Dongfeng H5 350 hp 8X4(12 wheels) cleaning suction truck (Huazhuanyi brand)
EXW
From $38,194
Export quote
Dongfeng H5 Heavy Truck suction/septic tank truck
Main model photos
1,993 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng H5 350 hp 8X4(12 wheels) cleaning suction truck (Huazhuanyi brand) | 8x4 / 350hp | From $38,194 | |
| Dongfeng H5 350 hp 8X4(12 wheels) cleaning suction truck (Chusheng brand) | 8x4 / 350hp | From $38,194 | |
| Dongfeng H5 350 hp 8X4(12 wheels) cleaning suction truck (Chusheng brand) | 8x4 / 350hp | From $38,194 | |
| Dongfeng H5 350hp 8X4(12 wheels) Cleaning & Suction Truck (Zhuanli Brand) | 8x4 / 350hp | From $38,194 | |
| Dongfeng H5 Chuangye Edition 270 hp 6X4(10 wheels) Cleaning and Suction Truck (Wanglongwei) | 6x4 / 270hp | From $29,861 |
Dongfeng H5 350 hp 8X4(12 wheels) cleaning suction truck (Chusheng brand)
EXW
From $38,194
Export quote
Dongfeng H5 350 hp 8X4(12 wheels) cleaning suction truck (Chusheng brand)
EXW
From $38,194
Export quote
Dongfeng H5 350hp 8X4(12 wheels) Cleaning & Suction Truck (Zhuanli Brand)
EXW
From $38,194
Export quote
Dongfeng H5 Chuangye Edition 270 hp 6X4(10 wheels) Cleaning and Suction Truck (Wanglongwei)
EXW
From $29,861
Export quote
Series Specs
Basic Info
Cab dimensions: 11.99×2.55×3.98 / 10.8×2.55×3.85 / 11.99×2.55×3.85 / 12×2.55×3.85 / 10.1×2.55×3.8 / 10.15×2.55×3.85m
Type: cleaning and suction truck
Drive type: 8X4 / 6X4
Front/rear track width: Front track: 2020/2020mm; Rear track: 1860/1860mm / Front track: 2050mm; Rear track: 1860/1860mm / 2050/1860/1860 / 2050；1860/1860
Wheelbase: 2050+3050+1350 / 4500+1350mm
Rated mass: 11.24 / 10.37 / 11.295 / 11.17 / 7.37 / 7.305ton
GVWR: 31 / 25ton
Front/rear suspension: 1.525/2.665 / 1.525/2.125 / 1.525/2.675 / 1.445/2.805 / 1.445/2.855m
Energy Type: Diesel
Body Parameters
Tank Size: 5.37×2.15 / 5.4×2.15m
Tank Volume: 16.43 / 17.62m3
Vehicle certification code: EHY5310GQWL6 / CSC5316GQWEL6 / CSC5310GQWEL6 / ZLC5316GQWL6 / WLW5256GQWLZ / CLW5252GQW6WS / EHY5250GQWL6
Body Brand: Huazhuanyi Brand / Chusheng Brand / Zhuanli brand / Wanglongwei Brand / Chengliwei
Engine parameters
Engine Model: YCK08350-60 / YCS06270-60 / YuchaiYCK08350-60
Displacement: 7.7 / 6.23L
Emission standard: China VI
Max output power: 257 / 199kW
Max hp: 350 / 270Horsepower
Rated speed: 2200 / 2300rpm
Chassis Specs
Chassis Brand: DongfengLiuqi
Chassis Series: ChenglongH5
Chassis Model: LZ1316H5FCT / LZ1256H5DCT
Frame Dimensions: 282(8+4) / 300(8+4)mm
Steering gear: Domestic
rear axle description: 2*440
Axle ratio: 5.143
Leaf spring count: 11/11/10 / 11/10
clutch: Φ430
Transmission Parameters
Number of gears: 10 / 12Gear
Transmission Model: 10JSD140T / HW11708STC / Fast Gear10JSD140T
Cab parameters
Cab: H51S / H53S
Tire
Tire Size: 11.00R20 16PR / 11.00R20 18PR
FAQ
What kind of truck is Dongfeng Dongfeng H5 Heavy Truck suction/septic tank truck?
Dongfeng Dongfeng H5 Heavy Truck is an export-oriented suction/septic tank truck lineup with about 8 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Dongfeng H5 Heavy Truck suction/septic tank truck?
Dongfeng H5 Heavy Truck suction/septic tank truck export reference is about $29,861 – $39,306. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Dongfeng H5 Heavy Truck suction/septic tank truck cover?
Dongfeng H5 Heavy Truck suction/septic tank truck mainly covers: Drive: 6x4 / 8x4; Horsepower: 270 hp / 350 hp; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Dongfeng H5 Heavy Truck suction/septic tank truck?
For Dongfeng H5 Heavy Truck suction/septic tank truck: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is suction/septic tank truck typically used for?
suction/septic tank truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Dongfeng H5 Heavy Truck suction/septic tank truck include?
Dongfeng H5 Heavy Truck suction/septic tank truck currently lists about 8 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dongfeng H5 Heavy Truck suction/septic tank truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
