Yanlong Auto 2.5T 2.75m pure electric wing-opening box mini truck 35.09kWh 4X2(6 wheels)

Export reference
From $18,028
MSRP ¥12.98M CNY
Rated payload:: 1.075ton
Wheelbase:: 2950mm
Cargo box volume:: 6.2m³
Model code (announced):: LZL5033XYKBEV
Type:: enclosed cargo truck
Box length class:: 2.8m
Drive 4X2 (6 wheels)
CLTC range: 185km
Motor 1 Brand: Inbol
Curb Weight: 1.3ton

Overview

The Yanlong Auto 2.5T 2.75m pure electric wing-opening box mini truck 35.09kWh 4X2(6 wheels) is a mini truck featuring 185km battery/range, Inbol motor, 4X2 (6 wheels) drive and 1.075t payload.

4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): LZL5033XYKBEV
Type: enclosed cargo truck
Drive type: 4X2
Wheelbase: 2950mm
Box length class: 2.8m
Cab length: 4.74m
Cab width: 1.51m
Cab height: 2.43m
CLTC range: 185km
Curb Weight: 1.3ton
Rated payload: 1.075ton
GVWR: 2.505ton
Max. speed: 80km/h
Origin: Liuzhou, Guangxi
tonnage class: mini truck
Energy Type: Electric
electric motor
Motor 1 Brand: Inbol
Motor 1 Model: TZ180XS-EP04515
Max torque: 150N·m
Motor Type: Permanent magnet synchronous motor
Fuel Type: Electric
total rated power: 20kW
Peak power: 45kW
total peak torque: 150N·m
total rated torque: 70N·m
Electronic Control
ECU Brand: Inbol
Battery/Charging
Battery Brand: CATL
Charging method: Fast Charge
Battery type: Lithium Iron Phosphate Battery
fast charge time: 2.5h
Battery capacity: 35.09kWh
Battery rated voltage: 202.96V
Battery total voltage: 229V
Energy Density: 158.98
Cargo box parameters
Cargo box volume: 6.2m³
Cargo box type: Wing Van
Cargo box length: 2.75m
Cargo box width: 1.41m
Cargo box height: 1.61m
Cab parameters
Cab: Single Row
seating capacity: 2Personnel
Seat rows: Single Row
Chassis Specs
Front axle allowable load: 960kg
rear axle allowable load: 1545kg
Aluminum wheels:
Tire
Tire Size: 165R13C/175/75R14C
Number of tires: 4pcs
Control configuration
ABS:
Power steering: Electric Power Steering
interior configuration
Steering Wheel Material: Plastic
AC control type: Manual
Power Windows:
lighting configuration
Headlight height adjustment:
Service brake
Brake Type: Hydraulic brake
Front wheel brake: Disc
Rear Wheel Brake: Drum Type

Photos

Exterior1

1 photos

FAQ

What is the export price of Yanlong Auto 2.5T 2.75m pure electric wing-opening box mini truck 35.09kWh 4X2(6 wheels), and what does it include?

Yanlong Auto 2.5T 2.75m pure electric wing-opening box mini truck 35.09kWh 4X2(6 wheels) export reference is about From $18,028; MSRP is ¥12.98M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What are the key specs of Yanlong Auto 2.5T 2.75m pure electric wing-opening box mini truck 35.09kWh 4X2(6 wheels)?

Key specs of Yanlong Auto 2.5T 2.75m pure electric wing-opening box mini truck 35.09kWh 4X2(6 wheels): Drive: 4x2. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Yanlong Auto 2.5T 2.75m pure electric wing-opening box mini truck 35.09kWh 4X2(6 wheels) suited for?

Yanlong Auto 2.5T 2.75m pure electric wing-opening box mini truck 35.09kWh 4X2(6 wheels) is a electric cargo truck model suited to short-haul or fixed routes with charging access. Confirm local charging and registration rules, then request a quote.

How does Yanlong Auto 2.5T 2.75m pure electric wing-opening box mini truck 35.09kWh 4X2(6 wheels) differ from other variants in the same series?

Yanlong Auto 2.5T 2.75m pure electric wing-opening box mini truck 35.09kWh 4X2(6 wheels) belongs to Yanlong Auto Yanlong Micro Truck (electric cargo truck). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Yanlong Auto 2.5T 2.75m pure electric wing-opening box mini truck 35.09kWh 4X2(6 wheels)?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Yanlong Auto 2.5T 2.75m pure electric wing-opening box mini truck 35.09kWh 4X2(6 wheels)?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
