SHACMAN Commercial Vehicle Xuande E9 7.3T 4.2m Single Row Pure Electric Box Light Truck 83.1kWh 4X2(6 wheels)

Export reference
MSRP N/A
Rated payload:: 2.955ton
Wheelbase:: 3300mm
Cargo box type:: Van body
Model code (announced):: SX5070XXYBEV1
Type:: enclosed cargo truck
Box length class:: 4.2m
Drive 4X2 (6 wheels)
CLTC range: 220km
Motor 1 Brand: Land
Curb Weight: 4.15ton

Overview

The SHACMAN Commercial Vehicle Xuande E9 7.3T 4.2m Single Row Pure Electric Box Light Truck 83.1kWh 4X2(6 wheels) is a Light Truck featuring 220km battery/range, Land motor, 4X2 (6 wheels) drive and 2.955t payload.

4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): SX5070XXYBEV1
Type: enclosed cargo truck
Drive type: 4X2
Wheelbase: 3300mm
Box length class: 4.2m
Cab length: 5.995m
Cab width: 2.2m
Cab height: 3.15m
CLTC range: 220km
Curb Weight: 4.15ton
Rated payload: 2.955ton
GVWR: 7.3ton
Max. speed: 80km/h
Origin: Baoji, Shaanxi
tonnage class: Light Truck
Energy Type: Electric
electric motor
Motor 1 Brand: Land
Motor 1 Model: Xi'an Lande LDTM060
Motor Type: Permanent magnet synchronous motor
Fuel Type: Electric
total rated power: 60kW
Peak power: 100kW
total peak torque: 460N·m
total rated torque: 250N·m
Battery/Charging
Battery Brand: Shanghai Kana
Charging method: DC
Battery type: NMC lithium battery pack
fast charge time: 3h
Battery capacity: 83.1kWh
Battery total voltage: 532.8V
Battery Model: CEB-LM26.4
Cargo box parameters
Cargo box type: Van body
Cargo box length: 4.2m
Cargo box width: 2.1m
Cargo box height: 2.1m
Cab parameters
seating capacity: 3Personnel
Seat rows: Single Row
Chassis Specs
Front axle allowable load: 3000kg
rear axle allowable load: 4300kg
Tire
Tire Size: 7.00R16,7.50R16
Number of tires: 6pcs
Control configuration
ABS:
