Fucheng 24.5x8(8 wheels).25 Aluminum Alloy Wheel (Part No.: FCT0187W)
EXW
Export quote
Fucheng 22.5-inch Wheel
Main model photos
2 photos
Models
On sale
Fucheng 22.5x14(8 wheels).00 Aluminum Alloy Wheel (Part No.: FCT014)
EXW
Export quote
Fucheng 22.5x14(8 wheels).00 Aluminum Alloy Wheel (Part No.: FCT0139)
EXW
Export quote
Fucheng 22.5x13(8 wheels).00 Aluminum Alloy Wheel (Part No.: FCT013)
EXW
Export quote
Fucheng 22.5x12(8 wheels).25 Aluminum Alloy Wheel (Part No.: PAK0215W)
EXW
Export quote
Series Specs
Basic Info
Product ID: FCT0187W / FCT014 / FCT0139 / FCT013 / PAK0215W / PAK0202W / FCT0011W / FCT011 / FCT009U / FCT009P / FCT009W / FCT009S / FCT0080W / FCT008 / FCT008U / FCT008P / FCT007W / FCT007U / FCT007
Specifications: 24.5x8.25 / 22.5x14.00 / 22.5x13 / 22.5x12.25 / 22.5x11.75 / 22.5x9.00 / 22.5x9 / 22.5x8.25 / 22.5x7.5
Max load capacity: 3350 / 6000 / 5800 / 5580 / 5170 / 4500 / 4000 / 4550 / 4250 / 4125 / 3650 / 3450kg
inner offset: 144 / 22 / 14.5 / 70 / 120 / 152 / 151.5 / 138mm
Weight: 27.9 / 30.2 / 27.6 / 28.9 / 21.8 / 22.2 / 23.2 / 25.1 / 24.3 / 23.6 / 21.2 / 20.8 / 24.8kg
Web plate thickness: 23.5 / 28.5 / 28 / 22 / 23 / 22.5 / 24mm
bolt hole diameter: 26 / 32mm
number of bolt holes: 10 / 8
Pitch circle diameter: 285.75 / 335 / 285 / 275mm
Center Hole Diameter: 220 / 281.2 / 335 / 221 / 221.1mm
Material: aluminum alloy
Air valve model: TR542 / TR543E / 70MS-07N / TR544D / TR545D
Reference tire specification: Chaoyang Langma 120 (11.00R24.5)；Chaoyang Langma 116 (285/75R24.5) / Michelin 425/65R22.5 XTE 2；Goodyear 425/65R22.5 RHT II / Goodyear 385/65R22.5 RHT II；Goodyear 425/65R22.5 RHT II / Michelin 385/65R22.5 XTE 3；Goodyear 385/65R22.5 RHT II / Michelin295/80R22.5 X LINE ENERGY Z；Michelin 11R22.5 X Coach Energy_Z；Michelin 315/80R22.5 XZA 2+ ENERGY；Michelin 12R22.5 X MULTI Z； / Michelin 12R22.5 X LINE ENERGY Z；Michelin 315/80R22.5 XZA 2+ ENERGY；Michelin 295/80R22.5 XTE 2；Chaoyang Langma 116 (275/70R22.5 PR16) / Michelin 11R22.5 XZA 2+ ENERGY；Michelin 275/70R22.5 XZU 3+；
Remarks: Bolt hole diameters: 26mm and 32mm.
