FAW Jiefang Hu V 160hp 4X2(6 wheels) Wrecker Truck (Chusheng Brand)
EXW
From $20,000
Export quote
Chusheng FAW Jiefang Chassis Tow Truck
Main model photos
25 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| FAW Jiefang Hu V 160hp 4X2(6 wheels) Wrecker Truck (Chusheng Brand) | 4x2 / 160hp / China VI | From $20,000 | |
| FAW Jiefang J6F 130 hp 4X2(6 wheels) Wrecker Truck (Chusheng Brand) | 4x2 / 130hp / China VI | From $18,333 | |
| FAW Jiefang HuV 120 hp 4X2(6 wheels) Wrecker Truck (Chusheng Brand) | 4x2 / 120hp / China VI | From $16,944 | |
| FAW Jiefang Hu V 130 hp 4X2(6 wheels) Wrecker (Chusheng Brand) | 4x2 / 130hp / China V | From $17,222 | |
| FAW Jiefang Hu V 130 hp 4X2(6 wheels) Wrecker (Chusheng Brand) | 4x2 / 130hp / China V | From $15,972 |
FAW Jiefang J6F 130 hp 4X2(6 wheels) Wrecker Truck (Chusheng Brand)
EXW
From $18,333
Export quote
FAW Jiefang HuV 120 hp 4X2(6 wheels) Wrecker Truck (Chusheng Brand)
EXW
From $16,944
Export quote
FAW Jiefang Hu V 130 hp 4X2(6 wheels) Wrecker (Chusheng Brand)
EXW
From $17,222
Export quote
FAW Jiefang Hu V 130 hp 4X2(6 wheels) Wrecker (Chusheng Brand)
EXW
From $15,972
Export quote
Series Specs
Basic Info
Cab dimensions: 7.59×2.3×2.4 / 5.995×2.31×2.35 / 5.995×2.3×2.43 / 5.995×2.3×2.4 / 7.52×2.3×2.47m
Type: Tow truck (towing one vehicle)
Drive type: 4X2
Front/rear track width: Front: 1726mm; Rear: 1678 / Front: 1580mm; Rear: 1480 / Front track: 1510mm; Rear track: 1475 / Front: 1510mm; Rear: 1475 / Front track: 1640mm; Rear track: 1540 / Front track: 1665mm; Rear track: 1590
Wheelbase: 3900 / 3300mm
GVWR (Gross Vehicle Weight Rating): 5.37 / 3.8 / 3.78 / 4.95ton
GVWR: 8.28 / 4.495ton
Max. speed: 100 / 110 / 115km/h
Front/rear suspension: 1.155/2.535 / 1.15/1.58 / 1.15/1.545 / 1.15/2.47m
Energy Type: Diesel
Body Parameters
Lifting capacity: 2715 / 500 / 520 / 3135kg
Vehicle certification code: CSC5080TQZPCA6 / CSC5040TQZPCA6 / CSC5045TQZPCA5 / CSC5047TQZPCA5 / CSC5081TQZCA5
Body Brand: Chusheng Brand
Others: Multifunction steering wheel, cruise control, ABS, A/C, power windows + central door lock, PTO
Engine parameters
Engine Model: WeichaiWP3NQ160E61 / WeichaiWP2.3NQ130E61 / QuanchaiH20-120E60 / CSC5045TQZPCA5 / XichaiCA4DB1-13E5 / WeichaiWP2.3Q110E50 / DachaiCA4DC3-12E5 / WeichaiWP3.7Q130E50
Displacement: 2.97 / 2.29 / 2 / 2.21 / 3 / 3.66L
Emission standard: China VI / China V
Max output power: 118 / 96 / 90 / 95 / 81 / 91kW
Max hp: 160 / 130 / 120 / 110Horsepower
Chassis Specs
Chassis Brand: FAW Jiefang
Chassis Series: Hu V / J6F
Chassis Model: CA1080P40K59L3BE6A84 / CA1040P40K61L2BE6A84 / CA1045P40K17L1BE5A84 / CA1047P40K50L1BE5A84 / CA1081P40K2L2BE5A84
rear axle description: Ratio 5.571
Leaf spring count: 3/3+3,3/7+9,3/10+4,7/10+4,7/10+3,3/4+4 / 3/3+3,3/7+3,7/7+3,7/10+3,3/7+9,3/10+4,7/10+3 / 7/10+3,3/3+4,3/3+3,3/7+9,3/10+4,3/4+4,7/10+4,4/7+9 / 3/4+3,7/7+3,3/7+9,3/7+3,3/3+3 / 7/10+3 / 7/10+3,3/3+4
Transmission Parameters
Number of gears: 6 / 5Gear
Transmission Model: WLYWLY6TS40 / WLYWLY6G40 / WLYWLY5TS32C / WLYWLY5TS32 / WLYWLY6T115
Number of Reverse Gears:
Tire
Tire Size: 7.50R16,8.25R16 / 6.50R16 12PR,7.00R16 8PR,7.50R16 8PR / 7.00-16 8PR,7.00R16 8PR,7.50-16 6PR,7.50R16 6PR,8.25-16 6PR,8.25R16 6PR / 6.50-16,6.50R16,7.00-16,7.00R16 / 7.50R16
Number of tires: 6pcs
FAQ
What kind of truck is Chusheng Chusheng FAW Jiefang Chassis Tow Truck?
Chusheng Chusheng FAW Jiefang Chassis is an export-oriented Tow Truck lineup with about 9 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Chusheng FAW Jiefang Chassis Tow Truck?
Chusheng FAW Jiefang Chassis Tow Truck export reference is about $15,278 – $20,000. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Chusheng FAW Jiefang Chassis Tow Truck cover?
Chusheng FAW Jiefang Chassis Tow Truck mainly covers: Drive: 4x2; Horsepower: 120 hp / 130 hp / 160 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Chusheng FAW Jiefang Chassis Tow Truck?
For Chusheng FAW Jiefang Chassis Tow Truck: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is Tow Truck typically used for?
Tow Truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Chusheng FAW Jiefang Chassis Tow Truck include?
Chusheng FAW Jiefang Chassis Tow Truck currently lists about 9 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Chusheng FAW Jiefang Chassis Tow Truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
