Sinotruk V3 Series 2.5L Diesel 185 hp 4X2(6 wheels) Sinotruk 12-Speed 3.85m Semi-Row Stake Light Truck

Export reference
From $20,028
MSRP ¥14.42M CNY
Horsepower: 185
Emission: China VI
Fuel: Diesel
Engine: Weichai2.5L
Transmission: Sinotruk
Curb Weight:: 2.72ton
seating capacity: 3Personnel
Rated payload: 1.58ton
Drive 4X2 (6 wheels)
Cargo box type: Stake type

Overview

The Sinotruk V3 Series 2.5L Diesel 185 hp 4X2(6 wheels) Sinotruk 12-Speed 3.85m Semi-Row Stake Light Truck is a Light Truck featuring 3.85m cargo length, Stake type cargo body, 3Personnel volume and 1.58t payload. Its segment focus covers Green Pass, matching those duty cycles. On the powertrain side, it comes with a Weichai2.5L engine, 185 hp, 4X2 (6 wheels) drive and China VI emissions.

China VI 185 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): CDW5044CCYG331DFA2
Type: stake truck
Drive type: 4X2
Wheelbase: 3600mm
Box length class: 3.8m
engine: WeichaiWP2.5NQ190E62
transmission: Sinotruk 12-speed
Rear Axle Ratio: 4.875
Cab length: 5.995m
Cab width: 2.2m
Cab height: 3.16m
Front track width: 1800mm
rear track: 1790mm
Curb Weight: 2.72ton
Rated payload: 1.58ton
GVWR: 4.495ton
Max. speed: 90km/h
Origin: Chengdu, Sichuan
tonnage class: Light Truck
Approach angle: 17°
departure angle: 20°
market segment: Green Pass
Front/rear suspension: 1.22/1.415m
Energy Type: Diesel
Engine parameters
Engine Brand: Weichai
Engine Model: WP2.5NQ190E62
Engine info: Weichai2.5L
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 2.493L
Emission standard: China VI
Max output power: 136kW
Max hp: 185Horsepower
Transmission Parameters
Transmission Model: Sinotruk 12-speed
Transmission Brand: Sinotruk
shift method: Manual
Forward gears: 12Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Cargo box type: Stake type
Cargo box length: 3.85m
Cargo box width: 2.1m
*Cargo box interior width: 2.1
Cab parameters
Cab: V36
Cab width: 2080mm
seating capacity: 3Personnel
Seat rows: Sleeper cab
Driver seat type: air suspension seat
fuel tank
Fuel tank capacity: 260L
Chassis Specs
Front axle description: 2.7T
Front axle allowable load: 1705kg
rear axle description: 7.2T
rear axle allowable load: 2790kg
Axle ratio: 4.875
Leaf spring count: 3/5+3
Tire
Tire Size: 7.00R16LT 8PR
Number of tires: 6pcs
Control configuration
ABS:
interior configuration
Multifunction steering wheel:
AC control type: Manual
Power Windows:
Remote key:
Electronic Central Lock:
Exterior features
Air deflector:
Multimedia features
Center Console Color Screen:
GPS/Beidou driving recorder:
External audio input (AUX/USB/iPod etc.):
Service brake
Brake Type: Air brake
Parking brake: Spring brake
Front wheel brake: Drum Type
Rear Wheel Brake: Drum Type

Photos

0 photos

FAQ

What is the export price of Sinotruk V3 Series 2.5L Diesel 185 hp 4X2(6 wheels) Sinotruk 12-Speed 3.85m Semi-Row Stake Light Truck, and what does it include?

Sinotruk V3 Series 2.5L Diesel 185 hp 4X2(6 wheels) Sinotruk 12-Speed 3.85m Semi-Row Stake Light Truck export reference is about From $20,028; MSRP is ¥14.42M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does Sinotruk V3 Series 2.5L Diesel 185 hp 4X2(6 wheels) Sinotruk 12-Speed 3.85m Semi-Row Stake Light Truck use, and can it enter my country?

This model is listed as China VI. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Sinotruk V3 Series 2.5L Diesel 185 hp 4X2(6 wheels) Sinotruk 12-Speed 3.85m Semi-Row Stake Light Truck?

Key specs of Sinotruk V3 Series 2.5L Diesel 185 hp 4X2(6 wheels) Sinotruk 12-Speed 3.85m Semi-Row Stake Light Truck: Drive: 4x2; Horsepower: 185 hp; Emission: China VI; Fuel: Diesel; Engine: Weichai2.5L; Transmission: Sinotruk. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Sinotruk V3 Series 2.5L Diesel 185 hp 4X2(6 wheels) Sinotruk 12-Speed 3.85m Semi-Row Stake Light Truck suited for?

Sinotruk V3 Series 2.5L Diesel 185 hp 4X2(6 wheels) Sinotruk 12-Speed 3.85m Semi-Row Stake Light Truck is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does Sinotruk V3 Series 2.5L Diesel 185 hp 4X2(6 wheels) Sinotruk 12-Speed 3.85m Semi-Row Stake Light Truck differ from other variants in the same series?

Sinotruk V3 Series 2.5L Diesel 185 hp 4X2(6 wheels) Sinotruk 12-Speed 3.85m Semi-Row Stake Light Truck belongs to Sinotruk V Series (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Sinotruk V3 Series 2.5L Diesel 185 hp 4X2(6 wheels) Sinotruk 12-Speed 3.85m Semi-Row Stake Light Truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Sinotruk V3 Series 2.5L Diesel 185 hp 4X2(6 wheels) Sinotruk 12-Speed 3.85m Semi-Row Stake Light Truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
