Dongfeng H7 8X4(12 wheels) 6.8m cab-over-chassis swap battery electric dump truck CATL 400.61kWh
EXW
From $91,667
Export quote
Dongfeng Chenglong H7 Heavy Truck electric dump
Main model photos
1,421 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng H7 8X4(12 wheels) 6.8m cab-over-chassis swap battery electric dump truck CATL 400.61kWh | 8x4 | From $91,667 | |
| Dongfeng H7 8X4(12 wheels) 6.5m cab-over-chassis swap battery electric dump truck CATL 400.61kWh | 8x4 | From $91,667 | |
| Dongfeng H7 8X4(12 wheels) 8.1m Crew Cab Battery Swap Pure Electric Dump Truck CATL 600.92kWh | 8x4 | From $109,722 | |
| Dongfeng H7 8X4(12 wheels) 8m Crew Cab Battery Swap Pure Electric Dump Truck CATL 600.92kWh | 8x4 | From $109,722 | |
| Dongfeng H7 8X4(12 wheels) 9m Day Cab Pure Electric Dump Truck CATL 400.61kWh | 8x4 | From $88,889 |
Dongfeng H7 8X4(12 wheels) 6.5m cab-over-chassis swap battery electric dump truck CATL 400.61kWh
EXW
From $91,667
Export quote
Dongfeng H7 8X4(12 wheels) 8.1m Crew Cab Battery Swap Pure Electric Dump Truck CATL 600.92kWh
EXW
From $109,722
Export quote
Dongfeng H7 8X4(12 wheels) 8m Crew Cab Battery Swap Pure Electric Dump Truck CATL 600.92kWh
EXW
From $109,722
Export quote
Dongfeng H7 8X4(12 wheels) 9m Day Cab Pure Electric Dump Truck CATL 400.61kWh
EXW
From $88,889
Export quote
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng Liuqi Chenglong H7 8X4(12 wheels) pure electric dump truck 423.936kWh | 8x4 |
Series Specs
Basic Info
Model code (announced): LZ3310H7FZBEV01 / LZ3310H5FZBEV171 / LZ3311H5FZBEV01 / LZ3310H5FZBEV161 / LZ3250H5DZBEV01 / LZ3310H5FZBEV152
Drive type: 8X4 / 6X4
Wheelbase: 2050+3750+1350 / 2050+4750+1350 / 1800+5000+1350 / 1800+4650+1350 / 1800+4400+1350 / 2050+4150+1350 / 4500+1350 / 4300+1350mm
Cab length: 10.715 / 10.515 / 11.925 / 11.825 / 11.575 / 11.475 / 11.115 / 10.915 / 9.325 / 9.125 / 9.025 / 11.225m
Cab width: 2.5 / 2.545m
Cab height: 3.45 / 3.8 / 3.65m
CLTC range: 150 / 350km
Curb Weight: 21.4 / 25 / 24 / 20 / 19 / 23 / 21ton
Rated payload: 9.47 / 5.87 / 6.87 / 4.87 / 7.87 / 9.87ton
GVWR: 31 / 25ton
Max. speed: 89km/h
Origin: Liuzhou, Guangxi
tonnage class: Heavy truck
Remarks: Rear-mounted battery / Side-mounted battery / Battery side-mounted
Energy Type: Electric
electric motor
Motor 2 Brand: Tebest
Motor 2 Model: TZ220XSTPG69
Motor 1 Brand: Fast Gear / Lv Kong / Tebest
Motor 1 Model: TZ375XSF60-FS01 / TZ460XS-LKM3004 / TZ445XSSF-SZF602 / TZ220XSTPG69
Motor Type: Permanent magnet synchronous motor
total rated power: 330 / 400 / 375kW
Peak power: 460 / 550 / 560 / 230kW
Motor 2 Peak Power: 230kW
Battery/Charging
Charging method: Fast Charge
Battery Brand: CATL / Guoxuan / Guoxuan High-Tech
Battery type: Lithium Iron Phosphate Battery
fast charge time:
Battery capacity: 400.61 / 600.92 / 405.5 / 608.26 / 423.936kWh
Transmission Parameters
Number of gears: 6 / 4Gear
shift type: AMT manual/auto
Transmission Model: Fast Gear6E240 / J4S280 / F6E240A-D transmission / Tebest TS-0406DF / TS-0406DF
Transmission Brand: Fast Gear
Number of Reverse Gears:
Cargo box parameters
Cargo box type: Dump type / Dump
Cargo box length: 6.8 / 6.5 / 8.1 / 8 / 9 / 8.8 / 8.6 / 8.2 / 7.2 / 7 / 6.3 / 6.2 / 8.7 / 8.4m
Cargo box width: 2.3 / 2.35m
Cargo box height: 1.5 / 1.3m
Cab parameters
Cab: H71V / H73WE
seating capacity: 2Personnel
Seat rows: Sleeper cab
FAQ
What kind of truck is Dongfeng Dongfeng Chenglong H7 Heavy Truck electric dump truck?
Dongfeng Dongfeng Chenglong H7 Heavy Truck is an export-oriented electric dump truck lineup with about 38 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Dongfeng Chenglong H7 Heavy Truck electric dump?
Dongfeng Chenglong H7 Heavy Truck electric dump export reference is about $86,111 – $109,722. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Dongfeng Chenglong H7 Heavy Truck electric dump cover?
Dongfeng Chenglong H7 Heavy Truck electric dump mainly covers: Drive: 8x4. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Dongfeng Chenglong H7 Heavy Truck electric dump?
For Dongfeng Chenglong H7 Heavy Truck electric dump: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is electric dump truck typically used for?
electric dump truck is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Dongfeng Chenglong H7 Heavy Truck electric dump include?
Dongfeng Chenglong H7 Heavy Truck electric dump currently lists about 38 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dongfeng Chenglong H7 Heavy Truck electric dump?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
