Jinhu Auto EV48 Shudu Edition 3T 4.86m Pure Electric Panel Van 41.86kWh
EXW
From $23,444
Export quote
Jinhu Auto JMC Jinhu EV48 Electric Panel Van
Main model photos
20 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Jinhu Auto EV48 Shudu Edition 3T 4.86m Pure Electric Panel Van 41.86kWh | — | From $23,444 | |
| Jinhu Auto EV48 Smart Enjoy Edition 3T 4.86m Pure Electric Panel Van 38.64kWh | — | From $23,444 | |
| Jinhu Auto EV48 Smart Edition 3T 4.86m Pure Electric Panel Van 38.64kWh | — | From $27,194 | |
| Jinhu Auto EV48 Smart Enjoy Edition 3T 4.86m Electric Panel Van 41.86kWh | — | From $23,861 | |
| Jinhu Auto EV48 Smart Edition 3T 4.86m Electric Panel Van 41.86kWh | — | From $23,444 |
Jinhu Auto EV48 Smart Enjoy Edition 3T 4.86m Pure Electric Panel Van 38.64kWh
EXW
From $23,444
Export quote
Jinhu Auto EV48 Smart Edition 3T 4.86m Pure Electric Panel Van 38.64kWh
EXW
From $27,194
Export quote
Jinhu Auto EV48 Smart Enjoy Edition 3T 4.86m Electric Panel Van 41.86kWh
EXW
From $23,861
Export quote
Jinhu Auto EV48 Smart Edition 3T 4.86m Electric Panel Van 41.86kWh
EXW
From $23,444
Export quote
Series Specs
Basic Info
Model code (announced): CDK5030XXYBEV / JX5039XXYTEB-MBEV / JX5039XXYTEA-MBEV
Wheelbase: 3160mm
Cab length: 4.86m
Cab width: 1.75m
Cab height: 1.99m
warranty policy: 3-year/100,000 km vehicle warranty
CLTC range: 305 / 275km
Curb Weight: 1.495 / 1.48ton
Rated payload: 1.375 / 1.39ton
GVWR: 3ton
Max. speed: 100km/h
Front/rear suspension: 0.64/1.06m
Version: Shudu Edition / Smart Edition / Smart Travel Edition
electric motor
Motor 1 Brand: Inovance
Motor 1 Model: TZ180XS141 / TZ180XS000
Motor Type: Permanent magnet synchronous motor
Energy Type: Electric
total rated power: 30 / 32kW
Peak power: 60kW
total peak torque: 220N·m
Battery/Charging
Charging method: Fast charge: <0.75h; Slow charge: ≤14h
Battery Brand: CATL
Battery type: Lithium Iron Phosphate Battery
Battery capacity: 41.86 / 38.64kWh
Body parameters
Cargo box volume: 6.2
Max body depth: 2.845 / 2.827
Max body width: 1.525
Cargo Box Height: 1.42 / 1.381
Chassis Specs
steering assist type: Electric power steering
Front suspension type: Independent suspension / MacPherson independent suspension
rear suspension type: Leaf spring
Body Parameters
Seat count: 2Seats
Door Parameters
Number of Doors: 4
side door type: Single-side manual
Tailgate type: tailgate
Wheel brake
Front brake type: Disc brake
rear brake type: drum brake
Front tire specification: 185R14LT / 195/70R15LT
Cab parameters
Seat rows:
Safety features
Tire Pressure Monitoring:
FAQ
What kind of truck is Jinhu Auto JMC Jinhu EV48 Electric Panel Van?
Jinhu Auto JMC Jinhu EV48 is an export-oriented Electric Panel Van lineup with about 5 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Jinhu Auto JMC Jinhu EV48 Electric Panel Van?
Jinhu Auto JMC Jinhu EV48 Electric Panel Van export reference is about $23,444 – $27,194. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What is Electric Panel Van typically used for?
Electric Panel Van focuses on lower-emission work where charging is available. Confirm local charging and registration before purchase.
How many models does Jinhu Auto JMC Jinhu EV48 Electric Panel Van include?
Jinhu Auto JMC Jinhu EV48 Electric Panel Van currently lists about 5 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Jinhu Auto JMC Jinhu EV48 Electric Panel Van?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
