JAC Gallop A5W III Heavy Truck Classic Edition 480 hp 4X2(6 wheels) Tractor Truck

Export reference
From $45,486
MSRP ¥32.75M CNY
Fuel: Diesel
Gross Trailer Weight:: 34.4ton
Wheelbase:: 3800mm
Tire Size:: 11R22.5
Front axle allowable load:: 6500kg
Displacement:: 12.155L
Drive 4X2 (6 wheels)
Horsepower 480
Emission China V
Transmission Fast Gear

Overview

The JAC Gallop A5W III Heavy Truck Classic Edition 480 hp 4X2(6 wheels) Tractor Truck is a Heavy truck featuring 4X2 (6 wheels) drive, 480 hp, 18t GVW and China V emissions. Its segment focus covers Express & Freight, matching those duty cycles. On the powertrain side, it comes with a YuchaiYC6K1248-50 engine, Fast Gear transmission and Diesel fuel.

China V 480 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): HFC4181P1K7A38S2V
Drive type: 4X2
Wheelbase: 3800mm
engine: YuchaiYC6K1248-50
transmission: Fast Gear12JSDX220TA-B
Rear Axle Ratio: 3.7
Cab length: 6.365m
Cab width: 2.5m
Cab height: 3.98m
Front track width: 2040mm
Gross Trailer Weight: 34.4ton
rear track: 1860mm
Curb Weight: 7.4ton
GVWR: 18ton
Max. speed: 100km/h
Origin: Hefei, Anhui
tonnage class: Heavy truck
market segment: Express & Freight
Version: Classic Edition
Energy Type: Diesel
Engine parameters
Engine Brand: Yuchai
Engine Model: YuchaiYC6K1248-50
Number of cylinders: 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 12.155L
Emission standard: China V
Max output power: 353kW
Max hp: 480Horsepower
Max torque: 2250N·m
Max torque speed: 1000-1500rpm
Rated speed: 1900rpm
Transmission Parameters
Transmission Model: Fast Gear12JSDX220TA-B
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 12Gear
Number of Reverse Gears: 2pcs
fuel tank
Fuel tank/air tank material: aluminum alloy
Fuel tank capacity: 1060L
Cab parameters
Cab: High roof
Cab suspension: Four-point air suspension
Cab tilting: Electric
seating capacity: 3Personnel
Seat rows: Sleeper cab
Driver seat type: air suspension seat
Chassis Specs
Front axle description: 5T
Front axle allowable load: 6500kg
Fifth wheel: 50#,90#
Frame Dimensions: 280×80×8mm
rear axle description: 469
rear axle allowable load: 11500kg
Axle ratio: 3.7
Leaf spring count: 2/1+-
Tire
Tire Size: 11R22.5
Number of tires: 6pcs
Control configuration
ABS:
interior configuration
Power Windows:
Electronic Central Lock:
Independent AC:
smart configuration
Cruise control (CCS):

Photos

0 photos

FAQ

What is the export price of JAC Gallop A5W III Heavy Truck Classic Edition 480 hp 4X2(6 wheels) Tractor Truck, and what does it include?

JAC Gallop A5W III Heavy Truck Classic Edition 480 hp 4X2(6 wheels) Tractor Truck export reference is about From $45,486; MSRP is ¥32.75M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does JAC Gallop A5W III Heavy Truck Classic Edition 480 hp 4X2(6 wheels) Tractor Truck use, and can it enter my country?

This model is listed as China V. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of JAC Gallop A5W III Heavy Truck Classic Edition 480 hp 4X2(6 wheels) Tractor Truck?

Key specs of JAC Gallop A5W III Heavy Truck Classic Edition 480 hp 4X2(6 wheels) Tractor Truck: Drive: 4x2; Horsepower: 480 hp; Emission: China V; Fuel: Diesel; Transmission: Fast Gear. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is JAC Gallop A5W III Heavy Truck Classic Edition 480 hp 4X2(6 wheels) Tractor Truck suited for?

JAC Gallop A5W III Heavy Truck Classic Edition 480 hp 4X2(6 wheels) Tractor Truck is a Tractor Trucks model, typically used for semi-trailer haulage, long-haul and port shuttle work. Match axle load, route and emission needs; describe route and payload in your quote request.

How does JAC Gallop A5W III Heavy Truck Classic Edition 480 hp 4X2(6 wheels) Tractor Truck differ from other variants in the same series?

JAC Gallop A5W III Heavy Truck Classic Edition 480 hp 4X2(6 wheels) Tractor Truck belongs to JAC Gallop A5 Heavy Truck (Tractor Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for JAC Gallop A5W III Heavy Truck Classic Edition 480 hp 4X2(6 wheels) Tractor Truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export JAC Gallop A5W III Heavy Truck Classic Edition 480 hp 4X2(6 wheels) Tractor Truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
