Foton ISF3.8E6154 154 hp 3.8L China VI diesel engine
EXW
Export quote
Foton ISF3.8 Series engine
Main model photos
16 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Foton ISF3.8E6154 154 hp 3.8L China VI diesel engine | 154hp / China VI | ||
| Foton ISF3.8E6168 168 hp 3.8L China V Diesel Engine | 168hp / China V | ||
| Foton ISF3.8E6141 141 hp 3.8L China VI Diesel Engine | 141hp / China VI | ||
| Foton ISF3.8E6154 154 hp 3.8L China V Diesel Engine | 154hp / China V | ||
| Foton ISF3.8e4R168 168 hp 3.8L China IV Diesel Engine | 168hp / China IV |
Foton ISF3.8E6168 168 hp 3.8L China V Diesel Engine
EXW
Export quote
Foton ISF3.8E6141 141 hp 3.8L China VI Diesel Engine
EXW
Export quote
Foton ISF3.8E6154 154 hp 3.8L China V Diesel Engine
EXW
Export quote
Foton ISF3.8e4R168 168 hp 3.8L China IV Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: ISF3.8 Series
Engine manufacturer: Foton / Foton Engine Co., Ltd., Beijing
Suitable Range: Suitable for light trucks, medium trucks, light buses, pickup trucks, MPVs, SUVs, and small construction machinery and small generator sets / Suitable for light trucks, medium trucks, light buses, pickup trucks, MPVs, SUVs, and small construction machinery
Intake type: Turbocharged Air-to-Air Intercooling
Min. fuel consumption at full load: 195g/kW.h
Engine net weight: 335kg
Engine Dimensions: 810×688×830 / 810X695X806 / 810X695X*806mm
Compression ratio: 17.2:1 / 17.2：1
noise at 1m: 92dB
Bore × Stroke: 102x115mm
Valves per cylinder: 4pcs
Engine Brand: Foton
Engine Model: ISF3.8E6154 / ISF3.8E6168 / ISF3.8E6141 / ISF3.8e4R168 / ISF3.8e4R154 / ISF3.8e4R141 / ISF3.8s5168 / ISF3.8s4R168 / ISF3.8s5154 / ISF3.8S4R154 / ISF3.8s4R141 / ISF3.8s3122 / ISF3.8s5141 / ISF3.8s3168 / ISF3.8s3154 / ISF3.8s3141 / ISF3.8s4168 / ISF3.8s4154 / ISF3.8s4141
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 3.76L
Emission standard: China VI / China V / China IV / China III / Euro III
Max output power: 115 / 125 / 105 / 90kW
Max hp: 154 / 168 / 141 / 122Horsepower
Max torque: 500 / 600 / 450 / 592 / 491 / 380 / 440N·m
Max torque speed: 1200-1900 / 1300-1500 / 1200-2200 / 1300-1700rpm
Rated speed: 2600rpm
Engine Type: HPCR+CEGR+DOC+DPF+SCR / PCR+CEGR+DOC+DPF+SCR / Turbocharged Air-to-Air Intercooling Bosch High-Pressure Common Rail Direct Injection SCR / Turbocharged Air-to-Air Intercooling Bosch High-Pressure Common Rail Direct Injection / Vertical, inline 4-cylinder, water-cooled, 4-stroke, electronic direct injection / Electronically controlled high-pressure common rail
FAQ
What kind of truck is Foton Foton ISF3.8 Series engine?
Foton Foton ISF3.8 Series is an export-oriented engine lineup with about 20 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Foton ISF3.8 Series engine cover?
Foton ISF3.8 Series engine mainly covers: Horsepower: 141 hp / 154 hp / 168 hp; Emission: China IV / China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Foton ISF3.8 Series engine?
For Foton ISF3.8 Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Foton ISF3.8 Series engine include?
Foton ISF3.8 Series engine currently lists about 20 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Foton ISF3.8 Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
