Sinotruk Wangpai W5D 160hp 4X2(6 wheels) range-extended hybrid water sprinkler truck chassis

Export reference
From $118,056
MSRP ¥85M CNY
Emission: China VI
Fuel: Natural gas (LNG/CNG)
Wheelbase:: 4700mm
Cab dimensions:: 9.86×2.5×2.92m
Truck Type:: Water Sprinkler Truck
Front track width:: 1957mm
Rated payload: 8.66ton
Drive 4X2 (6 wheels)
Horsepower 160
Curb Weight: 9.145ton

Overview

The Sinotruk Wangpai W5D 160hp 4X2(6 wheels) range-extended hybrid water sprinkler truck chassis is a water sprinkler truck featuring 8.66t payload, 9.145ton GVW and 4X2 (6 wheels) drive. On the powertrain side, it comes with 160 hp, China VI emissions and Natural gas (LNG/CNG) fuel.

China VI 160 Natural gas (LNG/CNG) 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Cab dimensions: 9.86×2.5×2.92m
Truck Type: Water Sprinkler Truck
Drive type: 4X2
Wheelbase: 4700mm
Front track width: 1957mm
rear track: 1860mm
Curb Weight: 9.145ton
Rated payload: 8.66ton
Max. speed: 85km/h
Front/rear suspension: 1.46/2.8m
Energy Type: Natural gas (LNG/CNG)
Engine parameters
Engine Model: YuchaiYCS04160N-60
Number of cylinders: 4cylinder
fuel type: Natural gas (LNG/CNG)
Displacement: 4.16L
Emission standard: China VI
Max output power: 118kW
Max hp: 160Horsepower
Rated speed: 2100rpm
Engine Type: Theoretical air-fuel ratio + EGR + TWC + ASC
Chassis Specs
Chassis Brand: 重汽王牌
Chassis Series: Wangpai W5D
Chassis Model: CDW1180A1NHEV
Front axle description: CZ1531BZS
Frame Dimensions: 245×70×10-860mm
rear axle description: CZ1530BZS
Axle ratio: 5.571
Leaf spring count: 9/10+8
Tire
Tire Size: 10.00R20 18PR
Number of tires: 6pcs

Photos

Exterior1

1 photos

FAQ

What is the export price of Sinotruk Wangpai W5D 160hp 4X2(6 wheels) range-extended hybrid water sprinkler truck chassis, and what does it include?

Sinotruk Wangpai W5D 160hp 4X2(6 wheels) range-extended hybrid water sprinkler truck chassis export reference is about From $118,056; MSRP is ¥85M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does Sinotruk Wangpai W5D 160hp 4X2(6 wheels) range-extended hybrid water sprinkler truck chassis use, and can it enter my country?

This model is listed as China VI. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Sinotruk Wangpai W5D 160hp 4X2(6 wheels) range-extended hybrid water sprinkler truck chassis?

Key specs of Sinotruk Wangpai W5D 160hp 4X2(6 wheels) range-extended hybrid water sprinkler truck chassis: Drive: 4x2; Horsepower: 160 hp; Emission: China VI; Fuel: Natural gas (LNG/CNG). See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Sinotruk Wangpai W5D 160hp 4X2(6 wheels) range-extended hybrid water sprinkler truck chassis suited for?

Sinotruk Wangpai W5D 160hp 4X2(6 wheels) range-extended hybrid water sprinkler truck chassis is a water sprinkler truck model; configuration should match the job. State the application, emission and LHD/RHD needs in your quote.

How does Sinotruk Wangpai W5D 160hp 4X2(6 wheels) range-extended hybrid water sprinkler truck chassis differ from other variants in the same series?

Sinotruk Wangpai W5D 160hp 4X2(6 wheels) range-extended hybrid water sprinkler truck chassis belongs to Sinotruk Wangpai W5D near-heavy truck (water sprinkler truck). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Sinotruk Wangpai W5D 160hp 4X2(6 wheels) range-extended hybrid water sprinkler truck chassis?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Sinotruk Wangpai W5D 160hp 4X2(6 wheels) range-extended hybrid water sprinkler truck chassis?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
