Dongfeng HV3 3L Diesel 200hp 4X2(6 wheels) Fast Gear 10-Speed 4.5m Dump Truck
EXW
From $27,778
Export quote
DongfengHV3 Dump Trucks
Main model photos
10 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng HV3 3L Diesel 200hp 4X2(6 wheels) Fast Gear 10-Speed 4.5m Dump Truck | 4x2 / 200hp / China VI | From $27,778 | |
| Dongfeng HV3 4.3L Diesel 220hp 4X2(6 wheels) Fast Gear 10-Speed 4.5m Dump Truck | 4x2 / 220hp / China VI | From $29,167 | |
| Dongfeng HV3 4.3L Diesel 220hp 4X2(6 wheels) Fast Gear 10-speed 6.5m dump truck | 4x2 / 220hp / China VI | From $29,167 | |
| Dongfeng HV3 4.3L Diesel 220 hp 6X2R Fast Gear 10-Speed 4.1m Dump Truck | 6x2R / 220hp / China VI | From $23,875 | |
| Dongfeng HV3 4.3L Diesel 220 hp 6X2R Fast Gear 10-Speed 4m Dump Truck | 6x2R / 220hp / China VI | From $23,875 |
Dongfeng HV3 4.3L Diesel 220hp 4X2(6 wheels) Fast Gear 10-Speed 4.5m Dump Truck
EXW
From $29,167
Export quote
Dongfeng HV3 4.3L Diesel 220hp 4X2(6 wheels) Fast Gear 10-speed 6.5m dump truck
EXW
From $29,167
Export quote
Dongfeng HV3 4.3L Diesel 220 hp 6X2R Fast Gear 10-Speed 4.1m Dump Truck
EXW
From $23,875
Export quote
Dongfeng HV3 4.3L Diesel 220 hp 6X2R Fast Gear 10-Speed 4m Dump Truck
EXW
From $23,875
Export quote
Series Specs
Basic Info
Model code (announced): DFD3186GL6D72 / DFD3183GL6D51 / DFD3253GL6D31 / DFD3253GL6D32 / DFD3253GL6D11 / DFD3253GL6D21 / DFD3253GL6D22 / DFD3243GL6D11 / DFD3243GL6D21
Drive type: 4X2 / 6X2R / 6X4 / 6X2
Wheelbase: 3800 / 5400 / 2400+1300 / 2700+1300 / 2600+1300 / 3800+1350 / 3300+1350 / 2750+1250 / 2700+1200 / 2600+1200 / 2950+1250 / 3150+1250 / 3350+1250 / 1750+3000 / 1750+2600 / 1750+2700 / 1750+3300 / 2900+1300 / 3300+1300 / 2500+1300 / 1750+4350 / 1750+3950mm
Engine Model: YuchaiYCY30200-66 / YuchaiYCS04220-66 / YuchaiYCS06245-60 / YuchaiYCS06270-60 / YuchaiYCS04220-61A / YuchaiYCS06245-60A / YCY30200-66 / YCS04220-66
Transmission Model: Fast Gear10JS90A-B / Fast Gear 10-Speed / Fast Gear10JSD120TB / 10JS90A-B
Rear Axle Ratio: 6.33 / 5.83 / 6.17 / 5.857 / 5.73 / 5.286
Cab length: 7.015 / 9 / 6.65 / 6.9 / 7.96 / 7.34 / 7.1 / 7 / 6.8 / 7.3 / 7.2 / 7.5 / 7.4 / 7.9 / 7.7 / 7.16 / 7.05 / 8.2 / 7.93 / 7.73 / 6.75 / 9.35 / 8.75m
Cab width: 2.25 / 2.55 / 2.36 / 2.4 / 2.45 / 2080 / 2360m
Cab height: 2.65 / 2.9 / 2.95 / 3.2m
Front track width: 1910 / 1930 / 1900 / 1940 / 1960 / 1910/1910 / 1800/1800 / 1860/1860mm
rear track: 1800 / 1860 / 1900/1750 / 1860/1860 / 1900/1860 / 1900/1880 / 1700 / 1900/1780 / 1750mm
Curb Weight: 7.2 / 8.5 / 7.3 / 8.6 / 11.6 / 11 / 8.3 / 8.7 / 9 / 9.89 / 8.4 / 8.9ton
Rated payload: 10.605 / 9.305 / 17.57 / 16.27 / 13.205 / 13.87 / 16.57 / 16.17 / 15.805 / 14.98 / 15.97 / 15.87 / 15.47ton
GVWR: 18 / 25 / 24.5ton
Origin: Shiyan, Hubei
tonnage class: Medium-duty truck / Heavy truck
Approach angle: 21 / 16 / 19 / 15°
departure angle: 16 / 13 / 23 / 17 / 19 / 15 / 14 / 11 / 26°
Remarks: lift axle / Lifting axle, ratio optional 5.286 / Lifting axle / Ratio 5.286 / HV3 full-floating cab, ratio optional 5.83.
Energy Type: Diesel
Engine parameters
Engine Brand: Yuchai
Number of cylinders: 4 / 6cylinder
Displacement: 2.97 / 4.295 / 6.23L
Emission standard: China VI
Max output power: 145 / 162 / 180 / 199kW
Max hp: 200 / 220 / 245 / 270Horsepower
Max torque: 850 / 1050 / 950N·m
Max torque speed: 1200-1700rpm
Rated speed: 2300rpm
Engine Type: High-pressure common rail + EGR + DOC + DPF + SCR + ASC
Transmission Parameters
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 10Gear
Number of Reverse Gears: 2pcs
Housing Material: aluminum housing
Cargo box parameters
Unloading Type: Dump type
Cargo box type: stake body / Dump type
Cargo box length: 4.5 / 6.5 / 4.1 / 4 / 4.6 / 4.4 / 4.3 / 4.2 / 5.2 / 4.8 / 4.7 / 4.9 / 5 / 5.6 / 6.8 / 6.2m
Cargo box width: 2.2 / 2.4 / 2.15 / 2.38m
Cargo box height: 0.6 / 0.8 / 1.2 / 1.5m
FAQ
What kind of truck is Dongfeng DongfengHV3 Dump Trucks?
Dongfeng DongfengHV3 is an export-oriented Dump Trucks lineup with about 53 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for DongfengHV3 Dump Trucks?
DongfengHV3 Dump Trucks export reference is about $23,778 – $36,111. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does DongfengHV3 Dump Trucks cover?
DongfengHV3 Dump Trucks mainly covers: Drive: 4x2 / 6x2R; Horsepower: 200 hp / 220 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in DongfengHV3 Dump Trucks?
For DongfengHV3 Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does DongfengHV3 Dump Trucks include?
DongfengHV3 Dump Trucks currently lists about 53 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for DongfengHV3 Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
