Jinbei Xinyuan T20S 1.5L 109 hp 4X2(6 wheels) gasoline 3.05m single-row van micro truck

Export reference
From $9,028
MSRP ¥6.5M CNY
Horsepower: 109
Emission: China V
Fuel: gasoline
Engine: Xinyuan Jinbei1.5L
Curb Weight:: 1.44ton
Wheelbase:: 3200mm
seating capacity: 2Personnel
Rated payload: 1.2ton
Drive 4X2 (6 wheels)
Cargo box type: Van body

Overview

The SRM Jinbei Xinyuan T20S 1.5L 109 hp 4X2(6 wheels) gasoline 3.05m single-row van micro truck is a Light Truck featuring 3.05m cargo length, Van body cargo body, 2Personnel volume and 1.2t payload. Its segment focus covers Urban Distribution, matching those duty cycles. On the powertrain side, it comes with a Xinyuan Jinbei1.5L engine, 109 hp, 4X2 (6 wheels) drive and China V emissions.

China V 109 gasoline 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): JKC5031XXY-DG5DL
Type: enclosed cargo truck
Drive type: 4X2
Wheelbase: 3200mm
Box length class: 3m
engine: Brilliance Xinyuan Jinbei SWCG14
transmission: 5-speed transmission
Cab length: 5.2m
Cab width: 1.635m
Cab height: 2.52m
Front track width: 1390mm
rear track: 1230mm
Curb Weight: 1.44ton
Rated payload: 1.2ton
GVWR: 2.77ton
Max. speed: 120km/h
Origin: Chongqing
tonnage class: Light Truck
Approach angle: 35°
departure angle: 26°
market segment: Urban Distribution
Front/rear suspension: 0.75/1.25m
Energy Type: gasoline
Engine parameters
Engine Brand: Xinyuan Jinbei
Engine Model: Brilliance Xinyuan Jinbei SWCG14
Engine info: Xinyuan Jinbei1.5L
Number of cylinders: 4cylinder
fuel type: gasoline
Cylinder arrangement: Inline
Displacement: 1.499L
Emission standard: China V
Max output power: 80kW
Max hp: 109Horsepower
Transmission Parameters
Transmission Model: 5-speed transmission
shift method: Manual
Forward gears: 5Gear
Number of Reverse Gears:
Cargo box parameters
Cargo box type: Van body
Cargo box length: 3.05m
Cargo box width: 1.54m
Cargo box height: 1.6m
*Cargo box interior width: 1.539999961853
Cab parameters
seating capacity: 2Personnel
Seat rows: Single Row
Chassis Specs
Front axle allowable load: 988kg
rear axle allowable load: 1782kg
Leaf spring count: -/6
Tire
Tire Size: 175/70R14LT 8PR
Number of tires: 6pcs
Control configuration
ABS:

Photos

Exterior1

1 photos

FAQ

What is the export price of Jinbei Xinyuan T20S 1.5L 109 hp 4X2(6 wheels) gasoline 3.05m single-row van micro truck, and what does it include?

Jinbei Xinyuan T20S 1.5L 109 hp 4X2(6 wheels) gasoline 3.05m single-row van micro truck export reference is about From $9,028; MSRP is ¥6.5M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does Jinbei Xinyuan T20S 1.5L 109 hp 4X2(6 wheels) gasoline 3.05m single-row van micro truck use, and can it enter my country?

This model is listed as China V. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Jinbei Xinyuan T20S 1.5L 109 hp 4X2(6 wheels) gasoline 3.05m single-row van micro truck?

Key specs of Jinbei Xinyuan T20S 1.5L 109 hp 4X2(6 wheels) gasoline 3.05m single-row van micro truck: Drive: 4x2; Horsepower: 109 hp; Emission: China V; Fuel: gasoline; Engine: Xinyuan Jinbei1.5L. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Jinbei Xinyuan T20S 1.5L 109 hp 4X2(6 wheels) gasoline 3.05m single-row van micro truck suited for?

Jinbei Xinyuan T20S 1.5L 109 hp 4X2(6 wheels) gasoline 3.05m single-row van micro truck is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does Jinbei Xinyuan T20S 1.5L 109 hp 4X2(6 wheels) gasoline 3.05m single-row van micro truck differ from other variants in the same series?

Jinbei Xinyuan T20S 1.5L 109 hp 4X2(6 wheels) gasoline 3.05m single-row van micro truck belongs to Xinyuan T20S (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Jinbei Xinyuan T20S 1.5L 109 hp 4X2(6 wheels) gasoline 3.05m single-row van micro truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Jinbei Xinyuan T20S 1.5L 109 hp 4X2(6 wheels) gasoline 3.05m single-row van micro truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
