Foton X13NS6B520 520 hp 13L China VI Diesel Engine
EXW
Export quote
Foton X13 Series engine
Main model photos
9 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Foton X13NS6B520 520 hp 13L China VI Diesel Engine | 520hp / China VI | ||
| Foton X13NS5-520 520 hp 13L China V Diesel Engine | 520hp / China V | ||
| Foton X13NS5-560 560hp 13L China V Diesel Engine | 560hp / China V | ||
| Foton X13NS6B580 580hp 13L China VI diesel engine | 580hp / China VI | ||
| Foton X13NS6B560 560hp 13L China VI diesel engine | 560hp / China VI |
Foton X13NS5-520 520 hp 13L China V Diesel Engine
EXW
Export quote
Foton X13NS5-560 560hp 13L China V Diesel Engine
EXW
Export quote
Foton X13NS6B580 580hp 13L China VI diesel engine
EXW
Export quote
Foton X13NS6B560 560hp 13L China VI diesel engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: X13 Series
Engine manufacturer: Foton / Foton Engine Co., Ltd., Beijing
Suitable Range: For heavy-duty cargo trucks, special-purpose vehicles, tractor trucks, heavy-duty engineering vehicles, and buses.
Intake type: Turbocharged Air-to-Air Intercooling
Engine net weight: 915kg
Engine Dimensions: 1292×992×1050 / 1487×898×1051mm
Engine Brand: Foton
Engine Model: X13NS6B520 / X13NS5-520 / X13NS5-560 / X13NS6B580 / X13NS6B560 / X13NS6B540 / X13NS6B510 / X13NS6B480 / X13
Number of cylinders: 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 12.9L
Emission standard: China VI / China V
Max output power: 382 / 383 / 412 / 426 / 397 / 375 / 352kW
Max hp: 520 / 560 / 580 / 540 / 510 / 480Horsepower
Max torque: 2600 / 2500 / 2400N·m
Max torque speed: 1000-1400rpm
Rated speed: 1800rpm
FAQ
What kind of truck is Foton Foton X13 Series engine?
Foton Foton X13 Series is an export-oriented engine lineup with about 9 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Foton X13 Series engine cover?
Foton X13 Series engine mainly covers: Horsepower: 520 hp / 560 hp / 580 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Foton X13 Series engine?
For Foton X13 Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Foton X13 Series engine include?
Foton X13 Series engine currently lists about 9 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Foton X13 Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
