Dongfeng F5 165hp 4X2(6 wheels) green sprinkler truck (Yandi brand)
EXW
From $22,917
Export quote
Dongzheng (Yandi) Dongfeng Chassis water sprinkler
Main model photos
27 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng F5 165hp 4X2(6 wheels) green sprinkler truck (Yandi brand) | 4x2 / 165hp / China VI | From $22,917 | |
| Dongfeng Yuhu 129hp 4X2(6 wheels) Water Sprinkler Truck (Yandi Brand) | 4x2 / 129hp / China V | From $18,750 | |
| Dongfeng Yuhu 180hp 4X2(6 wheels) Water Sprinkler Truck (Yandi Brand) | 4x2 / 180hp / China V | From $20,556 | |
| Dongfeng Yuhu 190hp 4X2(6 wheels) Water Sprinkler Truck (Yandi Brand) | 4x2 / 190hp / China V | From $22,778 | |
| Dongfeng Yuhu 170hp 4X2(6 wheels) Water Sprinkler Truck (Yandi Brand) | 4x2 / 170hp / China V | From $20,694 |
Dongfeng Yuhu 129hp 4X2(6 wheels) Water Sprinkler Truck (Yandi Brand)
EXW
From $18,750
Export quote
Dongfeng Yuhu 180hp 4X2(6 wheels) Water Sprinkler Truck (Yandi Brand)
EXW
From $20,556
Export quote
Dongfeng Yuhu 190hp 4X2(6 wheels) Water Sprinkler Truck (Yandi Brand)
EXW
From $22,778
Export quote
Dongfeng Yuhu 170hp 4X2(6 wheels) Water Sprinkler Truck (Yandi Brand)
EXW
From $20,694
Export quote
Series Specs
Basic Info
Cab dimensions: 7.7×2.5×3.2 / 7.7×2.48×3.25 / 8.2×2.48×3.05 / 7.35×2.48×3.05m
Truck Type: landscaping sprinkler truck / Water Sprinkler Truck
Drive type: 4X2
Wheelbase: 3950 / 5100 / 4500mm
Vehicle origin: Suizhou, Hubei
Front track width: 1820 / 1810 / 1910mm
rear track: 1800 / 1860mm
Curb Weight: 6.02 / 5.805 / 6.555ton
Rated payload: 9.785 / 9.6 / 9.25ton
Max. speed: 88 / 90km/h
Front/rear suspension: 1.25/2.3 / 1.45/2.3 / 1.45/2.25m
Energy Type: Diesel
Body Parameters
Tank Dimensions (L×W×H): 4.2×2.35×1.46 / 4.3×2.25×1.45 / 4.2×2.35×1.45m
Vehicle certification code: SZD5166GPSEL6 / SZD5167GSSE5V / SZD5168GSSE5
Body Brand: Yandi brand
Engine parameters
Engine Model: YuchaiYCY30165-60 / Yunnei PowerYN38CRE1 / YuchaiYC6JA180-50 / DongfengISB190 50 / DongfengISB170 50 / YuchaiYCD4D4S-140 / YuchaiYC4E160-56
Number of cylinders: 4 / 6cylinder
Displacement: 2.97 / 3.76 / 6.87 / 5.9 / 4.26L
Emission standard: China VI / China V
Max output power: 121 / 95 / 132 / 140 / 125 / 105 / 118kW
Max hp: 165 / 129 / 180 / 190 / 170 / 140 / 160Horsepower
Rated speed: 2800 / 3000 / 2300 / 2500 / 2600rpm
Engine Type: High-pressure common rail + EGR + DOC + DPF + SCR + ASC / 4-cylinder inline, 8-valve, turbocharged intercooled, high-pressure common rail fuel injection / Vertical, inline, water-cooled, four-stroke / SCR
Cargo box parameters
Box volume: 10.8 / 10 / 9.7m³
Chassis Specs
Chassis Brand: Dongfeng
Chassis Series: Huashen F5 / Yuhu / Huashen T3 / Huashen T5
Chassis Model: EQ1160GL6DJ / EQ1168GLVJ / EQ1168GLJ4
Leaf spring count: 9/11+8 / 9/10+8 / 9/11+8,8/10+8,8/11+8,9/10+8,3/4+3
Transmission Parameters
Number of gears: 8 / 6 / 5Gear
Transmission Model: Fast Gear 8-speed / WLY 6-speed / Fast Gear small 8-speed / Dongfeng 6-speed / Dongfeng 5-speed / Dongfeng 8-speed
Tire
Tire Size: 9.00R20 / 9.00R20 16PR / 10.00R20 16PR
Number of tires: 6pcs
FAQ
What kind of truck is Dongzheng (Yandi) Dongzheng (Yandi) Dongfeng Chassis water sprinkler truck?
Dongzheng (Yandi) Dongzheng (Yandi) Dongfeng Chassis is an export-oriented water sprinkler truck lineup with about 11 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Dongzheng (Yandi) Dongfeng Chassis water sprinkler?
Dongzheng (Yandi) Dongfeng Chassis water sprinkler export reference is about $17,500 – $23,056. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Dongzheng (Yandi) Dongfeng Chassis water sprinkler cover?
Dongzheng (Yandi) Dongfeng Chassis water sprinkler mainly covers: Drive: 4x2; Horsepower: 129 hp / 165 hp / 170 hp / 180 hp / 190 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Dongzheng (Yandi) Dongfeng Chassis water sprinkler?
For Dongzheng (Yandi) Dongfeng Chassis water sprinkler: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is water sprinkler truck typically used for?
water sprinkler truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Dongzheng (Yandi) Dongfeng Chassis water sprinkler include?
Dongzheng (Yandi) Dongfeng Chassis water sprinkler currently lists about 11 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dongzheng (Yandi) Dongfeng Chassis water sprinkler?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
