standard does SAIC Hongyan Genlyon M500 320hp 8X4(12 wheels) Fuel Tanker Truck (Luping Machine Brand) use, and can it enter my country?

This model is listed as China V. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of SAIC Hongyan Genlyon M500 320hp 8X4(12 wheels) Fuel Tanker Truck (Luping Machine Brand)?

Key specs of SAIC Hongyan Genlyon M500 320hp 8X4(12 wheels) Fuel Tanker Truck (Luping Machine Brand): Drive: 8x4; Horsepower: 320 hp; Emission: China V; Fuel: Diesel. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is SAIC Hongyan Genlyon M500 320hp 8X4(12 wheels) Fuel Tanker Truck (Luping Machine Brand) suited for?

SAIC Hongyan Genlyon M500 320hp 8X4(12 wheels) Fuel Tanker Truck (Luping Machine Brand) is a fuel tanker truck model; configuration should match the job. State the application, emission and LHD/RHD needs in your quote.

How does SAIC Hongyan Genlyon M500 320hp 8X4(12 wheels) Fuel Tanker Truck (Luping Machine Brand) differ from other variants in the same series?

SAIC Hongyan Genlyon M500 320hp 8X4(12 wheels) Fuel Tanker Truck (Luping Machine Brand) belongs to SAIC Hongyan Genlyon Heavy Truck (fuel tanker truck). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for SAIC Hongyan Genlyon M500 320hp 8X4(12 wheels) Fuel Tanker Truck (Luping Machine Brand)?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export SAIC Hongyan Genlyon M500 320hp 8X4(12 wheels) Fuel Tanker Truck (Luping Machine Brand)?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
