FAW Jiefang Tiger 6G Composite Version 4X2(6 wheels) 4.05m Single Row Pure Electric Refrigerated Truck CATL 140.41kWh
EXW
From $39,139
Export quote
FAW Jiefang Hu 6G Electric Refrigerated Truck
Main model photos
788 photos
Models
On sale
FAW Jiefang Tiger 6G Standard Load Version 4X2(6 wheels) 4.05m Single Row Pure Electric Refrigerated Truck CATL 120.27kWh
EXW
From $36,639
Export quote
FAW Jiefang Tiger 6G Composite Edition 4X2(6 wheels) 4.05m Single Row Pure Electric Refrigerated Truck CATL 120.27kWh
EXW
From $37,611
Export quote
FAW Jiefang Tiger 6G Standard Load Version 4X2(6 wheels) 4.05m Single Row Pure Electric Refrigerated Truck CATL 100.07kWh
EXW
From $34,833
Export quote
FAW Jiefang Tiger 6G Composite Version 4X2(6 wheels) 4.05m Single Row Pure Electric Refrigerated Truck CATL 140.41kWh
EXW
From $39,139
Export quote
Series Specs
Basic Info
Model code (announced): CA5090XLCP40L2BEVA84 / CA5049XLCP40L3BEVA85 / CA5048XLCP40L2BEVA85 / CA5047XLCP40L3BEVA85 / CA5096XLCP40L2BEVA85 / CA5046XLCP40L3BEVA85 / CA5044XLCP40L3BEVA84 / CA5040XLCP40L4BEVA84 / CA5048XLCP40L2BSEVA84 / CA5045XLCP40K51L2E6PHEVA84 / CA5041XLCP40K51L2E6PHEVA84
Drive type: 4X2
Wheelbase: 3400 / 3300mm
Cab length: 5.995m
Cab width: 2.26m
Cab height: 3.22 / 3.47 / 3.27 / 3.37 / 3.35 / 3.17 / 3.1m
Curb Weight: 3.91 / 3.4 / 3.15 / 3.95 / 3.3 / 3.31 / 3.75 / 3.65ton
Rated payload: 4.495 / 0.9 / 1.15 / 1 / 0.99 / 0.965 / 0.55 / 0.65ton
GVWR: 9.1 / 4.495ton
Max. speed: 90 / 95km/h
Origin: Qingdao, Shandong / Qingdao
Energy Type: Electric / Hybrid
electric motor
Motor 1 Brand: FAW Jiefang / CRRC Zhuzhou
Motor 1 Model: CAM270PT52 / CAM230PT52 / CAM230PT53 / TZ180XS018A / TZ180XS016A
Motor Type: Permanent magnet synchronous motor
total rated power: 80 / 67 / 68 / 70 / 60kW
Peak power: 185 / 147 / 130 / 40kW
Electronic Control
ECU Brand: FAW vehicle controller
Battery/Charging
Battery Brand: CATL / FinDreams / Huipeng
Charging method: Fast Charge
Battery type: Lithium Iron Phosphate Battery / Lithium manganate battery
Battery capacity: 140.41 / 120.27 / 100.07 / 131.98 / 96.25 / 132 / 100.224 / 165.158 / 82.43 / 100.46 / 14.016 / 13.616kWh
Engine parameters
Engine Model: XichaiCA4DB1-14E68
Number of cylinders: 4cylinder
Displacement: 2.2L
Emission standard: China VI
Max output power: 100kW
Max hp: 140Horsepower
Cargo box parameters
Box volume: 17.8m³
Cargo box width: 2.1m
Cargo box height: 2.1 / 2.3m
Chassis Specs
Chassis Series: Hu 6G / FAW Jiefang Hu 6G
Chassis Model: CA1090P40L2BEVA84 / CA1049P40L3BEVA85 / CA1048P40L2BEVA85 / CA1047P40L3BEVA85 / CA1096P40L2BEVA85 / CA1046P40L3BEVA85 / CA1044P40L3BEVA84 / CA1040P40L4BEVA84 / CA1048P40L2BSEVA84 / CA1042P40K51L2BE6PHEVA84 / CA1040P40K51L2BE6PHEVA84
Leaf spring count: 3/8+7 / 3/7+3 / 3/3+3 / 2/3 / 2/3+2
Safety features
Remote key:
Tire
Tire Size: 7.50R16LT 16PR / 7.00R16LT 8PR
Number of tires: 6pcs
Control configuration
ABS:
interior configuration
AC control type: Manual
Reverse Radar:
FAQ
What kind of truck is FAW Jiefang FAW Jiefang Hu 6G Electric Refrigerated Truck?
FAW Jiefang FAW Jiefang Hu 6G is an export-oriented Electric Refrigerated Truck lineup with about 18 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for FAW Jiefang Hu 6G Electric Refrigerated Truck?
FAW Jiefang Hu 6G Electric Refrigerated Truck export reference is about $15,403 – $42,472. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does FAW Jiefang Hu 6G Electric Refrigerated Truck cover?
FAW Jiefang Hu 6G Electric Refrigerated Truck mainly covers: Drive: 4x2. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in FAW Jiefang Hu 6G Electric Refrigerated Truck?
For FAW Jiefang Hu 6G Electric Refrigerated Truck: confirm local charging and registration first, then filter by range/power and payload, and quote with your operating route.
What is Electric Refrigerated Truck typically used for?
Electric Refrigerated Truck focuses on lower-emission work where charging is available. Confirm local charging and registration before purchase.
How many models does FAW Jiefang Hu 6G Electric Refrigerated Truck include?
FAW Jiefang Hu 6G Electric Refrigerated Truck currently lists about 18 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for FAW Jiefang Hu 6G Electric Refrigerated Truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
