Radar Auto RD6 2024 Tech Edition 2WD Double Cab Electric Pickup 86kWh
EXW
Export quote
Geely Horizon pickup truck
Main model photos
41 photos
Models
On sale
Radar Auto RD6 2024 Tech Edition 2WD Double Cab Electric Pickup 63kWh
EXW
Export quote
Radar Auto 2024 Horizon Max Edition 4WD Double Row Pure Electric Pickup 73kWh
EXW
Export quote
Radar Auto 2024 Horizon Air Edition 4WD Double Row Pure Electric Pickup 86kWh
EXW
Export quote
Radar Auto 2024 Horizon Air Edition 4WD Double Row Pure Electric Pickup 73kWh
EXW
Export quote
Series Specs
Basic Info
Model code (announced): ZB1030BEVRSD13 / ZB1030BEVRSD12
Drive type: 2WD / 4WD
Wheelbase: 3120mm
Min. turning diameter: 12.2 / 6.1m
Front/rear track width: Front: 1614mm; Rear: 1620
Cab length: 5.26m
Cab width: 1.9m
Cab height: 1.865 / 1.88 / 1.83m
Approach/departure angle: 20/24°
CLTC range: 560 / 415 / 460 / 520 / 410 / 632 / 550 / 400km
Curb Weight: 2.065 / 2.15ton
Min ground clearance: 221 / 230cm
Rated payload: 0.45 / 0.4ton
GVWR: 2.84 / 2.875ton
Max. speed: 185 / 190km/h
Origin: Zibo, Shandong
Model Year: 2024 Model
Front/rear suspension: 0.96/1.18m
Version: Tech Edition / Horizon Max Edition / Horizon Air Edition / Chuangyeban / Yueye Edition / Industry Edition B / Yuexiang Edition / Chuangke Edition / Industry Edition A / Qihang Edition
Energy Type: Electric
Chassis Specs
Front axle suspension type: MacPherson independent suspension
rear axle suspension type: Multi-link independent suspension
Chassis Structure: Load-bearing
power steering type: Electric Power Steering
Cargo box parameters
Cargo box type: stake body
Cargo box length: 1.525m
Cargo box width: 1.45m
Cargo box height: 0.54m
Cab parameters
seating capacity: 5Personnel
Seat rows: Double cab
Wheel brake
Front brake type: Ventilated disc brakes / Disc
rear brake type: Disc
Front tire specification: 225/65R17 / 235/60R18 / 235/65R17
Safety features
keyless start system:
Driver airbag:
Tire Pressure Monitoring:
passenger airbag:
Front side airbag:
rear side airbag:
Seat belt reminder:
FAQ
What kind of truck is Geely Geely Horizon pickup truck?
Geely Geely Horizon is an export-oriented pickup truck lineup with about 13 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Geely Horizon pickup truck?
Geely Horizon pickup truck export reference is about $20,250 – $37,333. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Geely Horizon pickup truck cover?
Geely Horizon pickup truck mainly covers: Drive: 2WD / 4WD. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Geely Horizon pickup truck?
For Geely Horizon pickup truck, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is pickup truck typically used for?
For pickup truck, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Geely Horizon pickup truck include?
Geely Horizon pickup truck currently lists about 13 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Geely Horizon pickup truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
