SANY Heavy-duty 480hp 8X4(12 wheels) 8.8m Dump Truck (China VI)
EXW
Export quote
SANY dump truck Dump Trucks
Main model photos
35 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| SANY Heavy-duty 480hp 8X4(12 wheels) 8.8m Dump Truck (China VI) | 8x4 / 480hp / China VI | ||
| SANY Heavy-duty 480hp 8X4(12 wheels) 8.6m Dump Truck (China VI) | 8x4 / 480hp / China VI | ||
| SANY Heavy-duty 480hp 8X4(12 wheels) 8.5m Dump Truck (China VI) | 8x4 / 480hp / China VI | ||
| SANY Heavy-Duty 480hp 8X4(12 wheels) 8.2m Dump Truck (China VI) | 8x4 / 480hp / China VI | ||
| SANY Heavy-Duty 480hp 8X4(12 wheels) 7.8m Dump Truck (China VI) | 8x4 / 480hp / China VI |
SANY Heavy-duty 480hp 8X4(12 wheels) 8.6m Dump Truck (China VI)
EXW
Export quote
SANY Heavy-duty 480hp 8X4(12 wheels) 8.5m Dump Truck (China VI)
EXW
Export quote
SANY Heavy-Duty 480hp 8X4(12 wheels) 8.2m Dump Truck (China VI)
EXW
Export quote
SANY Heavy-Duty 480hp 8X4(12 wheels) 7.8m Dump Truck (China VI)
EXW
Export quote
Series Specs
Basic Info
Model code (announced): SYM3315ZZX1F / SYM3250ZZX1F / SYM3251ZZX1F / SYM3312ZZX1F / SYM3311ZZX1F / SYM3310ZZX1F / SYM3313ZZX1F / SYM3257ZZX1E / SYM3319ZZX1E / SYM3310ZZX1E / SYM3318ZZX1E
Drive type: 8X4 / 6X4
Wheelbase: 2000+4600+1400 / 2000+4400+1400 / 2000+3900+1400 / 2000+4200+1400 / 5000+1400 / 4600+1400 / 4200+1400 / 2000+3300+1400 / 2000+2500+1400 / 3600+1400 / 1800+2500+1350mm
Engine Model: SANYD13C6-480E0 / SANYD13C6-520E0 / SANYD13C6-560E0 / YuchaiYCK11430-60 / YuchaiYCK11460-60 / YuchaiYCK08330-60 / YYuchaiCK08350-60 / SANYD12C5-462E0 / YuchaiYCK08350-60 / SANYD12C5-490E0 / SANYD12C5-517E0 / SANYD12C5-435E0 / SANYD09C5-380E0 / SANYD09C5-340E0 / SANYD09C5-320E0
Transmission Model: Fast Gear12JSDX240T-B / Fast Gear 12-speed / Fast Gear 10-Speed / Fast Gear12JSDX240T / Fast Gear12JSD160TA / Fast Gear12JSD160T
Cab length: 11.8 / 11.6 / 11.2 / 11 / 10.7 / 10.6 / 11.5 / 10 / 9.5 / 9.8 / 9 / 8.8 / 8.85 / 9.2 / 8.4 / 8.9m
Cab width: 2.54 / 2.51m
Cab height: 3.65 / 3.58 / 3.35 / 3.55 / 3.28 / 3.06 / 3.25 / 3.15 / 3.48m
Front track width: 2048/2048 / 2048 / 2046/2046mm
rear track: 1860/1860mm
Curb Weight: 15.5 / 12.5 / 12.98 / 12.8 / 12.43 / 15.4 / 14.77ton
Rated payload: 15.37 / 12.37 / 17.89 / 18.07 / 12.44 / 15.47 / 16.1ton
GVWR: 31 / 25ton
Origin: Changsha, Hunan
tonnage class: Heavy truck
Approach angle: 18 / 17°
departure angle: 22 / 24 / 20°
Version: Heavy-duty version / composite version / Standard Load Edition / Elite Lite
Energy Type: Diesel
Engine parameters
Engine Brand: SANY / Yuchai
Number of cylinders: 6cylinder
Displacement: 12.94 / 1.94 / 10.98 / 7.7 / 12.12 / 8.7L
Emission standard: China VI / China V
Max output power: 353 / 382 / 412 / 316 / 339 / 243 / 257 / 340 / 360 / 380 / 320 / 280 / 250 / 235kW
Max hp: 480 / 520 / 560 / 430 / 460 / 330 / 350 / 462 / 490 / 517 / 435 / 380 / 340 / 320Horsepower
Max torque: 2100 / 2200 / 1350 / 1450 / 2150 / 1529 / 1479 / 1379N·m
Max torque speed: 1000-1400 / 1000-1500 / 1200-1700 / 1300-1500rpm
Rated speed: 1900 / 2200 / 2100rpm
Engine Type: High-pressure common rail + EGR + DOC + DPF + SCR + ASC
Transmission Parameters
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 12 / 10Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
hydraulic cylinder brand & model: Sany/Jiaheng/PENDA
Unloading Type: Dump type
Cargo box type: Dump type
Cargo box length: 8.8 / 8.6 / 8.5 / 8.2 / 7.8 / 7.6 / 7 / 6.5 / 8 / 6.8 / 5.8 / 5.6 / 5.4 / 6.2 / 7.4m
Cargo box width: 2.35 / 2.4 / 2.36m
Cargo box height: 1.5m
Cab parameters
Cab: CB318 Flat Roof / CB318 / 318 flat top
FAQ
What kind of truck is SANY Truck SANY dump truck Dump Trucks?
SANY Truck SANY dump truck is an export-oriented Dump Trucks lineup with about 57 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for SANY dump truck Dump Trucks?
SANY dump truck Dump Trucks export reference is about $39,583 – $55,556. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does SANY dump truck Dump Trucks cover?
SANY dump truck Dump Trucks mainly covers: Drive: 8x4; Horsepower: 480 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in SANY dump truck Dump Trucks?
For SANY dump truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does SANY dump truck Dump Trucks include?
SANY dump truck Dump Trucks currently lists about 57 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for SANY dump truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
