Alcoa 22.5x11(8 wheels).75 8-hole heavy-duty wide-base aluminum alloy wheel (Part No.: 817570)
EXW
Export quote
Alcoa 22.5-inch wheel
Main model photos
6 photos
Models
On sale
Alcoa 22.5x11(8 wheels).75 8-hole heavy-duty wide-base aluminum alloy wheel (Part No.: 812580)
EXW
Export quote
Alcoa 22.5x9(8 wheels).00 8-hole heavy-duty aluminum alloy wheel (Part No.: 896570)
EXW
Export quote
Alcoa 22.5x8(8 wheels).25 8-hole heavy-duty aluminum alloy wheel (Part No.: 886570)
EXW
Export quote
Alcoa 22.5x14(8 wheels).00 8-hole wide-base aluminum alloy wheel (Part No.: 841510)
EXW
Export quote
Series Specs
Basic Info
Product ID: 817570 / 812580 / 896570 / 886570 / 841510 / 833520 / 818520 / 818510 / 812520 / 812510 / 896520 / 896510 / 895520 / 895510 / 886520 / 886510 / 885520 / 885510 / 883677 / 883360 / 883110 / 874520 / 874510
Specifications: 22.5x11.75 / 22.5x9.00 / 22.5x8.25 / 22.5x14.00 / 22.5x13.00 / 22.5x7.50
Max load capacity: 5000 / 4335 / 3835 / 5800 / 5500 / 4500 / 4750 / 4125 / 4535 / 3650 / 3750 / 3350 / 3250 / 3550kg
inner offset: 120 / 135 / 153 / 145 / 14 / 154 / 145.9 / 147 / 144 / 138mm
Weight: 23.6 / 27.2 / 26.7 / 26.3 / 30.7 / 25.2 / 22.6 / 21 / 23.2 / 25.5 / 25.4 / 22.7 / 22.5 / 20.4 / 23.5 / 23.7kg
Web plate thickness: 25 / 26 / 22 / 28 / 21 / 23 / 21.7 / 20mm
bolt hole diameter: 32 / 26 / 32.5mm
number of bolt holes: 10 / 8
Pitch circle diameter: 335 / 285.75 / 285mm
Center Hole Diameter: 281.2 / 220.1 / 221mm
Material: aluminum alloy
Air valve model: 40MS00N / 83MS00N / 70MS07N2 / TR554D / TR544D / TR555D
Reference tire specification: Michelin 385/65R22.5 XTE 3；Goodyear 385/65R22.5 RHT II / Michelin295/80R22.5 X LINE ENERGY Z；Michelin 11R22.5 X Coach Energy_Z；Michelin 315/80R22.5 XZA 2+ ENERGY；Michelin 12R22.5 X MULTI Z； / Michelin295/80R22.5 X LINE ENERGY Z；Michelin11R22.5 X Coach Energy_Z；Michelin 315/80R22.5 XZA 2+ ENERGY； / Michelin 425/65R22.5 XTE 2；Goodyear 425/65R22.5 RHT II / Michelin 11R22.5 XZA 2+ ENERGY；Michelin 275/70R22.5 XZU 3+；
Remarks: Heavy-duty, wheels without ventilation holes, protects brakes in off-road conditions, also suitable for regular road use. / Uses a patented surface treatment technology that allows aluminum penetration, enabling easy wheel surface cleaning with soap and water.
FAQ
What kind of truck is Alcoa Alcoa 22.5-inch wheel Wheel?
Alcoa Alcoa 22.5-inch wheel is an export-oriented Wheel lineup with about 23 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is Wheel typically used for?
For Wheel, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Alcoa 22.5-inch wheel include?
Alcoa 22.5-inch wheel currently lists about 23 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Alcoa 22.5-inch wheel?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
