Proton Auto Charging Version 4X2(6 wheels) Electric Kitchen Waste Truck 175.03kWh

Export reference
MSRP N/A
Rated payload:: 7.76ton
Wheelbase:: 4500mm
Model code (announced):: STL5187TCABEV1
Truck Type:: Electric kitchen waste truck
Cab length:: 7.69m
GVWR:: 18ton
Drive 4X2 (6 wheels)
Battery type: Lithium Iron Phosphate Battery
Motor 1 Brand: Jingjin
Curb Weight: 10.11ton

Overview

The Proton Auto Charging Version 4X2(6 wheels) Electric Kitchen Waste Truck 175.03kWh is a Electric Garbage Truck featuring Lithium Iron Phosphate Battery battery/range, Jingjin motor, 4X2 (6 wheels) drive and 7.76t payload.

4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): STL5187TCABEV1
Drive type: 4X2
Truck Type: Electric kitchen waste truck
Wheelbase: 4500mm
Cab length: 7.69m
Cab width: 2.53m
Cab height: 3.18m
Curb Weight: 10.11ton
Rated payload: 7.76ton
GVWR: 18ton
Max. speed: 89km/h
Origin: Baoji, Shaanxi
Energy Type: Electric
electric motor
Motor 1 Brand: Jingjin
Motor 1 Model: TZ365XSC12
Motor Type: Permanent magnet synchronous motor
total rated power: 105kW
Peak power: 160kW
total rated torque: 500N·m
total peak torque: 1050N·m
Battery/Charging
Battery type: Lithium Iron Phosphate Battery
fast charge time: 1.5h
Battery capacity: 175.03kWh
Chassis Specs
Front axle load: 6500ton
Rear Axle Load: 11500ton
Chassis Series: Dechuang Heavy Truck
Chassis Model: SX1187LF1XEV2
Leaf spring count: 3/11+5,9/11+5
Transmission Parameters
Number of gears: 4Gear
Transmission Model: 4.0E+120
Tire
Tire Size: 10.00R20 18PR
Number of tires: 6pcs

Photos

Exterior1

1 photos

FAQ

What are the key specs of Proton Auto Charging Version 4X2(6 wheels) Electric Kitchen Waste Truck 175.03kWh?

Key specs of Proton Auto Charging Version 4X2(6 wheels) Electric Kitchen Waste Truck 175.03kWh: Drive: 4x2. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Proton Auto Charging Version 4X2(6 wheels) Electric Kitchen Waste Truck 175.03kWh suited for?

Proton Auto Charging Version 4X2(6 wheels) Electric Kitchen Waste Truck 175.03kWh is a Electric Garbage Truck model suited to short-haul or fixed routes with charging access. Confirm local charging and registration rules, then request a quote.

How does Proton Auto Charging Version 4X2(6 wheels) Electric Kitchen Waste Truck 175.03kWh differ from other variants in the same series?

Proton Auto Charging Version 4X2(6 wheels) Electric Kitchen Waste Truck 175.03kWh belongs to Dechuang Battery-Electric Truck (Electric Garbage Truck). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Proton Auto Charging Version 4X2(6 wheels) Electric Kitchen Waste Truck 175.03kWh?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Proton Auto Charging Version 4X2(6 wheels) Electric Kitchen Waste Truck 175.03kWh?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
