Foton AumanETX 6 Series 336 hp 6X4(10 wheels) LNG Water Sprinkler Truck Chassis
EXW
Export quote
Foton Auman ETX Heavy Truck water sprinkler truck
Main model photos
853 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Foton AumanETX 6 Series 336 hp 6X4(10 wheels) LNG Water Sprinkler Truck Chassis | 6x4 / 336hp / China V | ||
| Foton AumanETX 3 Series 225 hp 4X2(6 wheels) LNG Water Sprinkler Truck Chassis | 4x2 / 225hp / China V | ||
| Foton AumanETX 5 Series 245 hp 6X4(10 wheels) Water Sprinkler Truck Chassis | 6x4 / 245hp / Special Beijing V | ||
| Foton AumanETX 5 Series 210 hp 6X2(8 wheels) Water Sprinkler Truck Chassis | 6x2 / 210hp / Special Beijing V | ||
| Foton Auman ETX 3 Series 210 hp 4X2(6 wheels) Water Sprinkler Truck | 4x2 / 210hp / Special Beijing V |
Foton AumanETX 3 Series 225 hp 4X2(6 wheels) LNG Water Sprinkler Truck Chassis
EXW
Export quote
Foton AumanETX 5 Series 245 hp 6X4(10 wheels) Water Sprinkler Truck Chassis
EXW
Export quote
Foton AumanETX 5 Series 210 hp 6X2(8 wheels) Water Sprinkler Truck Chassis
EXW
Export quote
Foton Auman ETX 3 Series 210 hp 4X2(6 wheels) Water Sprinkler Truck
EXW
Export quote
Series Specs
Basic Info
Cab dimensions: 8.425×2.44×2.76 / 9.507×2.495×2.948 / 10.412×2.495×2.95 / 8.625×2.47×2.75 / 9.507×2.495×3.37 / 10.875×2.495×3.015 / 6.635×2.44×2.7 / 8.3×2.48×3 / 8.265×2.5×2.76 / 7.86×2.47×2.83 / 9.707×2.5×3.12 / 8.345×2.44×2.7m
Drive type: 6X4 / 4X2 / 6X2
Truck Type: Water Sprinkler Truck
Vehicle origin: Beijing
Wheelbase: 4300+1350 / 4500 / 4300+1300 / 1860+4800 / 1840+4800mm
Front track width: 2010 / 1883 / 1960 / 1900/1900mm
rear track: 1860/1860 / 1847mm
Curb Weight: 6.08 / 8.05 / 7.4 / 7 / 8.25 / 9.25 / 6.305 / 8.32 / 7.33 / 11.45ton
Rated payload: 8.87 / 15.62 / 9.565 / 7.085 / 8.475 / 13.42ton
Max. speed: 85 / 80 / 94 / 90 / 83km/h
Front/rear suspension: 1.365/2.56 / 1.532/2.375 / 1.532/2.22 / 1.365/2.85 / 1.365/1.47 / 1.365/2.435 / 1.365/2.4 / 1.45/1.91 / 1.532/2.575m
Energy Type: LNG (liquefied natural gas) / Diesel
Engine parameters
Local Emission Standard: Special Beijing V
Injection System: Natural gas / Common Rail
Engine Model: WeichaiWP10NG336E50 / YuchaiYC6J225N-52 / DongfengISD245 50 / DongfengISDe210 50 / DongfengISDe270 40 / DongfengISDe245 40 / DongfengISDe210 40 / FotonIE6D210-e4ES / DongfengISB210 40 / DongfengISB190 40
Number of cylinders: 6cylinder
Displacement: 9.7 / 6.494 / 6.7 / 6 / 5.9L
Emission standard: China V / Special Beijing V / China IV
Max output power: 247 / 166 / 180 / 155 / 198 / 140kW
Max hp: 336 / 225 / 245 / 210 / 270 / 190Horsepower
Rated speed: 1900 / 2500rpm
Engine Type: Inline, water-cooled, wet cylinder liner, turbocharged intercooled, electronically controlled premixed, spark plug ignition, lean burn / Natural gas / Water-cooled, electronic high-pressure common rail, turbocharged intercooled, SCR / Electronic control high-pressure common rail
Body Parameters
Sprinkling width: 20m
Vehicle certification code: BJ5163GSS-AB / BJ5252GSS-XB / BJ5163GSS-XA / BSZ5163GSSC5T045 / HFV5250GSSBJ4
Body Brand: FotonAuman / Fulong Continental / Zhongyan brand
Cargo box parameters
Box volume: 9.4 / 9.97m³
Chassis Specs
Chassis Brand: FotonAuman
Chassis Series: AumanETX
Chassis Model: BJ1253VMPCE-XA / BJ5163XXY-XQ / BJ1252VMPHH-AB / BJ5163XXY-XP / BJ1252VMPHE-XA / BJ1253VMPHH-XA / BJ5163ELFHD
Frame Dimensions: 280 / 250mm
Steering gear: Domestic
rear axle description: 457 rear axle / 10T rear axle / 10T
Axle ratio: 5.286 / 5.571 / 5.143 / 6.5 / 4.875 / 5.833 / 6.166
Leaf spring count: 10/10+8 / 9/12 / 13/14/9+6 / 10/10 / 10/10/10+9 / 10/10/9+6
clutch: Φ430 / Φ395
Transmission Parameters
Number of gears: 9 / 6 / 8 / 7Gear
Transmission Model: Fast Gear9JS1135TA(Q) / DachiDC6J95TA(Q) / Fast Gear8JS105TA(Q) / DachiDC7J100TA(Q) / Fast Gear8JS118T-B(Q) / DC6J95TA(Q) / Fast Gear9JS135TA / DachiDC6J95TA / Fast Gear8JS105TA / DC7J100TA / DC6J95TA
Cab parameters
Cab: ETX-2490 flat roof / ETX-2200 flat roof / ETX-2420 flat roof
Tire
Tire Size: 11.00-20，11.00R20，10.00-20，10.00R20 / 10.00R20 / 10.00-20，10.00R20，11.00-20，11.00R20 / 10.00-20，10.00R20，10R22.5 / 10.00-20，10.00R20，9.00R20 / 11.00R20 / 9.00R20
Number of tires: 10 / 6 / 8pcs
FAQ
What kind of truck is Auman Foton Auman ETX Heavy Truck water sprinkler truck?
Auman Foton Auman ETX Heavy Truck is an export-oriented water sprinkler truck lineup with about 20 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Foton Auman ETX Heavy Truck water sprinkler truck cover?
Foton Auman ETX Heavy Truck water sprinkler truck mainly covers: Drive: 4x2 / 6x2 / 6x4; Horsepower: 210 hp / 225 hp / 245 hp / 336 hp; Emission: China V / Special Beijing V; Fuel: Diesel / LNG (liquefied natural gas). Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Foton Auman ETX Heavy Truck water sprinkler truck?
For Foton Auman ETX Heavy Truck water sprinkler truck: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is water sprinkler truck typically used for?
water sprinkler truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Foton Auman ETX Heavy Truck water sprinkler truck include?
Foton Auman ETX Heavy Truck water sprinkler truck currently lists about 20 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Foton Auman ETX Heavy Truck water sprinkler truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
