Xinchai XC4N20Q3U66 90 hp 2L China III Diesel Engine
EXW
Export quote
Xinchai 4N20Q Series engine
Main model photos
1 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Xinchai XC4N20Q3U66 90 hp 2L China III Diesel Engine | 90hp / China III / Euro III | ||
| Xinchai XC4N20Q3U55 75 hp 2L China III Diesel Engine | 75hp / China III / Euro III |
Xinchai XC4N20Q3U55 75 hp 2L China III Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: 4N20Q Series
Engine manufacturer: Zhejiang Xinchai Power
Suitable Range: Compatible with 0.5–1.5 ton light trucks, minibuses
Min. fuel consumption at full load: 225g/kW.h
Engine net weight: 240kg
Engine Dimensions: 700.5×635×655mm
Compression ratio: 18:1
Bore × Stroke: 85x88mm
Engine Brand: Xinchai
Engine Model: XC4N20Q3U66 / XC4N20Q3U55
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 1.997L
Emission standard: China III / Euro III
Max output power: 66 / 55kW
Max hp: 90 / 75Horsepower
Max torque: 245 / 205N·m
Max torque speed: 1800-2100rpm
Rated speed: 3000rpm
Engine Type: Inline, water-cooled, 4-stroke, direct injection, turbocharged & intercooled
FAQ
What kind of truck is Xinchai Xinchai 4N20Q Series engine?
Xinchai Xinchai 4N20Q Series is an export-oriented engine lineup with about 2 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Xinchai 4N20Q Series engine cover?
Xinchai 4N20Q Series engine mainly covers: Horsepower: 75 hp / 90 hp; Emission: China III / Euro III; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Xinchai 4N20Q Series engine?
For Xinchai 4N20Q Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Xinchai 4N20Q Series engine include?
Xinchai 4N20Q Series engine currently lists about 2 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Xinchai 4N20Q Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
